1. Class Intro: Hey guys, it's Spencer.
You might know me from pixel and bracket
over on YouTube. I'm a graphic designer from
Indianapolis, Indiana. In this class you're
gonna be learning so many different tools and
techniques in Adobe Illustrator, I've compiled a ton of different flat design tutorials and lessons for you guys to complete everything
from making a castle to a birthday cake to flat
design potted plants. Any one of these can be
completed as your class project or maybe you're
feeling ambitious and you're gonna do them all. I cannot wait to
see what you guys post and I'll see
you in lesson one.
2. Flat Design Tree: I'm gonna walk you
through step-by-step how to create a little
flat design tree. And you're going to
know much more about illustrator and hopefully
be a lot more comfortable. By the end of this tutorial, we're truly going
to go step-by-step. This is the new files
starting document window, screen thingy, and then the upper left-hand
corner and see new file. So we can click on that
and it's going to pull up the dialogue box from here. You could name this
as a new preset. You can select from a ton of different recently used
ones or anything up here. If we go to a web really quick, I think we could probably just
grabbed this 1920 by 1080. So you check the width, check the 1920s by 1080. Pixels are the dimension
we're gonna be using. I like RGB color mode for things that I'm creating
for digital work, CMYK for print works. So we'll stay on RGB under
here in the advanced settings, everything else will
just leave the same. Hit Create. We're going to have a new blank, 1920 by 1080 art board children in front of us right here. Now one thing you can do to get your window the same as
me is go up to window, down to a range
actually workspace. And you can click on Essentials and then we could
reset essentials. That's going to remove a couple
of things from my window, will open them up if we actually need them
as we move along. So you shouldn't see
the Properties panel here on the right Illustrator. Move them from the top down. If you're on an older
version of Illustrator, you'll see a lot of the things I mentioned in the top toolbar. And you can find
any of the windows that you need underneath
the window drop-down, like the alignment
panel and then the Pathfinder panel and all these
different things in here. Anything to do with type we won't use type in
this video though. Let me go ahead and get started. This is a tree. We're
going to be creating it out of triangles. I'm gonna click and hold on the Rectangle tool and
find the polygon tool. Another quick shortcut on
this essentials toolbar. We actually lost a lot of tools. One thing I like to do is
click on this Edit toolbar, go to the three little
hamburger menu thing, and click on advanced. So now our toolset here on the left-hand side is
the advanced version. We have all the tools in
front of us and you can minimize this to be a single
column or a double column. I kind of like the double column when I'm doing these tutorials. So that's what I'm on over
here on the left-hand side, we may make some
adjustments as we go along. There's some tooltips. I'll definitely do a tutorial
on how to get rid of those. Can't wait. All right, so we've got
the polygon tool out here. Click on your canvas
or art board and it's going to let us adjust
the number of sides. We're going to drop that
down to three radius, doesn't matter and hit
Okay, we've got a triangle. Check that out. We go back
to our selection tool. The shortcut key for that is V. And we've got this
little triangle out here and we can scale him up. We can keep him in proportion if we hold shift just like that. Let's scale him up a little bit. It doesn't matter
the size, it all. Now this has a white
fill and a black stroke. The stroke is the
outline and the fill is the color of
the actual shape. If we click on the stroke here, it might open up your
color guide here. And you could always pull that
over here to the side and till it highlights in blue
and drop it in over there. So now we have the
colors right here. If we'd like. One way I like to
adjust color is by double-clicking on the
fill or the stroke. And you can actually
use this color picker. It's my favorite. We'll probably
come back to that. But with this stroke, I actually don't want to
stroke and I'm gonna hit None. And you guys, I do not
like these tooltips, so let's go ahead and turn
those off really quick. We'll go up to the Illustrator
preferences into general, and I'm kind of assuming that they're gonna be
in here somewhere. Look at that right there,
show Rich Tooltips. I do not want that. I do like tooltips, but the rich ones
get out of here. All right, so now when
we hover over things, it just shows that little one. That's what I'm more used to. If we click on the fill, it's going to pull
it up to the front. We can double-click on it and until of course this is a tree. So let's pick a darker color. And if you stay in
this center area, it's a nice muted tone
in here, up here. It gets a little more
saturated over here, desaturated and then lighter at the top and darker
at the bottom. If you find your
way to the middle, you're going to have a
gray or green or I like to call it like a muted tone with any of these colors
that were picking. You can see the little
color hex code down here. So you can just grab
that and paste it in or type it in as you're, as you're working with me
and we're gonna hit okay. All right, so we got a little, little triangle tree now, we're going to maybe
zoom in a little with Command or Control
plus and minus. We can do that. I say command for Mac
users, control for Windows. We're going to duplicate
this piece of the tree down. Hold Option or Alt until you
see the double ended arrow. And you can duplicate
this piece over anywhere. You let go and it's there. We can bring it back over. Have you noticed all
these little little lines that allow me to intersect
and line things up, but those are smart guides. Smart guides are really
useful for exactly this. If I wanted to bring
this piece back over to the center of this piece and also start to line it
up in different spots. Smart guides are the way to go. So we're gonna go up to View, down to Smart Guides and make
sure that is checked on. Seemed to have Snap to
Pixel on if you want to get this all the
same as me as well. But anyway. We got this guy here. And what we can do is find this double ended
arrow at the bottom of him and we can click and
drag to make him larger. And if we hold
shift, once again, it's going to increase the
scale of this triangle. We could do that and then maybe
bump him up a little bit. You can use the up
and down arrow keys. And then if you hold Shift
while you're using those, it bumps them up and
down a little bit more. If we find the right little
spot I like that I think will keep something like that.
That's all we need to do. To build up this tree. We can keep clicking on the next piece
holding Option or Alt, getting a double-ended arrow, we can click and drag it down. Smart Guides helps
us keep it lined up. We can also hold
Shift while we do it and it's really
going to stay lined up. And then once we get
it somewhere in here, we can just find
the bottom of it, scale it down, hold Shift. It's going to bump
it out a little and make it a little
bit bigger like that. So as we build out this
tree the way that we want, we can just keep doing
that kind of thing. Maybe we'll do one
more hold Option or Alt and Shift and just
duplicate that down. Grab the bottom holding Shift, kind of scaling it
out just like that. So you can see how this tree is getting
built pretty quickly. I can click and drag to select everything here because we
have four different triangles. And then I could find
the bottom again and we can actually scale this down. You can, if you feel
like yours is too skinny or you want it to
be wider, you can do that. But I'm going to hold shift
just to make a little smaller so it fits on our
art board here. Once I've done that, another
way to zoom in and out, That's pretty easy as to press
Z shortcut key and you get the little magnifying
glass click and drag to zoom in and out. See that? Kinda drag them to the right, zooming in, dragging
left, zooming out? Probably the same
with up and down. No, not really. So right and left. Okay. So one thing I wanted to
do here is maybe just increase the size of this
triangle at the top. So that actually what I could
do is just bump these down, maybe the three
bottom triangles. I'm going to bump them
down just a little bit. I just felt like the top needed to be a
little bit bigger, like this line here
in relation to the other ones could be
just a touch larger, maybe one more bump up. All right. I'm just
being picky there. What we're gonna
do now is create the trunk at the bottom, the trunk of our tree. So let's select this fill
and grab something brown, and we'll probably do a
little bit darker brown, Something like this. Hit. Okay, remember that hex code
if you need it, hit okay, so we've got a brown,
we're going to click and get the
rectangle tool. The shortcut key for that is M. Once you have that, we're
just going to create a little rectangle out
here for our trunk. So something like this. Then we can actually center all this
together really easily. Even without the smart guy, you could use the smart guides, but what it will do is select everything.
Select everything. And we can then
click on the trunk. You see how that highlights it in more of a blue than the rest. That means this is now
the key object and we're gonna be aligning
to that key object. In the properties panel
on the right-hand side, you'll see the alignment panel. But also if you drop the
Window drop-down down, That's a lot of drop-down downs. You can click a line here and actually open up the
alignment panel. You can dock it over here
if you want or anywhere. You can use any of these. They're all the same. I'm just showing you
different spots. Anyway, we're aligning to a key object so we could
select that just to make sure, but once you click
on this again, after you select everything,
then click on this. Now we're aligning to that, which means everything
else will align to this. So if we press this
guy right here, which is horizontally aligning the centers are
tree scoots over, so it's in the center
of this trunk. Now, let's bring this
guy up and look, he's on top of our tree.
We don't want that. So what we're gonna
do is click on him, right-click on him, and then go down to
arrange, Send to Back. Now it's behind this tree. And I think that works out
pretty well right there. So we'll keep,
we'll keep that you can make this however
you want really. Alright, so there's
a couple more things here that we can do. One thing that we'll
do that I think is super helpful to keep in mind as you're working on
anything here in Illustrator as Erin dropping likes to say vectors are free, which means I can take
this state of this tree, a working file, almost
duplicate the whole thing out. I selected at all. I can duplicate the
whole thing out. And I can just drag it over
here and keep it over here. I could always go back to
this separated version of the tree if I want to. I always do that when I'm
gonna do something that I feel like is more of a
destructive technique. Nondestructive is
keeping all these shapes separate so you can edit them. Destructive would
be selecting them all and merging them together. So that's what we're
gonna do really quick. So don't select the trunk or you can select
everything and then. Shift, click on the
trunk to de-select that. You can also click and hold Shift to select
things individually, but sometimes it's easier to just grab it all
and de-select, uh, one thing you don't want by
holding Shift and clicking, I've got all these selected. I'm gonna look at my
Pathfinder options. Remember Window
drop-down Pathfinder if you need to find it. And I'm going to click
Unite right there. This is just gonna emerge
to these shapes together. Now this is one piece. You can also group it together, but I like merging this together so we can
just makes it easier. We're not going to bump
things around on accident. Alright, so the other couple of things that we
can do here is add a shadow to both this top
tree and this bottom trunk. The shadow super-easy
press M for that shape tool and then click on or
double-click on the fill. Let's go and drag it
down here to the Black. Want to make this a black
all zeros hex code. Hit. Okay, and we're gonna create
a rectangle and this is where smart guides are really
important, really useful. We're going to create
a rectangle that's got to start taller
than the tree. It's going to finish further
down than the bottom. So we're gonna make sure
we start it up here. It covers the entire right side of the tree and we're going to line it up to intersect in
the center, doesn't matter. All these shapes, this one and the trunk are all the same. So just make sure we can make sure by hitting
Z and zooming in and then clicking on
this rectangle and we can bring it in and out with
this double-ended hours. Just make sure it
snaps right there, right there to the
center of the tree. Once you have that, then we can select the top of the tree here. And this black rectangle, we can use something called
the shape builder tool. The shape builder tool
super quickly sees each of the different overlapping pieces of whatever you have selected. It does not see the trunk because we didn't
select the trunk. We just have the top of the
tree and this black shape selected if we hold
Option or Alt, notice how the cursor
changes to a minus. We can just click
on this to subtract out this outside shape. Now if it was a plus, you can merge things together. You could do that, but
that doesn't do anything. In this case, that's
not what we're doing. We're subtracting out. So you hold Option or Alt
and subtract that out. So now we have this really
dark side of the tree. What we could do is if we look in our Properties panel
in the appearance tab, that's another one under window. If you want to find
it, we can go to opacity and click
on Opacity to open up this little dialogue box where we can change
not only the opacity, but also the blending mode. You can hit multiply on this if you wanted
to and then change the opacity or normal or any other blending mode to get the effect that
you're going for. For me, I think what
we'll do is maybe drop it down to 10% opacity. You could go even like 20 if you wanted a little
bit darker shadow that's a little
bit more visible. So maybe that's what we'll do. Then what we'll do
is just press M for the rectangle tool again and then just do the same
thing down here on the trunk. I didn't really like how this if this all came down
in the straight line, I'm going to adjust it here on the trunk
just a little bit. So it's gonna be a
little bit off-center. If you can tell. We'll zoom in real quick. I'm gonna select both the
trunk and this rectangle. Shift M is the shortcut key
for that shape builder tool. And you can tell that I didn't completely cover the entire
right-hand side of this. Now one thing to note
here is the rectangle of the trunk is a little
bit larger than this black rectangle
that just made here. I can switch back with
the shortcut key V to the selection tool
and make sure I cover up every piece
of that trunk. So I make this rectangle
is tall enough to cover up what's behind here. Then I can select both Shift M for the shape builder tool. And what we'll do here is the
exact same thing will hold Option or Alt and just get
rid of the outside rectangle. Once we do that. Now we've got this piece
and the trunk here. This piece is in front. So we'll go ahead and
send all of these guys to the back by selecting them and then right-clicking
send to back. So it go underneath this. And we'll do the
same thing here. We'll grab this rectangle, will go to the opacity
and maybe drop it to 20% just like that. Now there's a couple of
things that you can do here as far as the shadow, like the long shadow or having a shadow
underneath the tree, we could do an oval. We can click on this shape
tool, find the ellipse tool. And we could do like
a really small oval, like a very skinny
one down here. And we could click and
make sure we center this up and then send it
to the back, Send to Back. Then once we have that, we can drop it
down a little bit. So if we see this guy
is right below this, we probably need him to
be like who is wide, as wide as the tree at least. So we'll zoom in a little bit till we can get those
double-headed arrows. We can grab these corner
ones if we wanted to, but if we zoom in
a little bit more, we might be able to
get the directly like side-to-side ones. And if we hold Option or Alt, It's going to scale
it from the center. So we already have
this lined up. We can scale it from the
center and out just like that. And then what we
could do is drop the opacity of this,
maybe like 50% And actually I think
that's a little wide. Maybe we can scale this back in, maybe maybe having more
like that was okay. Maybe twenty-five percent,
something like that. So you've got this little tree. I mean, really you
could make this a little bit wider
if you wanted to. Maybe we went a
little too skinny. You can do something like that. So you can actually
see the shadow below it, just like that. You could do that,
or vectors are free. Let's grab this guy, just drag them over here. We're going to duplicate
the entire thing out. Another thing you can do
is using the blend tool. I don't really like to
blend tool as much anymore. So maybe we will look at
a different method here. Yeah, I think what
we'll do is create a rectangle and then start
at this anchor point. So the top of the
tree click and drag. It's kind of like
making that shadow again and make
sure it locks into the bottom of the trunk. I'm actually going
to go beyond that. Then I can press Z
and zoom in here. And with this guy, just make sure
that I lock it and snap it into the bottom
there, just like that. Now we'll use a
gradient tool on this. If we find G actually is the shortcut
key for the gradient tool. So if we do that, we need to add a
gradient to this. I'm going to go find
my gradient panel and we can just click
on the linear gradient. I actually want
this to be flipped. So I'm gonna open
up the options of this gradient panel and it looks a little bit
more like this. And I can bring the white
and black swap sides. And actually I didn't
need to do that. It's really wondered,
want to do is change this white to black. We have two blacks. But I want the opacity of
the right-hand side to be 0. The difference there is
it goes from black to black with the opacity being 0. So this is totally see-through here on the right-hand side, that's more what I want. So once we have this
linear gradient setup, what we can do is grab the
direct selection tool, which allows you to play
with these anchor points. There's two anchor points here, 12 on the right-hand side. If we click and drag, we can grab them both. We can also hold
Shift to individually select or deselect
anchor points. As long as you have
them both selected, you can then click and drag on the path in-between those two. And we can drag
that path around. The gradient, follows the angle as well as we've
been this around. What I would do is maybe grab it and put it right
in here like this. So this is gonna be
a long shadow and then this is obviously
in front of everything. So we need to go back
to our selection tool. Shortcut key is V, right-click and send this
sucker to the back. Send to Back, just like that. And then we want it to
be a lot less dark. We want it to be
like some kind of twenty-five percent
type of opacity. Again, in regard to where
the shadow lines up. Now I made a mistake
here and we can fix it really
quickly and easily. We don't want the shadow
to start in the middle of this trunk and needs to start
from the right-hand side. What we'll do is press a again for that direct
selection tool, grab this anchor point here. So as long as you have
this shape selected, snag this anchor point, and we can bring
that anchor point. Just click and
drag over to here. Now, the shadow actually starts
at the right-hand side of this tree and then the
top of the tree up there. And maybe that's not right. I don't know. That
doesn't look right to me. So you could drag it
to the left-hand side, but you could put it anywhere. That's the whole point of this. You can put that guy anywhere. So maybe the shadow
starts there. And then you can always
edit this by grabbing these two anchor
points over here. You can stretch it out,
you can bring it in. I think this is a
much better way to do a long shadow than the old blending mode method
I used to use. Plus it uses a lot of computer resources and it also tends to look
really choppy. Anyway, I like this
method and we could just keep adjusting this
opacity if we want. One thing I do want to show
you on the gradient itself, you can adjust the
opacity as well. If the properties
panel gradient menu is kind of tough to find, the gradient menu can
be found right there. What you can do here is adjust where basically we're
going from black to black, from a 100 to 0 with this little gradient
slider in the middle. That means it's going
to be perfectly 100 counting down to 0.
Once you get to here. If you adjust this a little bit, you can see how it favors
one side or the other. Now this goes a
little bit slower, and then it's going to
be a lot quicker to 0 once you pass this midpoint. Same thing here. You could go really
quickly from dark and then it's going to hit the midpoint and then go
a little slower to 0. So you can adjust that there. You can also just the end
point here of the shape. Do you want this gradient to finish before the end
of the actual shape? You see the end of
our shape is here. But if I drag this
finishing slider back or the opacity turns to 0, it actually, the gradient
finishes here and the rest of the shape is
just blank 0 opacity. So you can make some minor adjustments to the gradient here if you'd like. And also, then we can just adjust the entire shape itself. But grep crabbing
this opacity here. And drop in that as well. So those are a couple of ways
you can really adjust this. But overall, I think I
liked the effect better. Or you could do a more
realistic shadow here at the bottom of
your tree as well. Now, let me show
you one last thing. I'm going to click
and drag and just pull this tree over here. We'll stick with this
one because that's what would the old tutorial was and I just wanted to make
this update for you guys. Let's make a quick background. So what we're gonna do first off is click and drag to
select this whole thing. We're going to group
them together. So that's Command or Control G. Or you can right-click
and go to group. Just like that. With this group, I might just move, I might
just move them out of the way. I'm a move them over here and we're going to create
a quick background. We know that our art
board is 1920 by 1080. We can press M for
the rectangle tool. Click on our art board
and go ahead and type in 1920 pixels by 1080 pixels high. Hit Okay, and then
to center this on our art board pretty easily we can go to the
alignment panel, align to art board, and then center horizontal
and center vertical. Just like that. But we need a better color. So we're going to
double-click on this and we're going to grab something like a
really light tan, maybe a little less yellow,
something like that. It okay. I want something like this. And then what we can do is go to the Layers panel and
then create a new layer. We could have done this
first, but we didn't. So we're creating a new letter, we're calling it background. We're gonna drop
it to the back or the bottom of this layers panel. And then you can find, first-off, you can find
all the shapes we've made. But we can find this
rectangle would just made and drag it to the
background layer. You could also have
done this in reverse, created this layer and
then select it and then added the rectangle
to that layer. But anyway, that's all
we have down here. So what we'll do is click
right here to toggle the lock. Now we cannot accidentally grab it and move it around or
anything. That's perfect. Then we can grab this little
tree which is on top layer. We can bring him out here
and we can send her or him. But we're going to need
to do a little something here because it all centers, centers this box, you see
this bounding box here. It centers this box
on this art board, which means our tree, if we wanted to a
tree in the center, it's a little bit offset. You could send to the
tree and then align the shadow to it if you want. Or you can just sort
of eyeball it if you want and we'll scale
it up a little bit. I'm holding Shift and
Option or Alt to scale proportionally from the center out just to make it
a little bit bigger. And then you can line it
up wherever you want. And then you could also always
ungroup this really quick. And then maybe just take
the shadow over here. You know how it lines up,
don't resize anything, but then grab this tree, group it together, and then
center it on your art board. Now this tree is actually in the center of this art board. And then we can grab this shadow you guy and bring him over. And it's easier
maybe to zoom in. And we know that when we created this point right here at
the top of this tree, so we can bring that over and intersect with that
right up there. Once we have that, we
should be good to go. Now, a couple of things
I noticed that I did, that you guys should be aware of this Z and I'm zooming in. I missed it. I missed my 0.1 off for both of these and I'm having
trouble lining this up. It's just bumping around. And I believe that's
because we're snapped to pixel and that might have been a mistake at the
beginning of this, I can always improve you guys. Instead of snapping to pixel, we're going to turn that off. What we want is Snap to Point. We want these points
to snap together. We don't want individual
pixels to be snapping. Once we have that, we're
able to click and drag this around to bring that
point right there. That's probably why this
shadow is off as well. I take back what I said. Snap to Point is nice or
don't even snap at all. Snap to pixel is going to actually snap to each
individual pixel. But you can create shapes
in-between pixels. So that doesn't
really help you as much unless you're trying
to create pixel-based art. That may have messed
us up a little bit, but that's one piece
that I noticed now. I'm just clicking and dragging
and looking down this. Yeah, see where a little
bit off down here to what we could do to
make it even easier. Press a for that
direct selection tool. Click on this point
and then click and drag this point to
snap it right there. I would say that that is exactly how I would
get this lined up, up here as well. Click a, I'm going to
click on this shape, so I make sure I get
this anchor point. And I can click and drag this around and snap it into there. I can do the same thing
with the shadows as well. I can click on this shape, that's the shadow shape. Click on this anchor
point and bring it up to snap into there. And depending on where this
ended up lining up down here, we're holding shift
just coming down here. What we can do is
the same thing here. I know that the trunk and the tree leaves or
whatever are centered. So I'm gonna press a
for that anchor tool or sorry, Direct Selection tool. Grab the anchor, you
can click on the shape. It's going to select the shape. Then you can click
on the anchor point. And now I have just that
anchor points selected. And I can drag that either way. I know when I see this
intersect right there, that's gonna be the
center of this tree. We've officially fixed that now. But I'm just showing you that. That's why snap into
points, snapping the pixel, these settings
actually snapping to pixel can actually
hinder you a little bit. So forget what I said before. That's not how we
wanted to have this. We wanted to snap to points, so these points can
snap together easily. And now we've, we've
fixed our tree. So at least I covered that
in this tutorial as well. I hope you guys
enjoyed this tutorial, this new flat design
tree tutorial. It's an update on the old one. And I used a lot better tools and this one things that
I didn't even know. So don't be afraid
that you don't know everything about
this program yet. You guys will get the hang
of it and just keep trying. There's a lot of
different flat design tutorials on this channel. And if there's
anything I can do to help you hit me up in
the comments down below. I'll catch you next time.
3. Flat Design Traffic Cone: Let's start a new document, command or Control N, or just go find new. I'm going to create
1920 by 1080 pixels. And CMYK RGB doesn't matter. Let's go RGB. I like creating digital artwork. Here is our new Canvas and we're going to start
by creating a triangle. Let's go over to
the rectangle tool, click and hold and go
to the polygon tool. Click on your Canvas one time, make sure the sides are
three on that polygon. Radius doesn't matter. I'm going to leave it at 50. Hit, Okay, and we have
ourselves a triangle. Now let's take a look
at our Layers panel. Go up to window, down to layers if you don't see it on the right-hand side. But if you do, you should see layer one right here
has a triangle on it. Double-click layer one and
rename this to outline. This is going to be the
outline of our shape. And I'm going to create
three new layers just by clicking that new layer button
down at the very bottom, we've got a bunch of
different layers here. Drag the outline layer
to the very top. Next up, we're going
to name this shadows and highlights after that color. And last but not least, I'm going to call this
last one background Kevin, optional layer. But background down
here at the bottom, lock these three layers, background, color and
shadows and highlights. And let's make sure we
have outline selected. We're going to be
creating the outline of our traffic cone
completely on this layer. I'm gonna zoom in by
pressing the Z key and then clicking and dragging
just to zoom in a little bit. With this shape selected, we're just going to
pull down the bottom to elongate it to
that traffic cone. Look. Now press a for the
direct selection tool, the shortcut key for that, as I just said that, but the direct selection
tool is up here. It's the white arrow, click and drag to select that top point, you might have to
press Z and zoom in a little bit and then press
a to go back to that tool. And we're going to round off this top corner a
little bit just until it looks like what you think a traffic cone
should look like. Then I'm going to select
this entire shape, go to the Properties panel. Any of these windows are always
in the Window drop-down. So go find properties
if you don't have it. From here, the stroke size, I'm gonna make the stroke eight and we're
gonna keep that the same for everything
in our document. That kind of changed
what this looked like. And I think I might just round this off a
little bit more. Then we can click these bottom two points with
that direct selection tool. And we can pull down to change the different
size of our cone here. I'm holding shift as well. You don't have to, but you might get a little wonky like that. So hold Shift to keep it in line and pull it straight down. We're just going to size
that traffic cone to about what we think it
should look like from there, I like that and I'm
going to go select the rectangle tool shortcut key for that is going
to come down here, see all these pink guides, those are smart guides. You might want to turn
those on in the View drop-down down to Smart
Guides, command or control U. To do that, what I'm gonna
do is make sure I see that smart guide lined up right here on the middle of that path. Click and drag with
the rectangle tool. And we're going to create
a very skinny rectangle down here at the bottom. Maybe a little bit less than a little bit skinnier,
just like that. Now with this
rectangle selected, I'm gonna go over
to my appearance. Click on Stroke, and we're going to round the corners here. And I think that should create a round enough corner
for your traffic cone. We might zoom in a
little bit here. I might even pull these guys
in just a touch as well. Remember I'm just selecting
with my selection tool and finding those Corner Widget
bubbles that we can pull in, go up to View, down to should be right here.
Hide Corner Widget. You can show the corner
widget if you don't see those little circles. Now as I zoom out, I feel like the top portion is a little bit small
compared to the bottom. So I'm just gonna click
and drag and hold Shift to scale that up a
little bit and get it looking like it fits
the bottom section. Select both. Go over to your alignment
panel and make sure those are horizontally aligned to
the center of each other. Otherwise they might be a
little bit off like see this is left aligned and right align. We're going to Horizontal Align. Make them in the
center just like that. We are looking good with
our outlines so far. Next up I'm gonna grab that rectangle tool
shortcut key is M. We're going to draw
the two lines that go through the center
of our traffic cone, holding Alt or option
to click and drag and duplicate that rectangle and then sort of position
these wherever you want. I'm just going to manipulate
them a little bit, maybe something like
this right here. Next I'm gonna click and drag
on all of these elements, make sure everything
is selected. You might notice
if you started at a new document that
your fill is white, so I'm going to just
select None for the fill. And you can click on the fill or the stroke
to highlight that. And if you select none, it's going to change that
Command or Control Z to undo. Whichever one is in front is where that none is
going to apply. This color guy popped up, we're just going to
exit out of that. Now after you do that,
I noticed one thing we had Scale Strokes selected. So that means when this
guy scaled up earlier, our stroke weight actually
scaled up as well. In the transform panel,
in the properties panel, there's a little ellipses
here and you can see scale corners and scale strokes
and effects are selected. So as we scale our objects, the corners, the
strokes and effects, those are going
to scale as well. So we have to be
careful with that. I'm gonna make sure
this is back to 8. Next, what we're gonna
do is delete out some of these paths so we can use
the shape builder tool, select the direct
selection tool. Shortcut key is a just click
in-between these paths. So in-between these
two anchor points and hit the Delete
key on your keyboard. Same thing over here
is even easier, is to click and
drag through them and hit delete so
I can make sure I just get that path selected. I'm just deleting
out these paths. If you don't get it right,
sometimes it might even select the whole shape and
delete the entire thing. Clicking and dragging
through might help you. Now I'm going to switch
to the selection tool shortcut key for that is V. Select everything up top here, go to my shape builder tool
Shift M is the shortcut. And then while I
have it out here, I'm gonna hold Option
or Alt on PC and I'm gonna click and drag
through the outside lines. And that's going to
get rid of them. Click and drag through
the outside lines and that gets rid of them. Now when we take a look at the outline view
Command or Control Y, you'll see that all these
lines match up perfectly. That's what we want. So everything I'm seeing
here is looking really good. You're going to want to make
sure all that lines up so none of the stroke
weights look off. We're going to switch back
out of that preview mode. We're looking good with
the outline. I like it. I'm going to select this
big triangle shape, hold Shift and select
the bottom part. And then Command or
Control C, That's copy. We're gonna go over
to our layers panel, lock that outline mode, an unlock the color, and then make sure you select on that color layer as well. Go up to Edit, down to paste in place, that's Shift Command
or Control V. And now we've pasted
that outline into the color mode or color
layer, I should say. I'm going to select
both this bigger shape and this rectangle. And we're going to
swap the fill and the stroke by clicking this double-ended
arrow right here. Now what we have is the
same cone but filled in with color right on top
of where it should be. So I'm going to give
this an orange look. I like to double-click on
this swatch over here, and then I can
select something in that orange color space. Maybe a little bit more orange, something like that
would work hit. Okay, now we have
an orange cone. Let's fill in those white
stripes on this cone. I'm going to press P for the
Pen tool that's up here, this little pin tool icon. Make sure that
you're of course on your color layer and your
other layers are locked. Click in-between these outlines and create a shape
that goes in-between. Where do you want
the strike to go? Just like that. Now I'm going to go
over here and change the color of this shape
by double-clicking to something maybe a
little bit more white or I'm going with just a
slightly gray tone hit. Okay. And it's filled that in. We're gonna do the
same thing down here. We're just going to
create a little shape that goes in-between this space. You can press I for the eyedropper and select
the color you want. Same with the orange. You could select the
orange, you can select white or whatever color you see using the eyedropper tool while that shape is selected, will change the
color of that shape. Cool. Now we're getting somewhere. I like where the colors are at. We're going to lock that
color layer and move on to our shadows and
highlights up here. I'm going to zoom in
just a little bit more Command or Control. Plus, let's create a shape
with our pen tool again. P for the Pen tool, I'm going to start
right about here. This is gonna be a highlight. I'm going to click to
make a point there. Come down. And this is gonna be,
it's gonna go all the way down to this
lower portion here. So I'm gonna click outside of the color area
underneath the outline. Back over here, but
not all the way to the side. Same thing. And then we can just
finish this up here. Now I want this to be a little bit more parallel to this line so we can press a for
direct selection tool, click on this anchor point. And I'm gonna use
my arrow keys to bump it over just a
little bit until I think this is a very parallel line to the side of my traffic cone. I think something like
that works pretty well. Now I don't like how sharp
this point is up at the top. So I'm gonna press Z, zoom in a little bit just by
clicking and dragging. I can drag left and
right to zoom in. That's called a scrubby zoom. Use the direct selection tool to grab this top anchor point, only the top anchor point and
pull it down a little bit. We're going to round off that
sharpness just like that. Now it might've dropped
it down a little bit. So what I could do is click and drag to select
these top points. And then I might need to zoom in a little
bit here to make sure I can drag it up without
changing the roundness. Some kind of click on one
of these anchor points and drag it up to here, just a little bit higher,
something like that. There we go. We've got this little
highlight thing. Now what we can do with this piece is changed
the color of it. First off, double-click,
I'm gonna make it a yellow, a bright yellow. Something like that. Hit Okay. Now we've got this
bright yellow shape over here in Properties, I'm gonna change the opacity
by clicking on the Opacity. First two maybe like a
screen blending mode. And then we can actually adjust
how transparent that is. So we can bring that
down a little bit if we'd like just
to find where we'd like that highlight color to be something like
50% might work. And then of course you
can play with the color. I feel like the yellows
popping a little too much. Maybe the screen blending
mode isn't even what we want. Maybe we just want normal and
we just want it to be 50%. Could be any of those. I kind of liked the screen
potential blending mode because it doesn't
show the color as much on here is as much as
it shows the highlight. But anything like that, you can play with that option. Now I'm going to show the
highlight down here as well. I could create just
a square shape with the rectangle
tool right down here. Simply like that, press the eye eyedropper key and you can click on this highlight and it's gonna change
it to that color. Just like that. I like
that for the highlight. And now we're gonna
do the shadow on this right-hand side. Press P for the Pen tool. I think I'm going to start
this shadow right down here. I'm going to try to
remain parallel. So we might even undo that. I might start at a little
bit closer to the edge. So somewhere right here, stay parallel with the
side of the traffic cone. I'm going to click
right in there. And then up here I'm gonna
click and drag a little bit. So it's going to round
off that corner. Then we're just going
to click down through the outline down here to the bottom to close
that path off. If you look at what
I did up here, if we zoom in a little bit, I'm going to use my
direct selection tool to click on these different
anchor points. I've rounded this off now I
don't like how that finished. I might take this
anchor point and move it over just a little bit. And then I might click
on this anchor point and convert it to a smooth point. So I'm gonna click
on this right there. That helps convert this
to a more smooth point. Otherwise it's got
a sharp edge to it. Now this isn't much, this is just a tiny bit of curvature. If I click on this
anchor point can bring it over just a little bit more. I think it just helps the top of the shape here
curve a little bit. Since the top of this cone is, is round, it's not just
straight squared off. Now we're going to click on this and we're gonna
change the color. Let's change it to something
like a darker orange color. Like this. I'm going
to go to opacity, hit Multiply on that, and then we're
going to bring the actual transparency
of it way down to find the opacity you like here and you've got your shadow. We're gonna do the same thing
down here at the bottom. Press M for the
rectangle tool and create a little
rectangle down here. And then I for the eyedropper
key and make sure you select this shadow over here, which will help create the same color there
at the bottom. If we zoom out, we are looking pretty good with
our traffic cone. Now the last thing we could do is add a background so we
can go back over to layers, lock the shadows and highlights,
unlock the background. And in this case, press M for the rectangle tool. And then just create
a shape out here. Double-click on the color. And I think I chose
something like blue, something like that for the for that orange blue contrast. And there we go. You've got a background and
your little traffic cone.
4. Flat Design Cheese: A flat design cheese slice. That's what we're making
in this tutorial. First thing I'm going to
create a square using the rectangle tool
shortcut key is M. You can create a
square or a rectangle. It can be perfect square or just kind of eyeball it
just like that. Now we're going to
add a stroke to this. I'm gonna go ahead and
use my eyedropper tool just to eyedropper
this color over here. It added it as a fill to
flip the fill to a stroke, you can just click this
double ended arrow on the left-hand side. Once we have that,
I want to change the stroke size to
something like 15 points. And then I can hop into the stroke properties
and actually adjust the roundness of the
corners of this stroke. And along with that,
I'm gonna select this, zoom in a little bit so I can see my corner widget right here. If you don't see it go
up to View right here. It's gonna be Show
Corner Widget or Hide Corner Widget if you already have it
shown like we do, I'm gonna just pull in these
corners a little bit to help the inside corner not
be so sharp as well. Now before we get too far along, we're going to go
ahead and start by drawing every outline
of this cheese slice. And I want to do that
only on a single layer. In that layer we're
going to name outlines. If you don't have your
layers panel open, go up to window, down to
layers to open that up. And we're gonna have
two other layers. Those are ones color swatches. So that's a third other layer, but the two other, if we add another one here, are going to be color, and then we'll add a last layer. We've got shadows and
highlights, color and outlines. I'm going to readjust these
and pull the outlines to the top underneath that shadows and highlights underneath
that will be the color. So make sure you have outlines selected and we'll continue on. I'm gonna go back over here
and select the ellipse tool. The shortcut key for that is l. And let's take a few
bites out of this cheese. I'm just going to draw a circle. There's nothing
perfect about this. And then press the
V shortcut key for that selection tool,
select everything. And then Shift M is the
shape builder tool. Notice the icon over here. What we can do with this is hold Option or Alt until you
get a little minus sign, click and drag through
these two shapes here. And it's going to just take a bite out of our cheese
slides just like that. We're gonna be putting holes
in this piece of cheese. And we might as well
have a few along the outer edge as well. So we can press L for
that circle tool. And let's just create a
couple more circles out here. Maybe one there, maybe
one here like that. Press V, we can select
everything by clicking and dragging Shift M for the shape builder tool
hold Option or Alt. And just drag through
these to where they highlight
where they overlap. And it's gonna
take a little bite out of the side of the
cheese right there. We've got a couple of
bites out of our cheese. Next I'm going to press L again and create a
couple of circles on our cheese to represent the little
holes that are in it. Just click and drag and
hold shift like that. And we can create a couple
of circles around here, kind of spread them out a
little bit different sizes. Like I said, there's
nothing perfect here. Just create whatever you would like to represent
your piece of cheese. This middle one, I'm gonna
make it a little bigger. I'm going back to
the selection tool. We're going to find this
double-ended arrow, pull it out a little
bit while holding Shift and Option or Alt. And then I'm just
going to spread this around a little more evenly. So I feel like they are
all across the cheese without being too far apart or too close to each
other kind of thing. There we go. So we have our cheese
drawn at this point. We have the outlines. What I want now is the color. So I'm gonna click and drag to select all of these outlines, press Command or
Control C to copy. You can go down to Edit or up to Edit and do copy
paste, paste in front. All right here, but I'm
just going to grab that with the shortcut key
Control or Command C. Then I'm gonna go ahead and lock the outlines layer for now. I don't want to
accidentally mess with it. Go down to the color layer, make sure you have it selected. And then we're going
to go up to Edit, Paste in Place that shift
Command V or shift control V. Now we've just pasted the same exact outlines onto
our color layer. So what we can do
with that is if we select the outer outline, if you will, this outer shape, we can actually flip it like
we did before to make it a fill of the inside of
where the outline is. And then what we can do is grab that eyedropper tool and go over and snag this yellow color. That's gonna be the first color of our cheese and
it's underneath the outlines because
the outline layer is above the color layer. Now we also have all these
little circles in here. I could click and drag just
to select all the circles. Now I also selected this color. I can hold Shift to unselect that and are de-select the hat. And then we have
just these circles. I could flip their color to fill their stroke
to a fill again. So now we have the
insides selected. And then I can select the orange color that I've
picked out just by using that I key for the eyedropper tool and then selecting this
orange right here. So as you can see, we're
well on our way already. So now we have these
orange inner parts and this yellow cheesy part. From there. We're gonna be adding
shadows and not really highlights on this
because I don't want it to look like a plastic
piece of cheese. So we're just going to
add some shadows in here. I'm gonna select all
of the color and I'm not selecting the outlines because we locked
the outline layer. So you've got to make sure
that's locked so you're not accidentally
selecting everything. I just want every piece
of the color here. Hit Command or Control
C to copy that. Then I'm going to lock
that color layer, go up to shadows and highlights
and do the same thing, paste in place,
that's going to place it right where it was before. So now I have a duplicate of all the color and we're going to create shadows and
highlights out of this. So the first one that we're
gonna do is basically all of these little circles
are gonna have a little interior shadow to
add a little bit of depth. So to do that, pressing Z
and clicking and dragging, I'm going to zoom
in a little bit, press V for that shortcut key for that direct selection tool. Now if I move this
circle around, it kind of looks like there's
only that one circle, but it's because we also have
this larger color block. So underneath that is
the rest of the color. This, the yellow here is kind of hiding the rest of
this color layer. That's okay. We're just dealing with these
shadows and highlights. We just want to create a few shadows out of these colors and then
it'll all come together. So don't worry about not seeing that underneath
color layer. But anyway, what we're gonna
do with this circle is actually hold Option or Alt. And you're gonna get this
double arrow or double cursor. And you're gonna be able
to duplicate this circle. If we bring it down, we can't see it very well. So what I might do
is actually just adjust that color a
little bit like that. So now I can actually
see it That's just by double-clicking this fill
and then changing the color. Now I can see where it's
at and I can move this down to where we create
this moon shape right here. Now, I want that shape
and I don't have it yet. So what I need to do is select this purple layer, hold Shift, select this background, and then Shift M for the
shape builder tool. And now what we can do with the overlap between
these two is I can actually just click on this moon-shaped and that
creates that shape. If we go back to
my selection tool, you'll notice now I can
just delete this one. And I've got two pieces here
now where I could delete this piece and then have
this selection right there. So that works out perfectly
and we can change that to our darker color just by pressing the I for
the eyedropper tool, snagging this darker orange or whatever color
you'd like to make it. And then you'll see this
come together here soon after we remove this full
color layer right here. And if I just show you
that really quick, see how we're gonna
get those shadows. That's just me deleting out the yellow color out of our
shadows and highlights. So then we can see
down to this color. But anyway, what we need
to do is create these little moon-shaped for
each one of these. If we zoom in, we'll do
the same thing this time. I'm not going to
change the color. I did that for you guys. What I'm gonna do is just
click and drag a little bit, kinda see where it hits. That looks pretty good. I can hold Shift, select both of these. Shift M for the
shape builder tool, just click on this
shape and then delete out the
rest of the stuff. So we just click on
this top circle, the bottom circle, and now
we have that piece there. I didn't might be going a
little fast for you guys. So I'm gonna go ahead and
just walk through it again. Click on this circle, we're on our shadows
and highlights, hold Option or Alt. Duplicate it down a little bit. We're going to move
it a little bit too hard to see, but
when you let go, you'll see the outline Shift click to select both
of these pieces. We selected one, I helped
shift selected the other, Shift M for the
shape builder tool. And then just click on the piece right here. And
it's going to create that. It's going to split
that underneath shape. So we go back to that selection
tool and we can start to delete out everything
on top and to the side. And we have this shape here. Pretty easy stuff,
hold Option or Alt. Click that down. We can
use our arrow keys even to shift or nudge this into
place just like that. Select both Shift M, Click on that shape and then we can delete these
out pretty easy. In fact, there might even be, I'm clicking on it, but there might even
be an easier way. Let's go ahead and
duplicate this down. We've got this held here. We're going to shift
click there, Shift M, and I'm going to hold
option to actually subtract everything
but this layer. And now we just saved
a couple of steps. So you see you guys,
even as you're working, as I work, there's
more efficient ways that I find as I work. And sometimes that's just the way it is while
we're doing it tutorial, we find a more efficient way. Select both of those
hold Option or Alt just dragged through these to
everything that's not the moon. And it's gonna go ahead
and delete them for us. So that actually helps us a lot, makes it real quick
hold Option or Alt, click and drag, bump it, nudge it to the spot
where you want it to have that little sliver of a moon shape hold Shift
select both Shift M, hold Option or Alt drag through and we
deleted those pieces. Right on. Now what we can do
is click on each of these and I'm holding shift so that everything gets selected. And I'm going to
just make sure it's that same shadow color. There we go. So we've got little shadows
for each one of these. Let's create a shadow across
the piece of cheese itself, across that back, yellow, I guess you would call it
across the L of the chiefs. I don't know why I'm
saying. Alright, so I'm gonna go to the pen tool. P is the shortcut key. And tools right here, we
can click, make a point. It's going to be inside of
this edge a little bit, maybe right in here. And then down here
and click again. But we're going to
click and drag, click, hold and drag, drag in the direction
that that line was going. We're gonna need to
drag pretty far. In fact, to get the
angle that we want, we might need to zoom out
a little bit for this. So what we want is for it to come down and across
our piece of cheese. I can hold Option or Alt to edit this handle right here
and move this back in. So now we've got this
swoop across our cheese. I'm gonna go click down and around to just reconnect
this point right there. Just like that. Now you can kinda see
how we've created this shadowy right
side of the yellow. Let's go ahead and actually
get that shape out of this. I'm gonna click on the
background cheese color, hold Shift, click on this new
shadowy layer we created. And then of course Shift plus M is that shape builder tool. Here we go. We can do everything
we've done before. We can just hold Option, subtract this shape, subtract
this shape just like that. Now we have everything that was overlapping right
here as a shadow. Let's go ahead and select
the color we had as the shadow for the
top layer of cheese. Now here's an interesting
little dilemma, and this is fine. What we need to do
is have this shadow actually underneath these
colors of the holes, but over top of the
cheese color itself. Well, this color,
the main color of the hole is actually
on the color layer. So there's no way I can have this layer which is
completely on top of the color layer to be underneath anything
on the color layer. So what I need to do
is grab this shape and we're going to
cut it out of here. We're cutting it,
we're removing it and copying it now for whatever reason we had a
duplicate shape underneath here, we can delete that as well. So these are just extra things that were on the
shadows and highlights. So make sure all you have
are the whole shadows. And then with that shadowy
layer over here copied, I'm gonna go over
to my color layer. We can lock our shadows and highlights, unlocked the color. We actually want this on
top of the cheese color, but below all the holes. So somewhere in
here we're going to paste it in place, Edit, Paste in Place, and just
make sure to see it, put it on top of everything. So we're going to drag it
underneath all the holes. And you'll see now that
brings back the color of the holes on top
of this shadow. Then we can adjust
the properties of the shadow from an
opacity standpoint, maybe down to like 60, just to have it be not
quite as saturated, just pull it back a little
bit so that shadow is not too harsh, if you will. I think that the outlines of these holes is
a little thick. I don't mind this 15
outline out here, but we might reduce the
outline of the holes. If we go back to our layers, we can lock what we
don't want to edit. So we'd locked the color, locked the shadows, unlock
the outlines. And I'm going to go ahead
and click and drag because we should only be selecting the outline since
everything else is locked. Hold Shift to deselect
this outer outline. Then with these inside pieces, I'm not sure what
point we should go to, maybe something like ten. So we've got 10
instead of 15 points. So I think that these,
since they're smaller, since their interior pieces, they should be a
little bit smaller than the outer outline. Last couple of things we'll do. We're going to add another layer I didn't talk about before. Let's lock the outlines. It hit the plus
button for the layer. This one's going to be
the background, right? So when you're
finishing something, if you want a background, It's nice to have just
a background layer. I'm going to create a rectangle the size of our art
board just by clicking and dragging from top to bottom, we still have that outlines. What we actually
want to do is press the eyedropper key and just
snag this color right here. You could switch the
outline to a fill and then change the field or
whatever color you want. We've got that and
then I think we'll add a little shadow of the entire piece just outside the edge of this
piece of cheese. So to do that, I think I
might go to the color layer, so it's locked the background
go into the color layer. And I'm going to grab this
background color shape. And I'm going to press
Command or Control C. On that. We could create another
layer underneath here, a lot more layers than
I thought we would. If we just call this the cheese shadow lock, the color layer. We're going to paste
this in place right on top of everything
and just shift it a little bit down
and to the right. We can use our
arrow keys to kind of bump that into place. Then from there we'll
go to Properties, change that fill to just a black and we can
drop the opacity, maybe a twenty-five percent
or something like that. And even, even less than
that if you wanted to, something like 15%
might even be better. Now we have a little shadow
of our cheese itself. Now if you want to select all of this and move it
around and rotate it, you'll want to
unlock these layers. I'm going to keep the background lock so we don't mess with that. My unlock all of these
and just rotate this, everything just
ever so slightly. Kind of give it a little
bit of character, lock these layers back up. And we created a cheese slice.
5. Flat Design Potted Plants: Here we are. I have a new document open. This document is 1920 by 1080. You can go to File
New and just create a new document if you want to
follow along 1920 by 1080, that's in pixels or points
or whatever you so desire. I have a little bit of
a background on this. It's just like a sort of a tan, very light tan color, but that doesn't
matter too much. Let's get started. First things first,
let's make a square. We're going to make
the pot first, and that's gonna be with
the rectangle tool. The shortcut key for that is m. So I'm just gonna make a
little square out here. It doesn't have to
be a perfect square, just this is gonna be
the bottom of the pot. And we're gonna make
it right about there, right about that size. Just guesstimating. And we want a color for this. I like to use the color, the actual color panel. You can go up to Window
down the color, that's F6. It's going to pop out here. I'm going to dock it
over here in my toolbar. And then it's this guy,
we're not that guy, that guy, that guy right
there, the color window. And so I like to
double-click on this and then I can choose
any sort of color. And I think that's sort
of terracotta color will work well for these. I actually have colors
already prepared. What I would do is once
you pick your color, go ahead and open
the swatches panel that's in Window
down to swatches. And once you have that open, click this New Swatch button. And when you do that
checkmark global swatch, that's going to create
a swatch that you can change later
and it'll change all the colors in your
design that use that swatch, which is very nice for working backwards later when
you want to change colors. So I have these
already picked out. I have five of them created. I'll go ahead and show you the color numbers
every time I go into this and that doesn't show
you what it shows you, the RGB 237121107. But if you're looking
for a hex code, we can go back over to
this little color palette. Double-click on that guy. And we have EDI 976 B. That is the hex code for this
little terracotta color. We're going to use this. We got this square created. I'm actually going
to duplicate it by holding Option or Alt, clicking and dragging and
holding Shift, dragging up. Notice all those pink
lines, I'm gonna let go. There's a duplication of it. Those pink lines are smart guides are gonna be very handy. Go up to View, down
to Smart Guides, command U or control. Use the shortcut for that. That's a lot of stuff. Alright, we got some of
that out of the way. Now let's really
create this thing. I'm gonna zoom in a
little bit, That's Command Plus or Control plus. And we're going to
scale this rectangle down because remember this is gonna be the top
of our little pot. Will scale him down to
somewhere right in there. And then I'm going to
hold Option or Alt. And just on the double-ended
horizontal arrows here, I'm gonna click and drag that
out a little bit because there's a little bit of a lip to the top of these type of pots. Okay, cool. We're creating one of those Mario pipes so far. I'm gonna grab
this bottom corner here with the direct
selection tool. The shortcut key for that is a, once I have that grabbed, I'm going to hold Shift
and hit my left arrow key just maybe one time
over to get some of that little tapering off
of the pot at the bottom. I'm gonna do the same
thing with this right one. Just grab that point, shift right arrow key to
bring those into each other. This is cool. I think this part
is a little tall, so I'm going to remain on
my Direct Selection tool. Grab both the bottom points just by clicking and dragging over both the bottom points. And how about we shift, click up with the arrow key. One-click. That looks a lot better to me. Let's round some corners. I'm going to click on my entire shape with the
direct selection tool. You could also click with the regular selection
tool if you wanted to. I'm going to find my
Transform window up and window down to transform, that's going to pop out. And what that gives me is some
corner options down here. As long as you
have this still is a perfect square or rectangle
with all 90 degree angles. You're gonna get this
little corner panel. So for this corner radius, I'm going to do five points. And because this is linked, they're all going to
change at the same time, which works for me. So we just round it
all of those corners. You can also click and
drag on these little dots, which we'll do that at
the bottom of this pot. At the base of this pot down here, I'm gonna
click and drag, grab those two points
again and kind of pull those little dots in just a touch just to round off those
bottom two corners. Now if you're in
CS6, go checkout my rounding corners
in CS6 tutorial, and you'll be able to round
those bottom two corners in the same way as
those who are updated. We have our little
little pot thing, but I need a separation between
the top and the bottom. We're gonna do that by creating a little bit of a shadow under the lip of this top of this pot. To do that, we're gonna go
back to the rectangle tool. Remember that's M for
the shortcut key. I'm going to create a rectangle. And it's just gonna be
sort of haphazardly across this guy, but then I'm gonna pull
him up so he locks into the bottom of the
lip of the pot here. And once I do that, I'm gonna zoom in
a little bit more. Switch to my selection tool. Grab the bottom of this with a double-ended vertical arrows and drag that up a little bit. Maybe into here. I don't want this shadow to be. I'm too tall. Just a little bit
underneath the lip of this. That looks good. Now I'm gonna click and drag, grab both this rectangle
and the bottom rectangle. See how they're both selected. Switch over to my
Shape Builder tool, that's Shift M is
the shortcut key. And then I'm gonna hold Alt
on a PC or Option on a Mac. And that switches that arrow to a minus instead of a plus. And if I just click and drag
through these extra bits, they're gonna get
rid of them for me. There we go. Now we have a shape right
over the top of this pot. And what we need to
do with that guy is just change his color. So I'm gonna switch back
to the selection tool. Make sure I have just
this piece selected. Go back to my swatches, which I'm not sure
which one that is. There we go. I'm gonna
select my darker color here. I'm going to sort of darker tan. And that color is 1 ninth
311073 on the RGB scale and on the hex code
scaled C16, E4, nine. You can input that
and you'll get the same color if you
want the same color. All right, so we've had a
little shadow, Let's zoom out. There's our pot. I mean, it's looking
pretty good so far. Last thing I'm gonna do is
add an entire shadow on the right side of
this as if there's a light source from the left
coming down to the right, That's super easy these days. They used to not
know this trick, but grab the Rectangle Tool, create a rectangle and
make sure that it cuts or stops or locks in at the
halfway point of your shape. Smart guides help you out here. Am I let go? There's
a rectangle. Cool doesn't matter
what color it is. Switch back to my selection
tool, grab everything, go back to the shape
builder tool that's Shift M. And now it sees everything
which is really nice. I just want to get rid
of this piece here. I'm going to hold Option
or Alt for the minus and slice right through
that and it's gone. There we go. We have a
shadow on the right side. I'm gonna click on it, change
its fill to a black color, then bring its opacity down
to something like 10%. We just have a
little bit of a hint of a shadow on that side. Sweet, I'm gonna
grab all of this. Right-click, group it together, and now we have a pot. While we're at it,
I'm gonna show you quickly how to create
another style of pot. We're going to grab this, go to the Ellipse tool that's
L for the shortcut key. From here I'm going to hold
Shift and Option or Shift and Alt on a PC to kind of
create it from the center out. I wanted to create it
about the same height as this guy and actually
we could lock it in. Well, I don't want to lock it. I'm going to create it
a little bit further, a little bit taller
than part on the left. Let go. Is a shape there. Switch
to the selection tool, make sure it's selected the I key for the eyedropper tool, and I can just eyedropper
this color. There we go. Now, I'm going to
cut off the top and the bottom by creating
rectangles again. And I'm going to create a
rectangle that lines up with the top of that Terracotta
pot on the left. Just like that. And
I'm going to create a rectangle that lines up
with the bottom of it. Just like that. Now
I'm going to switch to the Selection Tool that is v for the shortcut key,
grab everything. Shift M. That's my
Shape Builder Tool. I'm gonna get rid
of this slice here. So I can just slice
through the top of those shapes and the
bottom of these shapes. Here's another style of pot. Now I think that I
cut a little bit too much off the
bottom of this guy. I think the top should
be a lot more open. So I'm going to undo with
Command or Control Z. I'm just going to move this
rectangle down a little bit and we're gonna see how
much it cuts off there. I think that's better. I think it should
taper a little bit. So we're gonna do
the same thing. Just select everything, go
to the Shape Builder tool and then hold Option or
Alt and drag through this. And that looks a little
bit better now we can scale this guy down
some he didn't have to be so tall and
then we can drag him down to match the
bottom of this pot. And then what I think
you could do is add a little bit of
decoration to this guy. So I'm gonna grab
my rectangle tool, just create a rectangle
through here. On the top third of this, could bring him
down just a touch. Then what we'll do
with this guys, we can change his color. I like this sort of
whitish tan color. The hex code for that
guy is F9, easier, D7. Okay, so we can
grab both of these, Shift M for the shape
builder tool and then slice off these two side
pieces by holding Option or Alt and
dragging through them. So here's a different
style of pot. We can once again M
for the Shape tool, drag through this and
create the shadow. If we just select everything, Shift M for the
shape builder tool hold Option or Alt slice
through that right side. We've got a shape for
the right side of this. Once again, just
change him to black. And 10%, there is our sort of rounded
version of this pot. So we can grab this. Group them together. That's also Command
or Control G. There we go. We have two styles of pots. Little bonus here. Now, we're going to
create the leaves. Let's zoom out just a touch that's Command or Control minus come over here and
we're going to create two circles with the rectangle, not the rectangle tool,
with the ellipse tool, that's L for the shortcut key, I'm going to create a circle. I like creating them
from the center out. So I hold Shift and Alt or Shift and Option created
from the center out. It doesn't matter how big. We're just going to
create two of these guys. So switch back to the shape
or the selection tool. Grab this guy, hold
Option or Alt, and we're gonna
duplicate him out. And look at this carefully. The middle where
these two cross, it's like a Venn
diagram where they cross creates a leaf shape. So create the shape
that you want, maybe something in here. Let go and now
grab both of these with the selection tool and see how we have that
shape in the middle. Well, you guessed it. We're going to use the
shape builder tool that's Shift M hold Option or Alt, slice off these two sides
and we have a leaf, so easy. Now this leaf, we want him
to be a certain color. I have a swatch up here, just a light green. We have two leaves. I'm
gonna delete this one. Sometimes it'll
duplicate that for whatever reason we'll create two anyway, that doesn't matter. I created this
little green color. If you want the
same green color, that's going to be 87 B27, too. Cool. Okay, we need to
create a shadow on the right side of this
with maybe a darker green. Once again, the
shape tool up here, rectangle tool M is
the shortcut key. Grab that, make it so it's just over the
halfway point, boom. And then V for the shortcut
key, grab everything. Hey, do you think we should use the shape builder tool Shift, M, hold Option or Alt? I loved the shape builder tool. Just slice through
that right side. Now you have a shape that is
the size of half of this. So we're gonna change his color. I've got a swatch for
that and look at that. There we go. By the way, this
color, 50 to 6045. There you go, You guys, that's all the colors we're using. Now I have this leaf,
I'm going to group them together so he's easy
to move around group. And we can just
bring him over here. And more than likely
he's on top of our pot. Well, since we grouped this pot together, we just click on it, right-click go to
Arrange, Bring to Front. That's also shift
command right bracket or Shift Control right bracket. And we're starting to
build this little leaf. We can, with the
double ended arrows, we can always grab the
top and bottom of this. I'd like to hold Shift to
keep it in proportion. But you can also,
I'll show you in a second where you could
skew it if you wanted. But we have this guy so we can
duplicate him to the left. Maybe duplicate it, or maybe just rotate
him a little bit. You could bring him down some
we could scale him down, some hold shift when
you're scaling. And then we could do
the same thing over to the right and just
kind of make this pot, this plant, however you want
him to look just like that. There you go. You can or you can group these guys with command or control G,
they're grouped together. This guy's grouped
together. You could group the whole plant together, Command or Control G with
everything selected. Now it's one big group. You can center it
up with your eyes. That's fine. We could, we could
take this group here. Well, we'll just so if you
double-click into a group, you're in the
isolated portion of that group so you can work on
the elements inside of it. I could grab this group, because now we have
these two pieces inside of the whole plant group. I can grab this guy Command
or Control C to copy. Double-click outside of it and you'll go back to
your normal level. You're not in isolation
mode anymore. You can command or
control V to paste. And now we have this little
plant again and we could always just bring him down
instead of this guy here. He's on top. So we'll just grab the pot, right-click, arrange,
bring to front. And now we have two
different styles of plants and I can just bump
him over with the arrow keys to position him Two different
styles of plants in well, two different styles
of potted plants. Same plant. Cool, wow, we did
it. Lots of talking. Oh, I gotta go, but that's okay. I'm gonna do one more thing
for you guys and that is, I'm gonna grab this guy,
bring him over here. That's a duplication with
the Option or Alt key. I'm going to ungroup him, That's Shift Command G or
Shift Control G. And then we're going to, we're going to bring
this group over here. I just want one of these leaves, so I'm gonna double-click, find this leaf probably Command
C for copy or control C. Then I can just
delete this group. I don't care about him anymore. I'm going to command
or control V to paste. Now I have this leaf. Watch what happens when
I don't hold Shift, it actually squashes
the leaf down, makes them a little bit rounder. If I had something like this, I could make a little
baby plant over here. Let's create another shape for the stem of this
little baby plant. And he's just going
to poke out of here. That might be a
little too thick, That's okay.
Something like that. That's what the rectangle tool again, that's
shortcut key m. I want him to actually
be the lighter color. So I'm going to use the I for the eyedropper tool and grab
the lighter color green. I'm going to bring
this pot to the front. Right-click arrange,
bring to front. Now that's behind there. And I'm just going to
drag this leaf on top, which he's not on top. So we need to bring him
to the front as well, a range bring to front. Now I can rotate
him to the side. If I hold Shift, it'll be 45 degrees and I can just kind
of position him on there. I think the stems a
little too thick, so we're gonna zoom in here. We can grab this rectangle, hold Option or Alt, and you can scale
out from the center. Remember that? And I'm just going
to make his stem a little bit skinnier. Maybe that's too skinny. Maybe we'll just make that a little bit thicker,
something like that. Then we can bring
these leaves and just duplicate them with
Option or Alt. And we could rotate them, we could flip them
actually, then rotate them. So the shadows are
still on the bottoms of the leaves and we can create
two little leaves on here. These leaves might be a
little too big for that, but in their little
too lemon looking, so we can always skew them back a little bit so
they're a little bit more leaf shape that's holding option and skewing from the horizontal
section of that. And then we can bump that
over just to make sure he's over the top of this stem. If you want to, you
can zoom in and just make sure that lines
up with the side there and covers up anything
we can zoom way in on this guy and make
sure that sort of lines up there with the
stem. Then we can zoom out. There we go. We have a little baby plant over there. That's
a little bonus. Thank you guys for
joining me for this lovely tutorial
on potted plants.
6. Flat Design Flowers: I'm going to show
you a new technique that Illustrator has implemented in which you can create flower shapes really
quick and easy. This is a 1920 by 1080 pixel
background or document. I have a layer open, that's the background layer
and all it has on it is a rectangle shape as
my background color, we're gonna be working on
the layer above that as I've locked my background so I don't accidentally mess with it. So to start, we're
going to create an ellipse out here or a circle. I'm going to change the
fill color to a red. Something down in here works. And then we're just going
to create a circle. I'm holding Shift to make
it a perfect circle. Now once I have that made, what I'm gonna do is press it for the direct
selection tool, that's the white arrow key
up here in your toolbar. Click and drag to grab that bottom point
and I'm going to pull it down a little bit. So this is my pedal shape. Now once I have
that petal shape, I'm going to switch
back to the regular selection tool
shortcut key is v0. I'm going to scale it down
by grabbing the corner here, holding Shift and Option or Alt. And we'll scale that
down a little bit to maybe this size right here. Once I have that set, I'm gonna go up to
object down to repeat. This is a new feature in
Illustrator radial repeat. And that's going to
allow me to repeat this object around
and keep it editable. I can do a couple
of things here. I can expand the distance from the center just by clicking
this point on the circle. I can also expand or decrease the number of
instances of that object. So like of that pedal leaf, It's not a leaf, It's a petal. So I'm gonna pull this down, so that closes in right there. And I think this will
be our flower shape. What I'm gonna do now is
actually click on this again, go up to Edit, down to Copy, and then Edit paste in front. Now I have a duplicate
right on top of this guy. See, I've got two of them. So I'm gonna select
the one on top only and I'm going
to edit its shape. So if I double-click in here, I get to this petal and
I can go over here, change the color of it. And when I change
the color of this, actually changes the color of every one in the pattern here, the radial repeat, I can
also adjust the size. So as I pull in from the corners and I'm going to hold
Option or Alt to pull in from the center
of that corner and maybe even drag it down. I can adjust the shape
of this and create the interior of my
flower really easily. Once I have that, I can
actually double-click outside of this and this
more of a gray area. It's going to kind
of bring that back. If I click on this
again now I can adjust how close or far from the
center of these things are. I'm going to bring them in a
little bit closer and then double-click on it again to
adjust the size of this. As I'm working on this, I can actually make all sorts
of adjustments and changes. I can rotate this around
just to make sure it's still lines up these other petals. And we're going to do
just that right in there. There we go. We have the inside of our flower and
then I could create another circle out here
holding shift, of course. And this will be the very
center of the flower and we can make it like a dark steel
blue color just like that. And if we grab this and we grab everything here all
at once like that, I can go to my Properties
panel and just center align everything to put that circle right in the center of this. You can then even
add the stem of this flower just by creating
a quick little rectangle, we can change the color to something like a
natural green color. Could even press a key for
the direct selection tool, pull in the corners a
little bit to kind of round them and then
center this up. And a real easy way to create leaf shapes is to grab
that ellipse tool again, credit couple of
circles holding Shift. And then I can just
select this with V for the Selection Tool hold Option
or Alt to duplicate it. And if you look when you
select both of these, center shape is kind
of like a leaf shape, maybe something like there. I've got them both selected. Shift M for the shortcut key for the shape builder tool
hold Option or Alt, and just remove the
edge pieces there. Now it removed it
for both of them. So there's gonna be two
leaves, which is perfect. And I can just rotate
this one, put it here, maybe rotate this one a little bit and put them right there. And then we'll send these two guys to the back just by selecting all
right-clicking, arrange. Send to back that
quickly we have a little flat design
flower if you want to add a shadow to it, we could create a
rectangle that is black. Just build this rectangle
so it covers maybe half of the stem and the
rest of the flower. Select everything, hold shift in that shape builder tool and we can remove
the outside of this. Now one thing to note here, because these are
still editable, they have bounding
boxes like that. So the shape builder tool actually doesn't work with them. So what we need to
do is actually move this to the side,
take these pieces, take these two radial pieces and I'm gonna
duplicate them over by holding Option or Alt that keeps editable versions over here. But then over here what I could do is just select all this, go up to object, down to expand, and that expands the
fill the object. Now I have all these
actual objects, not just the editable radial. Repeat. Now we can bring
this guy back over. Select everything, grab
that shape builder tool on the outside of this
hold Option or Alt to subtract that out. Now we have this black
shape that's kind of the right half of our flower. And we could drop the opacity, but a lot times something like 10% over
in the properties panel. And now you have a little shadow here on the right
side of your flower. That's a really quick
and easy way to create a flower here in
Adobe Illustrator.
7. Flat Design Castle: Lo and behold, this is
our castle right here. I'm going to keep this
on the screen because I don't really feel
like memorizing every little piece that I made. And we're gonna start the
castle right over here. Let's build out the basic
shape of everything. First, I'm going to use
that rectangle tool. It's over here. Pretty easy. Shortcut key is M. And I'm going to use
the basic swatches. I'm going to open
up my swatch panel up here, Window drop-down, down to swatches that'll open up wherever it is
for whoever you are, whatever system you're on, however updated you are. Okay. And I'm gonna pick three different grays
I'm going to use. The lightest is gonna be the front and the darkest
will be the back. So we'll start here for maybe this main
piece right there. I do have the smart
guides setup, but you don't
necessarily need them. Just make your own size
rectangle for the front. Eventually, this smart guides will help you line things up. You can go to View down to
Smart Guides to turn those on. And those are gonna be
able to pink lines. You see lining everything
up just like that. We've got the base wall belt. Let's go ahead and build
like a secondary tower. It'd be about this
height right here, kind of arbitrary
width like that. Then the one thing I want to
make sure of here is that these two are aligned right
to the bottom together. So I'm going to select
them both open up my Alignment panel
just like that. And we're going to use this guy here that's
Vertical Align Bottom. That just makes sure that that bottom is exactly in place. We don't want any spaces here. You can zoom in and
out with Command or Control plus or minus, just to make sure
there's no gaps in-between these two shapes. And once you've done that, I'm gonna leave this guy
here because we'll just duplicate him over later. Let's build out this, maybe this side here
in this middle one. So I'm just going to duplicate
this by holding Option or Alt on a PC and I'm going to drag
it over to the middle, should be able to intersect. It's not working, so we're just going to drop it in there. I'm gonna hold shift
and select both of these two pieces and then
click on my main wall again, go back to that alignment panel and horizontal align center. That's going to center up
this piece in the back. We're gonna make him bigger just by grabbing those double arrows on the top and
dragging him upwards. And then I'm going to
grab the double arrows on the side while simultaneously holding Alt or Option to
drag that out like this. Maybe something right
in here, looks good. Now you see this next pillar
kind of goes over the side. This little, I don't know, tall point here, wherever you call that,
that little block. So I'm going to duplicate
this guy over holding Alt or Option and Shift
to keep it in line. Remember, we want all this
to line up on the bottom. Let's make him just a
little bit shorter, something like this and here and then I'm going to pull
him back a little bit until he's somewhere
overlapping this guy here. Now it's hard to see everything, so we need some color separator. So let's make this a
little bit darker. We're gonna go back up to that, fill that little swatch will actually make
this one the darkest. So maybe over there, just a couple of spaces away. And then same thing with this
guy maybe right in here. So we got light, medium, dark, just like that. Now these two guys
there in front of our wall in the back
don't want that, so I'm gonna grab them both. Right-click, arrange,
send to back. Now we've got them
all in the back. Let's go ahead and make
our little blocks that go on the top of these towers. So I'm just going to, I mean, I like duplicating rectangles
if I already have made. So I'm just going to
duplicate this rectangle like that holding Alt or Option. And then I'm going
to make it into a smaller little block
just like this, like that. Then we need it to line up right there and line
up right there. So basically the smart guides
are going to help you, but in order to make sure these two are lined up perfectly, I'm going to make sure
I select them both. Click on my big wall and then of course aligned to the
left, just like that. Now it's not a big deal if
it overlaps a little bit. In fact, that'll guarantee
that you don't have any gaps. You might consider doing
that if you want to. The next thing we're gonna do is just duplicate this over. I'm hold Alt or Option and
Shift and kind of give myself whatever spacing I
sort of want, just like that. Now what we're gonna
do is duplicate again, going up to object,
down to Transform. Actually it's called
transform again, that's Command or Control
D as a shortcut key. And when I click that, it just does that last
transformation again, which was a duplication
that we had done. I can hit Command
or Control D and just duplicate that
all the way across. I just keep pressing D. I think I'll probably
stop it with that piece. And what I'll do now
is bring this piece over until it intersects
with the side there. I'm gonna make sure that it's completely on
the right side there. Remember, just select them both and use that
alignment tool. And then I'm going to select all of these pieces right
here, just like that. Open up that
alignment panel again Window Align if you
don't already have it. I need to show more options. So you might need to click
this hamburger menu, but once you do there, should see distribute objects. You may already see it anyway. Got to make sure it's aligned to selection M. I distribute horizontally and that's going to distribute all these guys evenly between the first
and the last shape. Perfect. I like it. All right, Let's grab one
and bring him up here. Same thing I'm
going to intersect. And I want him to kind of
bump down a little bit, shift click and
then click again. We're aligning to
that key object and aligned to the left.
Same thing here. I'm going to duplicate
him over, grab them, click aligned to the right, and then we need
one in the middle. I can just drag him over. That little smart guide
helped me intersect it. But if you don't, you can do the same
strategy here again, select them all, go to
your alignment options. You might need to show
the advanced ones align mixtures to selection that selection and horizontal
distribute just like that. Now that we have
this guy is set up, I'm gonna go ahead and
grab this entire piece, the blocks on top and the tower. I'm gonna hold Option or Alt and bring it over here to this side, just like that, it
intersected perfectly. So now we've got that
guy up here at the top. I'm going to grab these blocks, duplicate them on their own, and bring them up
here on this tower. And I'm just going
to let him go. There's a little gap here. That's the thing we need to fix. So click on it, right-click on this guy, then select him again. So we've got both these selected
key object, left align. All right, I might make
these a little bit smaller. Let's pretend like they're in
the distance a little bit. The other thing we need to
do is make sure they overlap some maybe two arrow
keys down on that. And we're going to just select them all and
bring them in this way. I want four up here
with a little gap. So I'm gonna bring
this guy over, duplicating alter option,
make sure they're lined up. Remember just selecting both. We've done this a million
times, align them to the right. I just want to make sure
those line up perfectly. Those might be a
little bit tall, so I'm gonna drag them
down a little bit more or just click them
down by selecting them using the arrow keys. And then last but not least, just grab them again. Use the eyedropper key
that's I as a shortcut. And just select that color. Now you've got that
tower in the background. Easy-peasy. All right, grabbing this
and we're duplicating this whole piece over
to the other side. Just so actually
before we do that, I'm going to undo that Command
or Control Z. I actually want it to come over to about
the center of this block. So I'm gonna grab this
whole piece again. And I'm going to
just pull everything over and scale it to
the center of that. Those smart guides
helped me line that up. Now that I have that, I'm going to duplicate
it over just like this. Alright? And of course it's on top, so make sure you
grab that again. Right-click, arrange,
send to back. We're getting the
basic shape down. We're just about
there. It looks like I totally screwed that up. Wow, we got ahead of ourselves so you don't need these pieces. Just go unless you want them. You actually totally could. Let's build it with them
and see how it looks. See it. We did it up here. So let's go ahead and maybe
grab these big blocks again, because even though this
isn't the distance, we're gonna pretend
like it's like the biggest block and actually
reverse these colors. So what we can do
is select this, use the eyedropper key. Sorry guys, I'm
confusing you now. I know, but these towers
are gonna be the darkest. This one is going to be that
middle color and I lost it. So we'll go grab
it just like that. Alright, and then these blocks up here are going to
be the same color. There you go. All right, we're back on track. We got some extra pieces here. We're gonna see how
it looks in the end. We may just get rid of them at the end, but that'll be okay. Same thing as always. Click both of these aligned to that key object and push
that to the, to the left. I'm gonna do the
same thing here. Just push him to the
right, line him up, and then we're gonna
duplicate this. I duplicated at
once and I can do Command or Control D to duplicate it a couple more
times, maybe once more. Then we're gonna
grab all these guys, open up my More Options, Align to Selection good, and just distribute
those so they're perfectly lined up on top there. Okay, so next up, let's do what do you want to do? Let's do, let's do the
the rooftops there, the little pointy rooftops. I'm gonna grab the polygon tool. Click on my Canvas, make sure it's three sides, the radius we'll
figure out later. Hit Okay, there we go. We've got a triangle. I'm going to use a color and let's find out
what this color is. Let's just grab it. Actually know this is
gonna be different. So just an orangey,
orangeish color. I like to double-click this
color swatch, sorry, no, my mouse was all over the place, but I like to double-click
that color swatch. And we're going
to pick something a little bit saturated in there, maybe
something like that. There you go. This guy is just going to
sit right on top here. So first thing I'm
gonna do is make sure he's aligned to the
center of my tower. So I'm gonna grab them both. You know, the drill
horizontal lines center. There we go. It's perfect. All right. Is also going to be
sent to the back. So we're going to
right-click him, arrange send to back, just like that, and
then he needs to be a little bit
bigger in my opinion. So we're just going
to click on him and maybe hold Shift and
Option to make him bigger. I don't want him to go
outside of my tower, but I can just sort of lift him up a little bit like that. That's okay. He's a little point is. So
I'm going to actually bring this top point down
and make that a little bit flatter of a
little rooftop here, here. I'm not really sure
how I'm liking this. So here's what we're
gonna do. We're already going to get rid of these. Got rid of them. I'm actually going to make
him the width of our tower. Just like that. Those smart
guides helped me out there. And then we're going
to place him on the very tippy top here. Just zoom in, make sure he
locks in there just like that. There we go. He's right on top. Now we can just duplicate
this guy over to here. Make sure it's aligned in the center of this
one same thing. Select both, click
one Key Object, Align, Center, and then
get rid of these again. I know I made you
do them before, but it was good. It was a good test. Right? Okay. Next, let's
put this guy on top. I do know it looks okay up here, so we'll go
ahead and do that. We're going to bring them up. We're going to align them to
the center of this piece. You know how to do that now. And I'm just gonna
make him larger by holding shift just like that. And I liked where I
got this one to hit, looks like it hits just
above this corner. So that's what we'll try to do. I'm gonna show you a
little trick here. We're gonna make him actually
bigger than everything. He goes just above
the corner there. Alright, well I got
these two little, too little side pieces
that are, well, how about I just select
everything that I see right here. Just select an OOP,
just deselected, select everything
I see right there. Go to that shape builder
tool that we haven't even used yet, Shift plus m. And then on these little edges, I'm going to zoom in here
so I can see right here, I just need to make
sure it's highlighted. I'm gonna hold Option or Alt. The little minus pops up and I click on that
and it goes away. Same thing with this side
click and it goes away. So now we've cheated
a little bit, but I like the way
that looks better. Where are we at? Maybe we need maybe
we need a door on this guy gonna make the door. Here we go. Next up is the door. Alright, so we're gonna do, we're gonna do a rectangle tool. And let's just put it
right here to start with. And let's make it a darker brown color somewhere down in here. Okay. We're just going to eyeball the size of the door right
here, maybe like that. Next thing we want to do is switch back to the selection
tool shortcut key is V. Drag this down here. We're gonna build
the door down here. We don't need to
build him on top of everything zooming
in so we can see, I actually need to select
the top two points. The direct selection tool, this white arrow shortcut key is a right-click and select
the top two points. Once I do that, I got this
little corner widget things. I'm going to pull them in. This is in CC 2015, maybe 10,017 and later
update if you can't do that, I highly recommend it. Otherwise, I have other
corner widget videos for CS6 or anybody
that doesn't have it. But the corner widgets, awesome, Look, I just
pulled those in. Now we have a door
shape just like that. Let's go ahead and add
maybe the stroke around it. I'm gonna duplicate this out. You should know how to do that.
We're going to flip this. We're going to flip the stroke and the fill just like that. And by clicking the
little sloppy arrow over here, also shift X. Then I want to maybe up
the stroke a little bit. Not sure how much we're
just going to up it to 55. Looks pretty good for the
size that we made this. We might actually do ten. I think we're going to do ten. I'll show you why
here in a second. Next, I want to make this
an even darker brown. So I'm gonna double-click
that swatch or that little stroke swatch,
drag this down. Be a darker brown hit. Okay. There we go. And then I
believe we may get this wrong, but I believe I'm going
to use the Scissors tool that's a C as a shortcut key. And I'm going to
click on this anchor and click on this anchor. Now I believe once again that
I have two separate pieces. I can grab this
one at the bottom and hit delete, and it's gone. Now I have this little
arch around the door. It's like that door
frame and I can bring it back over
the top of this door. And then I can click on
the main part of the door, right-click arrange and just
bring that to the front. Once I bring that to
the front now that reduces that stroke to more
of a five-point strokes. So I liked the five
points stroke. Now half of a hidden
up half of the ten. So that makes, leaves five. That makes sense,
Makes sense to me. All right, next thing we're
going to add a little shadow. Let's do all of our shadows. Let's just look at the castle
before I get carried away, let's do all of our
shadows on the right. We're going to add a
rectangle out here. And not like that, I'm gonna make this
rectangle just pure black. And then I'm gonna make
it bigger than the door and I need it to intersect
in the middle of the door. Now I'm running into a
little problem up here. So here's what I do to fix that. I simply zoom in. Luckily, Smart Guides
pretty much just look at what you can see. So now if I do this, it locks in right there on the middle of the door.
We've just covered it up. Let's grab everything. Shape Builder tool is
perfect tool for this. Over here, Shift M, you know, the drill option, click on
the outside of this guy. And there we go. We've got a little shadow here. The door frame doesn't need
a shadow, it's already dark. This is too dark, so we're gonna make it lighter by dropping the opacity to, I don't know if 10% works. We'll try 10%. Alright, let's make
little door knobs now, these are gonna be the
lightest part of the door. We're gonna use
that ellipse tool. Shortcut key is l.
Make a little circle. Just like that. I did it
from the center out by holding Shift and Alt or option. And let's say we want our little door knobs
be like this big. Now I'm going to grab
the color of the store, a key eyedropper key. Grab the color, and
I'm gonna double-click this and just make it a
little bit lighter like that. Pretty easy. We can probably bring
it on top of our door. It's sometimes
hard to grab that, So just have to zoom in so I can get a better grasp
on that piece. Just like that. What I'm gonna do is
just pick a height, line it up to the center. And I'm going to use
Shift and the left arrow key to bring it
over a little bit. Gonna do the same thing
after duplicating it over, lining up right there, shift right arrow key, bring
it over a little bit. I have a feeling that's too far. So let's go back 1234,
maybe like that. 1234. Just put these where
you want them. Pretty much. There's two door knobs. There's our door. Let's group it together. So select it. All
right-click group. And then we want it to
line up to the bottom. Remember, so first
things first I'm gonna grab both the main
wall and the door. Click on the main wall, and then we're going to
align it to the bottom and align it to the
center, just like that. So we should be good
at doors in there. Perfect. What's next? All right. I'm seeing
something here. You guys. First off, I think there's four different colors
here instead of three. The outside two towers
are a different color. So what we can do is
just grab that like that and let's go ahead and
just work our way back here. So this tower I want to be, Let's see what we did before. This tower was the
second darkest, this was the second lightest. I was totally off as we did this tutorial, but that's okay. All right, So second darkest, Let's make it this right there. Then we'll grab this one. And I for the eyedropper key, make it that right there. And now these two guys, these guys are going to
need to be a little bit darker even so we go to those swatches and maybe
grab this swatch here. There we go, Just like that. Alright, let's add some flags. Let's add some flags on the top. What I did do these flags, I went ahead and probably did a line segment tool and just found the center
here you can start at the very top at
that anchor point, made a little line segment. And just like that, now this line segment needs
a stroke size on it. So I think two
points might work. We're just going to
put in to there. Yeah, that'll do that. We'll do. Next
thing I want to do is this is like a dark brown
and I think that's fine. You can make it just any
dark color you want. But that stroke, I want to
round the caps on that, which basically,
whoops, whoops, whoops. Basically that turns the
ends of them from a square to a nice round look that just adds a
little finishing touch. Now the problem is that we
are kinda on top of this guy. So I'm gonna select both here. And then actually the
first thing I'm gonna do is grab this guy and
send him to the back. He needs to be behind this to look like he's kind
of popping out on top of it. So arrange, send to back. Next, I'm going to
grab both select the triangle and center
it up just like that. And then we just
need to drop him down maybe with the arrow keys until he can't see the
end of him anymore. So just, just like
that right there, he just gonna come out at
the top of this tower. We need, of course,
a little flags. So let's just duplicate
this triangle. Easy-peasy. I'm gonna rotate him holding Shift to rotate by 90 degrees. And this isn't quite
a flag shapes, so we're gonna bring in the
two edges just like that. Hold Option or Alt to bring
in both at the same time. And that's about a flag
shape right there. What color did I choose? Maybe the same
color as the roof. That's fine. Let's go ahead and
resize him so I can just grab the edge here and hold
Shift while I do that, it's going to scale him down. And just kind of pick
a size for your flag. Doesn't have to be
anything perfect. And then I would
just put him I would allow a little bit
to pop out up top, but I would probably send
him to the back as well. Make him go behind that. And there we go. We've got the little
flag. That looks good. I can just grab him and
duplicate him up here. Just like that, but of course
he's a little bit off, so let's go ahead
and bring him over till he lines up
right in the center. He's not doing it,
he's not cooperating. So we're gonna grab
this flag posts, shift, click this guy again and just
align handed the center. Now this flag, you
could bump it over one if you want, just like that. And then we'll grab him. I'm just going to command copy and then Command
or Control C, and then Command or
Control V to paste, just to bring them over here. And we need the line
him up against that. We'll have to zoom in, maybe grab both of these
here, line them up. Did I forget to send that
other one to the back? Will see. You guys send
this guy maybe to the back. Then I would send this flag to the back as well. Like that. There we go. Is he on top? No, That works. Okay. Let's zoom back out. Now we've got little
flags on top. Okay, what's next? We've got windows. Look at these
windows. They look a lot like the door, don't they? Let's make more doors that turn into Windows
rectangle tool, maybe this size, we're just
guessing, just like that. I need to pull in
the top two corners. So a for the direct
selection tool, this tutorial is a lot longer than I expected. That's okay. Okay. Pull these in here
just like that, and then let's make these
that darker door frame color. Maybe that's not
the right color. I can select. It didn't seem like I can get it very easily because
it's underneath there. So what we're gonna do is not
have this be 10% opacity. We're just going to
select a color here. I don't want, I don't really want it to be
all the way black. So let's maybe do some super
dark brown just like that. Okay, now these windows too big, so let's make it a
little bit smaller. Not selecting that
correctly. There we go. I have no idea what's going on. Do we have the Direct
Selection Tool selected here? Whoa, buddy. We have actually what's
going on here if you're running into this issue, go out to the Transform panel. I believe we have an issue
with these not being checked, so we need to scale corners, scale strokes and effects. I would have those checked. Now, what can happen? There we go. Okay,
so the corners weren't scaling, that's
what was happening. We can put these
windows in here. You can choose your size. Looks like I went a little
bit bigger than this, maybe something like
that hold Shift to keep it in proportion. And then I'm gonna go ahead
and duplicate this out. It doesn't really matter
where it lands over here. If I select both right-click and group those together,
this is a little group. I'm going to Shift
click the main wall, click the manual and
we're going to align to the main wall just like that. So bump them now
I know there are exactly in the center
of each other. I can go ahead and get rid
of that group by ungrouping. And now I can grab
these guys and just place them on your
towers around here, make sure they're
aligned to the center. You can just place them
wherever you want. I'm not sure if that's
aligned to the center, so I'm gonna grab that and
make sure it's centered up. Good. I'm putting one on each
of these big towers. I don't know if that's centered. So same thing just there. It wasn't so just select both and center it up with
your alignment panel. And I'm just gonna go ahead
and do that over here. And I'm gonna worry about
trying to eyeball it. It looks like I did
three on this big one. So let's try it. Let's try doing that. We'll do 123. I'm gonna grab them
both or grab them all. Go. And first I'm gonna align
to selection to make sure they're exactly three in a
row, spaced out perfectly. Then I'm going to group them. If I select them all again,
I'm going to group them. And we're gonna select this back object and center on that. There we go. So we've got
the windows all centered. We're looking pretty good. Let's, let's add, let's
add some shadows. And the last thing we'll do
is add the little bricks, little texture and then
the grass shadows next. We probably could have already done this,
but that's okay. We've got, we've got
these triangles. Okay? What I'm gonna do
with these triangles, these two are gonna be easier. We're going to grab the
rectangle tool again, just make sure it's
completely black here. No, not like that. I
don't want that selected. I need the rectangle
tool and then I need my swatch to
be a darker color. Police. Then we're just going
to build this out. So it's exactly in the
center of this triangle. Select a triangle, select the rectangle shape
builder tool, and then just hold Option or Alt to get rid of the
outside of that. Now we have this
triangle right here, and what we can do is
drop that to about 10%. You got a little bit of a
shadow there. That works. All right, same
thing on this side. In fact, what we could do
is just grab this shadow, duplicate it over and let it line up with the
center of this guy. We know those two are the
same. That'll work out. This is an up here we'll
do a little bit different. We're going to bring
him to the front first, arrange bring to front. And then I'm going to
use that rectangle tool. This part will be the same, but I just wanted
to bring them to the front and then
we'll push him back, line them up right
there in the center, grab both, and then click. I don't need to
click on anything. We just do that
shape builder tool. Get rid of the outside. There we go. Go ahead and do my
opacity while we're here. 10% could do 15 or
self you wanted. I'm gonna grab both of
these right-click and group it. And I'm
gonna right-click. And actually I'm going to grab the flag and this
whole shape here, right-click, arrange,
send to back. It goes beneath
everything again. There's the shadows for us. There. We'll go ahead and build
out a shadow for down here. I believe they're the same
note there are different. So we're gonna build a rectangle that is
once again black and it goes just a little bit up
up our main wall like that. We're going to bring this door. This is two pieces. This is one piece. So we're going to bring
the door to the front. Bring to front. We actually don't need to use the shape builder tool here. I can just grab this piece
and lock him in like that. And then run that opacity
again down there. Can just duplicate this piece over like that, make
sure intersects. And then we can grab this
corner and resize it. I'm going to bring
this shadow up a little bit since
this guy is taller. And then we can do the same
thing on this side over here. Just duplicate him over to
this tower, just like that. And then I think I added a
little shadow behind here. So we can just grab
this piece again. I like just using these
rectangles that we already have. What I'm gonna do is just
kind of placed him up here, right-click this main building and we're going to
align them to the left. And then let's zoom
in a little bit and bring him over
to the right side. Like that. Then
what we can do here is select everything
except for this tower. So hold Shift, Shift-click,
Shift-click, Shift-click. That should be this wall. I'm going to bring this
wall to the front, arrange bring to
front. There we go. That just sits that
shadow back there. I think I want to drop
this down a little bit. Maybe something like that and I think that's a little dark. So let's just make
this 1, 5% back there. I just want the
slightest hint of a shadow back there. All right. What does that leave us with? Are we onto the texture guys? Are we almost there? It's texture time and
the little Greenpeace, let's add in the world
Greenpeace here at the bottom. That piece is pretty easy. Rectangle, build him so just sticks out a little
bit on either side. Now we can select that main
wall will center it on that. So we center on
this whole thing. All we really need
here is a color. The other thing I'll do
here is to click on him. And up here in my
Transform panel, if I go to more options, I actually have the corners
right here they can select. So I could do like
a corner radius of five and see what
that looks like. Yeah, I could just
round these corners a little bit and maybe I'll do three just so it's not
as sharp of an angle. And then all I have to
do is click on this guy, double-click, go into the greens and select a green that I like. I like something maybe
in the middle here, maybe a little darker like that. That's a little hot about something like that right there. That'll be good. There you
go. Something like that. Okay. Little aqua, whatever, kind
of like this color better. Well, actually it's
gonna change here. I'll show you how to recolor
everything here at the end. Okay, guys, last but not least, it's pretty obvious
what these are. These are just little,
little rectangles, but what I want to do
is start a new layer. And it looks like I have a color overlay layer that
I've already screwed up. So what I wanna do is just
add a new layer here. I think I've put this
entire castle on my color overlay
layer. That's okay. This will be pretend
like you just started and you probably
only have one layer. And this one layer is going
to be the castle layer. Then this layer is going
to be the texture layer. So I'm gonna go ahead and
lock everything else. I cannot move anything anymore. This texture layer where
I'm going to build these little, little
texture blocks. Once again, these guys are just rectangles, pretty simple. Build out a little block, whatever size you
want, zoom in on him. I think I'm gonna start with just a gray and see what
happens here like this gray. I think what I can do, I'm not sure if there's a
blending opacity that I can do. We'll see if it works. I'm gonna pull in
these corners just to touch just like that. So they're a little
bit softer blocks. Going to bring this over
here on top of this guy. Now, what I did was I
made these always be a little bit lighter than
the shape that they're on. I'm gonna start with something, a color that's lighter
than this wall. To begin, let's go back
to my Properties panel. I'm going to fill it with
something like this. I'm gonna go ahead
and test this out. We're gonna duplicate
this guy onto each wall. Just random spots. I'm going to select them all
and see what happens when we go to that opacity and we change it to something
like a soft light. I think that works out
to where even though it's the same white color at the soft light
helps change that. The brightness of it, depending on the darkness
of the tower that it's on. I can drop the
opacity as well to maybe like 50% or something. Maybe we'll do like 70%. So we can still
see it like that. It's all one color, which makes it a lot easier than the first way I did this. And you use the soft light
by clicking on Opacity, just use the soft light
blending mode and then you can drop the
overall pasty a little bit. And now all you're
doing is just making this texture so we can
duplicate these pieces out. I may even speed
up this section, but I'm just using
Alt or Option to duplicate these different pieces and build them on
top of each other. I like keeping the same
same relative spacing and sort of centering them up. So if you ever offset them, remember the offset like
this where you have two and then you put one in the center and you
would do two more. Kinda keep that in mind as
you're building all these, all these little shapes out. Remember, it's
easier to zoom in. It's easier to zoom
in on this and grab these blocks than it is to grab them by looking
at it like this. We'll just speed up
the rest of this here. While I create the rest of
these blocks on this layer, and I'll see you
on the other end. Okay, So we've placed
these blocks around. I stopped short of doing the rooftops because they're
a little bit different, but place these blocks on, I think they're a
little bit too visible, so I'm gonna drop
that back to 50. Want them to just
be kind of like a little bit there so you get
the sense of the texture. Now, the only
difference here with the roof, the rooftops, the little piers up here, is that these guys should be probably a
little bit smaller. So I'm gonna grab duplicate
some blocks and just make them a little
smaller up here. But nevertheless, we're
going to just do the same, same type of type of
thing up here with these. We're just going to bring
these around like that. Maybe I'll, oops, actually, I should probably
duplicate this one because it should be smaller. Maybe like this right here. Doesn't really matter. I
was doing the same thing. I'm sitting there talking
to myself saying, this should go over here. Maybe just kinda piece it, pieces together like that. Maybe we'll put one
extra one up here. Just like that. Then we can just duplicate
these little segments. I was doing a lot of that where I've just duplicated segments. I'm gonna keep them away from
the middle of the shadow. I don't want them to
get sort of confused or anything Just like
that right there. Now these actually, I wouldn't mind going ahead and shift, selecting them all and dropping those back
even more and opacity, maybe they like
thirty-five percent. There we go You guys, we built the castle, Holy macaroni, That took a way longer than I
expected, but we did it. Last thing I told you
to wait for this. This is how I might color
like re-color something. You notice how this is a
little bit different color. Well, guess what? It's not really, there's
just a layer on top of it. I'm gonna go up to
my layers panel and we're going to
unlock the castle layer. So I've got this
castle layer and this texture layer on top of that, we're
gonna make a new layer. I'm gonna call this
Color Overlay. Color Overlay. This is just gonna be the last little
piece to the puzzle. I'm gonna make a big old
rectangle just like this, over the top of everything. Now this rectangle,
I actually want to select everything underneath
it and the rectangle itself. So we've got everything selected right there with
that big rectangle, the color overlay rectangle
using the shape builder tool, I'm going to hold
Option and just minus out, subtract everything. That's not the castle. Now, we're going to hide the
castle layer or not hide it, but we're going to lock it, lock castle, locked texture. Now we just have this
little color overlay. These flags. I'm gonna make sure we grab
them all just like that. With this all selected. I want to change this code. Let's say I want this
to be a warmer tone. Let's go down here
into the oranges. We're going to select an
orange just l
8. Flat Design Balloons: Here's our cute little balloons. They each have their
own little Smiley faces and their own little colors. We're going to just start a
completely fresh document File, New. We're going to make it 1920 by 1080 because that helps them
make thumbnails out of this. Alright, let's start by
creating a background. So going over to
my rectangle tool, the shortcut key for that is M. I'm just going to
click in the corner of my art board and
make this thing 1920 by 1080 the same
size as my art board. I want to get rid of
this stroke so you could just click this little
slash there to make none. And then that's I click
on my fill to make it the foreground of
what I'm working on. I can double-click on it. And we're gonna go down to
something in the tan region. So a little bit more saturation, something right in
there, hit Okay. And there we go. That's a little
yellow for my liking. So let's pull it
back away from the yellow a little
bit and hit Okay, we got a little bit warmer tone. Now we're going to
go up to layers. I'm going to double-click the name of this
layer, call it BG, create them a new layer and lock the background and makes sure the new
layer is selected. We're going to build everything
on top of the background. That way we don't accidentally move the background around. Woof, That's a lot of rounds. L is your shortcut key
for the ellipse tool, Let's make a perfect
circle holding shift, something like 350 by 350
around, around that size. And then we're going to create the color of our little balloon. Double-click on our fill. Go to our color picker. I think something I want
like an orange, red. Something right in
here might be good, maybe something like that. And then I also want a
stroke around this guy. So I'm gonna
double-click the stroke. I'm gonna make it like a really, really deep purple,
something around here. If you look at this little
b right here in the HSB, I don't even know
what these stand for, but I'm pretty sure
this one's black. I'm looking at the
percentage and I think I want him around 25 or so, somewhere
around there. And then just in this
region hit Okay, and we have a stroke
around our shape. Switch over to my
Properties panel and check out that stroke. I don't remember how wide it
should be, maybe ten points. That looks pretty good. And then I'm going to click
the stroke properties and we're going to align
it to the outside. Now here's where I would've
stopped in the past. But instead of a perfect circle, we're going to warp
him just a little bit. It adds a little bit
of cuteness to this. All right, I'm going to grab
not that ellipse tool again, I'm gonna grab the
direct selection tool. The shortcut key for that is a. I'm gonna click and drag
over that bottom point. And I'm gonna use my arrow keys to just bump him
up a little bit, just to kind of flatten out
the bottom of my balloon. Then I could grab some
of these handles and pull them out just to
kind of warp the shape. If I click on an anchor point, I'll see all the
handles around it. I can grab them and kind of just warp this little guy around. So he's not just
a perfect circle. That's where it starts
to get a little bit more of that illustrated effect. Alright, so we've got this sort of shape here are a little blob. Let's go ahead and create the, I guess I don't even
know what the opening to the balloon here
at the bottom. We're going to do
that by creating a square with the
rectangle tool hold Shift. And then once we
have that square, I believe what we're gonna do is use the pen tool, which is P. And then just click on one of the anchor points
to cut that off. And then I'm gonna go over to the stroke options again and click on the corner around join so that the corners
aren't so sharp. And then I'm gonna rotate him, hold Shift 45 degrees. And that's gonna be that's
gonna be the other way. So we want the point facing up. He's a little large. So what I want to do is
just shrink him down. Of course. Then the other part you
can use the scale tool here to pull in without
holding anything. It goes ahead and sort of keeps in line could
hold Shift if you want to squeeze
in those corners. So it's not maybe the
widest of shapes. Something zooming in and
out might help there. Alright, maybe like that also if your stroke is messing up
when you're scaling things, so you scale that down and the stroke is real tiny now too, all you have to do is go up
to your Transform window, Window drop-down down to transform and make
sure that scale, strokes and effects
is not selected for this because I want
that stroke to stay at ten points
no matter what I do. Back to this, all we have
to do with this guys, just pull that right
up into there. We can zoom in a little, that's Command or
Control plus and minus and kind of
pull them down. I think he's got to
be just a little bit smaller in there, maybe, something like that just so
he's right at the bottom, but make sure he doesn't
overlap too much, so just bump him down so we can't see the top portion
of that triangle. There you go. You've got the bottom
of the balloon that works out pretty well. Alright, so what else
do we have here? Let's go ahead and do
the little Smiley face. I'm gonna go ahead and draw an ellipse L key again and make just a
tiny little circle, something in this size. Then we got to adjust this. I'm going to click
this little flip, flip stroke and fill. Then I'm going to make sure the stroke is selected
and hit None. So now we just have
one little black dot. We can go ahead and make
the Smiley face out here. If I hold Option or Alt, It's gonna click and drag and it's going to
duplicate that. I'm going to zoom
in just a touch. Now, I'm going to
create an ellipse, but I'm going to go ahead and
swap the fill and stroke. So I just have this stroke. I'm going to create a
little ellipse here, hold Shift to keep that in line. And this is gonna be
his little smile. So we basically
made, made a circle. I want to make sure it's
ten points on that stroke. And then what we can do is simply delete out the top point. Grab that direct selection tool, hit the Delete key on the
top point, and there we go. Now, one thing to
finish this off though, you see how it's just a
jagged edge there at the top, we can go over to the
stroke options again. And on the cap, we're gonna do a rounded cap that's going to round off the ends
of our stroke. I think the smile is
a little bit too big, so I'm going to scale
him down just a little. I'm holding Shift and Option or Alt with my selection tool. Always going back to
that selection tool. And we're going to
bring that smile right up in-between those eyes. Somewhere around here. Maybe we'll make those
eyes just a little wider. This part it doesn't, things don't have to be
perfectly centered all the time, especially for an
illustration that adds a little bit of
character to this dude. Also, if you're not
centered on the eyes, it just looks like he's
looking one way or the other. All right, so let's go ahead
and group this guy together. So Command or Control
G to do that. So now it moves as one layer and we can just drag
him on top of our balloon. There he is. He's got a giant head. We can always scale this stuff up and down
if we would like. So we've got a
little Smiley face. We got some eyes and
beady eyes on there. Let's go ahead and work on the highlight and
the shadow here. I'm gonna create another circle. This one I'm going
to fill with white, like a pure white. Not fill, but I'm going to add the stroke as a pure
white groups that ellipse tool create a
circle and go ahead and create it on
top of your guy. Hold Shift there. And we'll take a look at this. I'm gonna make sure he's
also ten points stroke. If it didn't
automatically do that, I'm going to align him
up to the top here. I'm concerned with putting
this highlight up here. And I'm just going
to use my pen tool to add anchor points to this path where I want my highlight to go,
something like that. And then we're gonna
have a shorter one. Somewhere between here. Like real short like that. Now what I can do is zoom
out on this guy and start to delete out the other
anchor points on this circle. And so I can just use my
direct selection tool, shortcut kids a click on other anchor points and
start deleting them. Just like this. Just click and delete
what we don't want here. I don't want this one. Let's see. I've got one. I want I want there to be a
break in-between these two. So I'm gonna pull out
a different tool. It's the scissors tool. Shortcut key is C, and
I'm going to cut it on this anchor point and cut
it on this anchor point. And then I can use
my selection tool, click in-between and delete out that sometimes it leaves
a little extra point. You see how it's got an
extra points selected here. All you have to
do is delete that as well and you're good to go. So now we've got our
little highlight. This guy makes sure that
those caps are rounded. Mine automatically did it, but if yours didn't, make
sure they're around it. And then what you
can do is just grab both of these and you can start to rotate them around to
make them fit in here. And I'm pretty sure
in my other one, I upped the stroke to maybe 15 just to give it
a little bit more. And these guys are a
little close together. It's a feel thing here. Just pull him apart
a little bit, maybe rotate these around
just a touch more. And then I would take the
opacity of both back. I don't remember, maybe
50% or so, just like that. So he's got a little, little, little highlight up there. Let's create a shadow. And to do that, I'm gonna go ahead and
duplicate this entire piece. I'm selecting everything,
holding Option or Alt and dragging it out
here just like that. So this guy, I'm
going to use him to create the shadow and I'm going to delete out
what I don't need. I don't need the
bottom, I don't need the face and I don't
need the highlights. I just need the blobby circle, balloon shape, body thing. Alright, so create another
ellipse this time, lag that. And honestly you don't
have to hold Shift here. Oh, you know what, We're
not gonna do that. Sorry. We're going to use his
body to create a shadow. On his body. Does
that makes sense? All right. So go up to
the selection tool. We've got him right, hold
Option or Alt and create another duplicate and
just bring him out here. I'm going to swap the fill and stroke
just so I can see it. And then if stroke is selected, get rid of that stroke
just like that. Now I can see where my shape is. I'm going to make
him a little bit bigger so it's kind
of scale him up. I'm holding shift on that, maybe a little bit more. What I'm looking at is
the negative space here. So I'm looking at the
space that's leftover of my balloon guy shape here. I'm just kind of scaling
him up to try to find the right sliver
to make a shadow. Once I find that, select both, and then use the shape
builder tool that's Shift M as a shortcut key. And we're going to hold
Option or Alt until that little plus becomes a minus and we're just going
to swipe through here. You can also just click on them. Now I have this piece over here. What I can do with this
piece is do the same thing, swap the fill and
stroke and then click on the Stroke,
get rid of it. We'll click too many times. Just want to get
rid of that stroke. I just want this type
of sliver right there. Bring him over on top of
my balloon over here. We're just going to
line him up, zoom in, just kinda line him up in
here so that he completely covers out to the stroke edge, something like that works. I'm going to click on
him and take him down to maybe twenty-five percent
is where I'm I'd taken. Now we've got a little
highlight and we've got a little shadow on the
side of our friend here. I think I'm going to
take us take his face, facial features down
just a little bit. He's got a nice, nice,
big round heads. So cute. We need the little, little strings string here
that he's connected to. So let's open up our pen
tool shortcut key is P. Make sure that we have
just the stroke selected, and this is always the same Blau we've been using the same
black the whole time. That stroke weight is
gonna be five points, ten points, It's
gonna be ten points. Make sure the stroke options, we got rounded cap selected
and then we're golden. Now I'm just going
to create out from the center of this
little triangle, his, his little string. I'm gonna click and drag in the direction that I want to go. I'm also going to hold shift
a little bit with that. That's going to influence
my curve out here. And I just want like a little, little rounding
maybe to the curves. So something like this. And then maybe something
like that, just like that. And then if it doesn't
look like look at this, it doesn't look the best. Okay, so I'm gonna hit a my direct selection tool
and select this anchor point. I can start to mess
with these handles just to make this a bit
more fluid of a curve, I can also move this anchor
point if I want to just adjust how much these
handles influenced the line. Either way, that looks, that looks a little bit better. So you just want to make
those curves nice and smooth. And it'll, it'll
look pretty good. It's not a scientific
process here. All right. I want to send this
guy to the back obviously. So right-click him,
arrange, send to back. You guys. We've got a balloon. We did it. You made a little balloon. Let's change these colors. All right, so we've
got this balloon. I'm gonna grab him. I'm actually going to
probably Command or Control G is going to group them together. You can also right-click
and go to group. It'll be right there.
That's ungroup. Group will be there. Alright. We're gonna duplicate
him hold Option or Alt, bring them out here. There we go. Got to look at. Now let's just double-click
into them until you get to the inside this
layer group now, and now we can select
each individual piece. We can select his head and
we can change the color of his balloon of this
little bloom guy. What? Let's make this guy green. Just drag this around, find
a green that you like. If you keep it in the same spot, it's going to have some
similar tones to the, all the colors are going to
have a similar feel to them. So I'm just gonna keep
that in the same spot. Just adjust this hit. Okay, and there's a
little green color. If we double-click in there, well, not double-click in there. Let's click out. Alright, I got the group, double-click into him
and then click the head. We can double-click
on that fill. And before you exit this, you can always grab this
little hex code at the bottom. Copy that, and then go
out to this little piece double-click and you can
paste that hex code just to make sure you have
the same color. And then you can always go
into Window down to swatches. You can always add a new swatch. So we're adding that
color as a new swatch. And if we check mark
global and we hit Okay, now it's a global swatch. Now what I could do is click on that button and click
the global swatch. So these are both
a global color. I can double-click on that global swatch at
anytime just like that. And I could change his
color if I wanted to. I can hit Preview to see
how it's going to preview. If you want those
similar muted tones, just keep this RGB
kind of in the middle. So like if it goes
from here to here, keep them, keep them in here, and find your colors
and you'll still have the muted tones that
won't be too saturated, too bright, anything like that. I still want them
to be green though. There we go. We've
got a green balloon. We're going to drag
this guy out and we're going to make him blue. We're going to find a
nice blue that we like. I'm going to copy
his little hex code. Then I'm going to click
on this little triangle. Is there a name to that
part of the balloon? I don't know what
that is, but it's little triangle
DoubleClick is out. Now the thing I did
is you can go back into either of these by
double-clicking into them. Since they're grouped together, you can pull their
little face to the side so it looks
like he's looking left. And we're going to click into
him and he's looking right. Just like that. Then we can just sort of
put them behind each other. I'm going to
right-click this group, arrange send to back. There he is. We can rotate them a little bit, make them so he's like that
same thing with this guy. Make sure he's in the back, arrange send to back. Just like that. And then we can rotate
him just a little bit. So he's kinda he's kind
of going out that way. And then I did tie these strands together so I could
go back into, if I double-click
into this group and use my direct selection tool, that's a, I can grab this point here and
bring it way over. Grab the handle on
accident there. It's usually easier
if you zoom in a little bit so you can grab
these small little points. And so he's going to come over, he's going to come
over just like that. We just click on these
points, grab the handles. I want him to come
out a little bit and then come over there. And then I can double-click and use the selection tool
to go inside of this guy. And we kind of intertwine his little little strings so you can just come
across there like that. Maybe, maybe
something like that. Then the blue the blue feller, he's gonna come, oh, you don't have to
double-click in there. If you use the direct
selection tool, you can actually just click on his little strands so you
don't have to double-click in, just click on the strand with
the direct selection tool. I'm going to pull
him way over here. I think like this. And he's just gonna,
he's gonna sort of loop around these guys here. Maybe something like that. We'll just shrink
that handled down. So I'm just clicking and
dragging the anchor points, shrinking the handles down, just make it look
all nice and flowy. Just like that. There we go.
9. Flat Design Bunny: On the right-hand side you'll
see the Properties panel. We're going to keep that over there because we're going to use it quite often
in this tutorial. But what else I want
to pull up is under Window down to swatches. We'll pull open our
swatches panel, and this one's
already opened here. So I'm actually
going to pop this out with the double arrows. And you can see we have
swatches open here. We're also going to open up underneath Window,
the color panel. And we can drag this color
panel underneath the swatches, as long as it
highlights in blue, it's going to put
it under there. And then if we hover
between the two panels, will get a double ended
arrow that we can use to adjust the height
of our panels will also pull in the alignment
panel because we'll be using that as well
and we will want that to be available
to use anytime. You can also pull out
the transform panel and align that here
in our document. And then what I would do
is actually probably bring the color panel all the
way up below swatches. That way these two color options are closest to each other. I might keep colored guide with that which can nestle in here if we just drop it in on top
of this color dialogue box. So as you can see,
we can quickly create our own workspace. And we can actually go
up to window down to workspace and save
as new workspace, your own version of this. So I might call this the
pixel and brackets workspace and I can hit Okay, and I can always come back
to that workspace that always has the setup that I need for working on my document. There's the hex
codes on the right for each of these colors, what I would do is create
global swatches out of each one of these with
a color selected. I can go to in my swatch panel, this new swatch icon, it's going to pull
up a dialog box. This dialog box, first off, since I'm creating
a digital artwork, I'm going to select RGB, but I'm also going to
check mark global. Once I do that, I would
normally hit okay. But I already have
them made over here. I have these global swatches. The word global
basically means like, I can re-edit these
and change them to any color that I want it
anytime and anywhere. I've used that swatch, It's going to actually
update that color. So let me show you really quick. If I double-click on that, I can change that color here. I can click Preview
and notice how it changes the entire
color of my bunny. Just with that one swatch. That's a pretty powerful way with global swatches
to be able to go back and re-edit colors
after you've applied them. So we're going to
jump in here and just create a new bunny. And we're gonna
start with the head, and we'll grab the pen tool. The shortcut key for
the pen tool is of course P, which is pretty easy. Now with the Pen tool, if you're new to Illustrator, what I want you to think about is you can click and add points. And that's going
to create a line. And then you can
either add a stroke to that line or fill
or both that shape. If you click and drag, it's going to create little
anchor points with handles. Now these handles are
essentially telling Illustrator, Hey, I want to send
this line out that way. And I want the strength of the
influence of this curve to be stronger or less strong depending on how far
you drag out the handles. When we do that. And then we go click
on our next point. You'll notice that this
line is already curved. And I can click and drag
and do handles again. I always think about this. I always think about when
I'm using the pen tool, just point in the direction
that you want to go next. That's how I remember how to use it with where
my line is going. We're going to redo
this a little bit here. Just Command or
Control Z to undo. I'm gonna click and drag
and pull those points out. If I hold Shift, it's going to lock it into
45 degree increments, going to pull that out. And we're just going
to create the head of the bunny. Just like this. We're going to create about
four different points. Doesn't matter how it looks. You can close that shape by clicking on the last
anchor point and read, dragging out those handles. And then if you've
created sort of a messed up shape here, the way that you can go in
and re-edit those is by clicking a or pressing
a on your keyboard, which is the shortcut key for the direct selection tool
up here in the left, the Direct Selection Tool, when you click on
an anchor point, allows you to move that
anchor point around and also re-edit the handles
of that anchor point. With that, you can
create a shape here that actually looks like the head of
the bunny rabbit. And we can create a
more organic shape. It doesn't have to be a
perfect circle or oval shape. We can sort of pull out
these anchor points. I'm using that direct
selection tool until we get something that looks sort of
like a circular head shape. Once we've got that, we're
going to create the eyes. I'm gonna go over here and grab the Ellipse tool by clicking and holding on the
Rectangle tool shortcut key for the ellipse
tool is actually L. I'll make sure I have my
darkest color selected. We're going to create
a little circle here. I'm gonna hold shift and
it's gonna be really small. So we're just going to
create it, maybe that size, I'll zoom in with
Command or Control plus, just so that I can grab that
circle a little bit easier. We're going to
bring that in over the top of our bunny rabbit. And In his right eye. Now to duplicate this, we're going to hold
Option or Alt on PC, and then we're going
to drag that out. We can also hold Shift at the same time to
keep it lined up. You see that pink line
that is a smart guide. Our smart guides are turned on up here in the View drop-down, down to Smart Guides, really useful to sort of align
things and line them up. And I think keep, keep your designs pretty even. Alright, so once we
have both those eyes, one of the things that I did to sort of make it a little bit cuter was cut out a little circle shape and
the bottom of the eyes. We're going to create
another circle here. Like so, this one you don't
have to hold Shift on. I'm going to use
that white color. Use the selection tool
shortcut key is V, and bring that over the top
of the bottom of the eye. Just like this, we're just going to cut out a little bit of that hold shift and select
both this circle and the eye. Then we're going to
use my favorite tool, the shape builder tool. Over here in your tool
panel is two circles with a cursor Shift M is
the shortcut key. Once I have that selected, these two objects selected. Notice how it can see,
I'll zoom in here. You can see every
little overlap here. If we hold Option or Alt, my cursor now has a
minus next to it, normally a plus
holding that button, it has a minus click and drag through everything
we want to get rid of, which would be the
bottom two pieces. Let go. And now we have
a little I cut out. We can do the exact
same thing over here. Press L for the circle
tool or ellipse tool. Create another ellipse like so. Shift over to that selection
tool shortcut key is V, and do the same
thing on this side. We have to select both of them, which will click out of here, click and drag with
that selection tool to select everything. Notice how we get
the head as well. So I'll just hold
shift and click on the head that'll deselect it. Shift M for that
shape builder tool hold Option and drag
it through here. Now, I'm gonna go a
little slower here in the beginning for some
of these new tools, especially if you're
new in Illustrator. And then I'll sort of just
create this as we go along, letting you know what
tools I'm using, I won't be quite as detailed. So you can go back to the
beginning if you need some help going
through the tools. Because I don't want this
to be 45 minutes long. We're going to try to keep
it a little bit concise. So we have our two eyes now, one of the other
things I did was add a little blush
underneath the eyes. I use this pink color over here. Once we grabbed that, we can grab the Ellipse tool again and just add a little oval
shape underneath the eye. Press V for the Selection
tool hold Alt or Option, click and drag that over and bring it
underneath the other eye. So we have two little, little brushy type of
things underneath the eyes. Now we can always move
these around at anytime. I can click, hold Shift
to click on both of these and select them both and move them around by
clicking and dragging. As we go along,
we'll sort of move, morph and readjust are shaped to be the
right bunny shape. It's a little hard to design it correctly just on the fly. So we'll take a step back from our design
and a little bit, look at it and maybe
make some adjustments. Let's go ahead and make
the nose and mouth. So we'll grab that
pen tool again. Shortcut key for that is P. And I'm gonna make it
outside of the head shape. So grab that darkest
selection again. By the way, if you
want to add all these up into a folder like I have, we can go back over
to these swatches. If you've created
them like I did, you can select them all and
then create this folder. Select this new color
group folder icon. You'll see you can name the
color group and also say, Hey, create this from
the selected artwork. And if I hit OK,
it's going to create a folder of all of
those swatches. So we've got this,
we're going to create the nose and the mouth here. A suppose it's called
a mouth right? Grabbing that pin tool again,
we're going to create, maybe just click and drag
out with our pin tool. Do the same thing here. If I hold shift sometimes
that throws me off. So I'm not even going
to hold shift on this. I'm just gonna click
and drag and try to get the shape that I
want out of this. You'll see the shapes
sort of develop as you click and drag
and pull this around. I don't need it to be perfect. Remember, I don't need
this to be perfect. We're gonna do the
same now if I were to just click on this, it's going to create
a sharp corner here. You can see that by if
I can show you here, that line just kinda
comes in and then sort of like a harsh edge there. So what you really need to do is as you're clicking around, you really need to click and drag on that last
anchor point to re-create and reroute around
the shape to finish it off. Now, same thing here, so I've got a
messed-up corner here. I can redo those anchor points with the pen tool by
holding Alt or Option, clicking and dragging
out from that point. By doing that, I've recreated and re rounded those
anchor points. And then what we can do is
that direct selection tool. Remember that white arrow. We can press a and we
can go in and sort of tweak what this nose looks like. Just click on each anchor
point individually. You can click, drag it around. You can adjust the handles, kind of rotate them
differently and create the nose shape that
you think works best. I think we should
pull this bottom part down a little bit more. I think that looks actually
that looks pretty good. Pretty flat on the top and
kind of pointy on the bottom, but very, very round overall. Then what we're gonna
do is go back to that pin tool shortcut key P. And this time you
see how we have a fill and a stroke
here on the left, I'm gonna click
this little double ended arrow to swap
the fill and stroke. That's also shift X
as a shortcut key. Now instead of a shape, we're going to be
creating a stroke. I'm going to find that
middle section here. My smart guides helped
me identify the center. I'm gonna click there, come down to somewhere
right here where I think the corner of the mouth should be like where
the smile should end. If I click there and pull back, I can see that I'm creating
this rounded shape. When I let go, it's going to
create a line with a stroke. And if I press V to switch
over to my selection tool, I've got this stroke selected. We're gonna take our first
look at the Properties panel over here and you'll see
some stroke options. We can adjust the point
weight of it to something like tin. Tin is way too much. So we could maybe do five or find something that
works on your document. The other thing I want to do, you'll notice that the end
of the stroke is cut off. But what we can do with that to round it is actually click on this little stroke linked to
pull up the stroke options. And inside of there, there's gonna be a
cap and we can use Round Cap to just round
the end of that stroke. Now the other thing I'm
gonna do is duplicate this. So holding Option or Alt, we can click and drag that out. I'm going to hold Shift
to keep it in line as well with it selected. Same thing, backup in
our properties panel. There's a little flip along horizontal axis and that's just going to flip that shape over. Then we can bring it
back and line it up right on top of our
original stroke. Now we can completely
edit this if we want. I like to use that direct selection tool
shortcut key is a, can select both these
bottom points and we can move this around to scale it up or readjust the smile
shape as much as we want. And once you have that to
a spot that you like it, we can bring this up over the top of our bunny
and onto the face. That nose is way too big. So let's scale this
sucker down a little bit. I'm holding Shift and Option and just grab the
side of it with both selected until we get closer
to the size that we want. Now one thing that happened here is the strokes also scaled. If we select these two, you'll notice that the
stroke is now 3.189. It's scaled with the nose. We can click this to
make it go back to five. This is where in the
transform panel down here, you'll see we have checkmarks, scale, strokes, and effects. I would recommend when you're
resizing smaller elements, leave it unchecked so that
your stroke doesn't scale. If you want it to be a
point weight of five. You wanted to stay five when you're moving things around,
you want that to stay five. But if you have your entire design or illustration selected
and you just want to resize the whole thing. I would recommend checkmark and Scale Strokes and
Effects so that you can scale the entire shape without it getting
super funky looking. Okay, so now we have our
little nose and smile. What I want to do next is actually add a little bit
of shadow to this guy. We're going to
grab that pen tool again and I'm going to select maybe one of my darker
gray swatches over here. I'm gonna click way, way up here and
create a curve all the way around to the
bottom of the chin. And we're going to
click outside of the shape on both of
those anchor points. And then we're gonna
click and drag to create a curve that goes around the edge of my bunny. Now this might not be perfect
and that's quite alright. Because what we're gonna
do is just use that direct selection
tool shortcut key is a click on this
anchor point and bring him down until
we get something that matches the edge
of the head shape. So it's gonna take a little
bit of playing around with, to tweak this and
get it just right. You want it to kind of
taper on both edges here. So you wanted to
taper on the bottom here and on the top there. It might even require
more anchor points to keep continuing
on with this path, we switch back over to the
pen tool shortcut key is P. Look for that
little slash icon. That means we can click on
that anchor and continue on. I'm just going to
click completely outside of my shape.
Just like this. You want it to be
completely outside and cover up the edge of the head. So I pressed V, my
selection tool. I select both the head
and this new shape. I go over to my
Shape Builder tool Shift M. And we're going to just hold Option or Alt and click on this outside piece
to get rid of it. Now we have a stroke. This piece as well. We wanted to get rid of
that and we can look in our stroke options
over here, we have it, I'm just going to press 0 on that and it's gonna get rid
of it so we only have a fill. Now this film has
a question mark. If for some reason
maybe it thinks that there's multiple objects here, we're going to make sure that
we select the correct one. I might just select
this even lighter gray and it looked like I had
the head selected as well. That's why that Phil
was kinda messed up. So we can just click
on the head again and select this other swatch. There we go. We've got a little shadow going around the
edge of this bunny. Now if you want to add
other points to this, you can just click
on that shape, the PIE tool look, there's a plus icon
there you can click. It's going to add a point
with a perfect curve there. We can press a for the direct selection
tool and we can pull this point back so it goes up against this edge
a little better. Now we can pull this
handle over to create a better taper along this side kind of gets
thicker in the middle. And then we want this taper
to be better down here. So let's go ahead and tweak
this handle just like that. So that's how you can
sort of add and fix the tapering along the
edge of this shadow. Now with this entire head, I'm going to press V for the selection tool,
select everything. And it's gonna be
Command or Control G. Or you can right-click, go to group or
ungroup right here. Now this piece is
grouped together so we can move it
around individually. Let's create an ear. Next, we're gonna go up
here with the Pin Tool. I'm gonna check my
selection here. I think that's the darker ones. So we're going to switch to the, I guess, the color
of the rabbit's fur. And we're just going
to click here. We're not going to click
on the edge of the path. We're gonna click inside. Remember this ear is gonna
kinda go fall behind the head. Click once, come up here as
high as you want the ER to go click and drag to
create a little shape. Then we'll just bring it right back it down, just like that. And we'll close off that path. That's perfect. Now I'm going
to click or press V and click off of this ear shape and we can move
this around freely. I want to create the inside of the ears and the pink part. We're going to press P
for the pen tool again, kind of find an
inside edge here, click, same exact
sort of shape here. Doesn't really matter
where you're putting this. I'm actually going to click
and drag here just to create a little bit different
edge on one side of this, I don't want it to be perfect. And then we'll click
again right there, press a for the direct
selection tool and grab one of these handles
and just bring it back. But you've got to make
sure that this handle, it doesn't take that
outside of the ear. We made it white. So what we can do
with it selected, just press that
little pink swatch. And now we've got a pink
section of the ear. It's in front of the head. So we want to grab both of
these and I might just group that Command or Control
G. Right-click, arrange, send to back, that's Shift Command left bracket or Shift
Control Left Bracket, bring to front is the
opposite of that. So there we go. We've got a little ear
and I can actually click on this group hold
Option or Alt, drag it out, let go. So now we've got to, I can come back up to
my Properties panel, Flip Horizontal really
quick like that. If you don't have the
properties panel, this might be a difficult
tutorial for you, but up an object transform
is also reflect. You could do the
same thing there. And we can bring this
ear over to this side. And maybe with one of these
ears and we can just readjust and select and move these
around and grab the edge, rotate it just to make it
a little bit different. I think these years might be a little bit just looking at it. There might be a
little bit small. So I'm gonna click
both of them and just grab the edge here, hold Option or Alt as well as shift and scale
both of these up. What we might even do here
is squat Both of them down if that's a term by pressing a for the
direct selection tool, grabbing the top two points. And we can just drag this back
down to bring in that ear. We can create whatever kind
of shape we want here. With this, we can select
our anchor points. Remember, I talked about
kind of stepping back from your design and readjusting
it if you want, you can select with
the selection tool, rotate these around, do whatever you want to create,
the shape that you want. I think what's actually happening is the inside
of the ear here. This pink shape is
too wide down here. What we can do to fix that is just take these
two anchor points and bring them in
closer to each other. Like so. And even, you could even bring them in on top of each other at this point. And then you might need to just readjust your different
handles here. If you click on the right thing, readjust your different
handles to make sure that ear sort of looks the
way you want it to look. Same thing I think with this other outside
edge with the fur, we got to use that
direct selection tool. I'm just using the
direct selection tool to grab these different
anchor points. Bringing them in and creating the shapes that I want
for my bunny design. All of this that we're doing is gonna be totally
different for you. Whatever you're
creating, just use these same techniques to
click, Adjust, move around, adjust some anchor points, create new anchor points, do whatever you want to
do to create your design. Now one other thing we can do, and this is kind
of important with the regular selection tool. You know, this is a group so it all moves around together. Well, if I want to
get in there and adjust maybe where this pink
shape is just by moving it. I have to double-click
into that group. And now I'm in a
little bit of an isolation mode and I can see my layers up here in the upper-left it says layer one, which is gonna be the full
just art board of everything. And then I'm inside of this
group and now I can't even select anything else
except for what's in the group and it's
separated these pieces. Now, I can just
move this around. If I double-click back out
in this sort of gray area, it's gonna take me back. So that's kind of a
nice way to work. Instead of a group, I like this shape better
than this shapes. So let's just delete it. Grabbed this again, hold
Option or Alt, bring it over. We'll flip it horizontal
and we have some ears. Now, by the time we
look at the old design, I might completely
readjust that, but hey, look, there's some
ears, That's how you make it. And let's move on to the body. The body is going to be
kind of like a squat. Squat is sort of circle. So I'm gonna start with
1 here at the top. I'm gonna click and drag. I'm creating the body outside
of the shape of the bunny just so that we can look at it and then move
it underneath. I'm gonna create another anchor
point a little bit lower down here and drag it out and create this little
squatting shape with four anchor points. We're going to have to
readjust that bottom one. Click and drag on
the last one here, just to create this shape. And I'm going to press a for the direct selection tool and grab this handle
and pull it out. One more shoulder shape there. Then down here we might just
pull this down a little bit. We're going to want that to
be a little bit more round, a little bit more flat. If this is locking into things, sometimes Smart Guides
get in the way. What we want to do is just zoom in and it's going to be able to let us move this and tweak this and the way that
we want a lot easier, you can just tweak
all these anchors. Once you have this all created. It's not a big deal. It's pretty easy to do. And you're just gonna get
the shape that you want. I don't like how that's
sort of pinching in. We might reduce the influence
of this anchor point over here is sort of
a little egg shape. It's kinda tilting to the left. Not a big deal if you want, you can just grab this
anchor point at the top. Remember this is what the
direct selection tool, the shortcut key is a. And we've got that
all completed. Now, this is pink. We
want this to be white. We're just going to click
on our white swatch. We also do want a similar
shape in the middle here for his belly Pin Tool again,
same sort of thing. Just click on the top here and
we're just going to create this rounded shape
on the inside. We're gonna go around,
I think I'm gonna do three anchor points
for this one. And we'll just have to readjust our handles here in a second. Click around. I would do this a lot quicker, but I'm trying to show you
exactly what I'm clicking on direct selection
tool shortcut key is a pull this handle out. We want it to kind of mimic the shape of the outside
of our bunny here. I know this one's
way too strong, so we got to pull
him back a little bit. Same thing with this one. It's sort of flattened. Maybe we need it to be a little bit rounder so we can bring it in a little and
then round it off. A lot of this is just clicking. You got to be direct
with your clicks. It's the direct selection tool. And click once to select it and then click it's got
to be very sort of, I guess, direct and
certain with your clicks. So make sure you
click everything. Because if you click and
accidentally drag my sort of take your
whole shape with you. So once we've done
that, we're going to switch the color
of this to pink. And we have our belly shape. Now we can take this
and group it together, Command or Control G, drag it underneath our bunny and sort
of see where things are at. It's on top of our bunny. So we're gonna right-click, arrange send to back
underneath our bunny. Now, I'm going to press V for
the regular selection tool, grab this whole group and
sort of scale him up, but also holding option
if I don't hold Shift, I can do this with him so we can make him exactly
what we want. Well, that's a fat bunny. We'll grab this point
here and continue holding option to squeeze
them in just a little bit. He didn't eat that
much candy quite yet. What I'm gonna do is actually double-click into this group. That's gonna make
it easier just to adjust this group only. We're going to press the
P key for the Pen tool. Always grab that
light gray swatch. I'm gonna start at probably
somewhere, maybe in here. And we're going to
swoop down all the way to write in here, similar to what we
did for the chin. And then we're gonna
click and drag, click. Remember all the way outside, create a big old
shape outside here. We're going to add with the P
shortcut key, the pen tool. Another point right here. With this one, we're
going to adjust our influenced between
these two a little bit. And I might even bump this
anchor point up just a touch, just to get this curve
a little bit higher. We can always make these
adjustments later with the bottom, let's
select everything. Shift M for the shape
builder tool Option or Alt. Click. And we've removed it. And now we can kind
of look at how that shadow looks on
the side of our bunny. I might move this
anchor point a little bit closer to the edge here. And I think that actually
looks pretty good. We've got to create some arms. Coincidentally, the arms are
kind of similar to the ears. Let's make sure we have
our white fur selected. I'm going to create something
maybe starting up here, like if his shoulder was coming out right there and click, click down here and
we're gonna create a little rounded shape. Then we're going to
come right back to here and just close off that path. Now after creating it, I noticed this arm is way too small, so we're going to use
the selection tool and scale him out a little bit. He's gonna be way too fat
now, it looks like a flipper. So let's grab the direct
selection tool, grab this point, and maybe reduce how much handles affect this
curve like so, we're going to use
the selection tool, right-click and transfer,
no arrange, send to back. It's gonna be the arm on
the side of our bunny. I think we can rotate
it a little bit. So let's just kind of stick
out and we can move it in to find where you'd like
it, something like that. And then we can just
grab this arm option, drag, that's Alt on PC. We could simply
rotate it around. Remember, we had
him waving before. And we can give
them a little wave. Just like that. We're just going to
rotate this round, right-click arrange, send to back to make sure it's behind. So now we've got a little
bunny and he's waving. We need some feet
using that pin tool. We're just going to
create some little squat feet down here. I'm gonna be kind of round
with the top part of them. And then just bring
this over flatter, which will change the
handle here in a second. Very similar to his nose. Actually. Use the direct selection tool
to click on this point and adjust that handled sort of flatten the bottom of his feet. We're going to send
this shape to the back. So it's underneath everything. And then we just going to
move that in a little bit. Find the spot where you
want his feet to be. Press the selection
tool, that's V, hold Option or Alt click
and drag to move this over. This one, I don't
think I'm gonna flip. I think I'm gonna keep it
sort of poking out there. His little foot is just going
to poke out on this side. And it's going to be the
same shape on this side, but it looks different because you can see
more of it over here. Did we create the bunny? I think we did. It's probably going to
look completely different than the one that
we started with. This guy looks a lot
cuter over here. There's a couple of reasons why, and there's a couple
of things we can do. We're going to add a
little hair up top. We're gonna make his
eyes bigger and we might adjust the shape of his
belly a little bit. His ears, I think
even look better. So there's a lot of
things that you can click and adjust with this guy. I think his arms
could be fatter. His body shape is descent, the feet are okay. But he couldn't be way
cuter with those eyes. So let's zoom in here. We're going to use
the selection tool. Double-click on the head
since we grouped it all together and click on the eyes. And what I would do is
just do one I holding Alt or Option and Shift and pull that up
and make it a lot bigger, bigger iss equals Qt or bunny. Just delete this other eye because we're just going
to hold Option or Alt, click and drag with this
guy to duplicate that one. Wide set eyes. A lot cuter. I think we can
probably pull this nose up. I'm going to group these
guys together so I don't have to select them
individually anymore. Pull that nose up a
little bit higher. Then we might even just
grab everything on the face here and pull it all down
just a little bit more. So he's got a bigger head, bigger eyes, just like that. Maybe those eyes are
a little too big. You guys can adjust
it to look like this. I'm going to press M for
the Shape tool here. You see that it's
a rectangle tool. Create a rectangle. I'm going to create a perfect
square by holding Shift. I'm going to click on my
green that I've got selected. We're going to go back to the selection tool V is
a shortcut key, Arrange, Send to Back on that sucker, select everything
so we get our whole bunny shift click on the square. So now it's just the bunny. I'm going to group
them together. And what we could do
is select everything. So we have this group
and the shape selected. I want to center my
beanie on the shape, so click on the Shape. Darker blue line
around it means we're aligning to a key object. You can actually see
that down there in the alignment panel
align to key object. Now we can press Center
and Vertical Align Center and our bunnies sort
of centered on that. Let's create the little
shadow at the bottom. Pretty easy to do. One thing I might do with
my background is locked it. We can go to Object
down to lock selection, that's Command or Control to now we can't move
the background. That's a good thing
in this case. I'm going to press the
P for the Pen tool. I'm going to click
here to start. We're going to go over here, use our handles that we
learned and just create this little circle shape
down here. Like so. Finish it off with this
last little anchor point. It's going to be some
kind of dark gray. I'm not sure. Maybe we'll just do the
darkest one and then we'll go to the opacity over here. And we're going to drop
that to maybe like 15%. And then we need to send
this behind the bunny. So what we can actually
do is just bring the bunny, the front. We want him on top
of everything. So arrange bring to
front on that group. There we go. We have a little
shadow underneath him. You can readjust all
the anchor points of that and move it up
and down if you want. The only difference between these two is actually the hair. Let's do the hair. Let me show you how to do
the hair really quick. We're not done. So since this is grouped, we don't have to ungroup it. We can just
double-click into it. Remember we go into
that isolation mode and we have a group
within a group here. We've double-click into that, see how we can go
layer group, group. We can keep diving into
these different groups. So I'm gonna
double-click all the way into only the white
shape of his head. I'm all the way in layer
one group, group path. So here we're going to select the Pen tool and we're
going to add some points. I need for every
little tuft of hair, I need three points. I'm going to add a point
here and add a point here. That'll be one tuft of hair. Over here. We're going to add a
point, another point, press a for the direct
selection tool. And let's zoom into this guy. We see all these points. We got a group of three here. I'm gonna grab the
middle and just pull it up just like that. Now we need to adjust
these anchor points here. I'm gonna adjust
the handle here, adjust this handle
to push it out. And we're just going
to keep adjusting these until we have sort of like a little
tuft of a hair up here. Want to pull and adjust the
influence of these handles. Press the P shortcut key for the anchor point tool which
you hold Option or Alt for. I think we're just
going to keep adjusting these until we get the
shape that we want. It doesn't even
have to be perfect. It doesn't look all that great, but just a little bit shows
that there's some for up there and you guys can
adjust this however you want. This is almost like two
little waves of hair. There we have it.
That is how to create a flat design bunny
in Adobe Illustrator.
10. Flat Design Cloud: Alright, so this is the graphic that we're
gonna be creating. It's this sort of flat
designed Cloud icon with a nice long shadow on
a blue background. To get started, let's go
ahead and go up to File New. And we're going to
create a new document. It's going to be 1920 by 1080. That's in pixels, of course. And the rest of this
you can leave alone, I do like starting it
in RGB color mode, however, just click
Create and we're going to have ourselves a new
document from here. Let's start. As always,
with the background, we're going to
create a rectangle That's just a shape with the rectangle tool and that's shortcut key M for
anybody wondering, just going to click and drag and cover my entire canvas here. This shape, if I check my
transform option up here, it should be 1920 by 1080. And if you want
to make sure it's dead center on your background, you can make sure that
the align tools here is aligned to art board and you can click the middle of each. So this is Horizontal and
Vertical Align there. Once that's set, Let's change the color of it here
in the upper left. And let's just select this
sort of sky blue color. And from there I'm also going to get rid of any stroke that we have just by clicking
this none color with a little slash through it. Alright, so I've got this
background color set. That's great. Let's lock it in to do that, go up to object, down to lock, and then
you can lock selection. So whatever you have
selected, what you can lock, the shortcut key
for that is command to that is something
I use quite a bit. And then the shortcut key
to unlock things is Shift Command E. On a PC that's
control anytime I say command, it's Control on a PC. Anytime I say option, That's Alt on a PC. So keep that in mind in case
I forget to tell you later. All right, So what
we're gonna do is build this thing
out of shapes. I'm a big fan of building
things out of shapes, using the shape builder
tool to make them work. So I'm going to grab the
ellipse tool over here. The shortcut key for that is L. Then I'm going to, I mean, you don't have to create
them out of perfect circles, but in this case
I'm going to create this little cloud icon
out of perfect circles. Let's go ahead and change the selection or the
fill up here to white and the stroke we can
change to black for now. And then the stroke width. Let's do, I think on
this type of a canvas, we're gonna do something
like 20 points from here, we're going to draw
our first circle. I'm gonna hold
shift to keep that completely as a perfect circle and then let go and just create a circle any size you
want on your canvas. Now I'm gonna grab
my selection tool. The shortcut key for that is V. And with this circle I'm gonna hold option that's Alt on PC. And I'm gonna click and drag
out while holding shift. You see these little pink lines, those are smart guides. You can turn them on in
the view window up here. Command U is the shortcut key. I pretty much always
have them on so that it helps me keep things
in line with each other. I do, however, want to drag that circle completely
straight across. Don't move it vertically yet, because these two circles are important that they're
aligned together, it's going to help you give that even perfect horizontal line at the bottom of
the cloud shape. All right, so we've
got the two circles, these are our two
outside shapes. Now let's go ahead and duplicate
again by holding Option, holding Shift and
dragging this circle over maybe until it intersects
with the side of itself. And I let go. I've got it. Three circles
here are all the same size. Well, this center middle circle. Let's go ahead and drag him up. I'm gonna just hover over that middle top point and
click and drag them up. Now makes sure you hold
Shift or else you're gonna get this like
elongated oval shapes. So if I hold Shift,
it's going to create a nice big circle. And let's just make him, so this'll be our
medium-size circles. So there's two on the
sides are gonna be small. This will be medium, maybe just a little bit taller than those two guys
right in there. This is not an exact
science, just so you know. All right, so let's
switch back to that selection tool
and we're going to, well, we were already on it. You don't have to switch
back to it, but we're going to duplicate this one more time. Let's create one more circle. I'm holding Shift
to keep it aligned and sure will
intersect right there. From here, I do want to make
this the biggest circle. So I'm gonna hold shift
again to scale it up from that top point
till I don't know, Let's give this a little
bit more right in there. Cool. What I want to do with all of these now is select them all. And then we're gonna grab our shape builder tool
that's over here. It's got two circles in it
and a little cursor icon. The shortcut key for
that is Shift M. I got a little plus
icon on my cursor here. And as I scroll over
all these circles that recognizes all
the little shapes in here, that's fine. All we're gonna do is click and drag all the way
through everything. And I missed a few. So make sure you click
through everything. And make sure everything gets highlighted and then let go. And that's going to merge all of those shapes together.
This is pretty cool. You can already see that we're getting this little cloud shape, but the bottom of it, I mean, if you want the bottom of it to have those clouds, you can. But we're gonna make
this a little bit flatter and we're going to use, you can see all these
little anchor points here. We're gonna use the
bottom two anchor points of our outside circles. What I want to do
is just get rid of all these middle anchor
points between those two. I can grab the pen tool
to do that pretty easily. And if I just hover over those
anchor points and click, it's going to get
rid of each of them. So if I just click
through and get rid of each of those
little anchor points. Now we've got this
nice cloud shape that rolls right into a
straight horizontal line, allows to create that nice
long shadow underneath and replicate that first
shape that you saw that we are
trying to create. Alright, so I like this. I think this is pretty good. What I do want to do is
get rid of the stroke. Let's just create a
white fluffy cloud. That stroke did help us see
where all of our lines were, but we're just going to
get rid of it for now. I'm going to click on
this guy again and let's get him in the center
of this art board. To do that once again, go
to those alignment options, which are usually hanging
out up here at the top. If you don't see them up there, you can go to window down to align and they'll probably
pop out here to the side. But we're going to
ignore that guy. Let's just use this one up here. I think it's handy-dandy. All right, align to
art board. Perfect. Now I'm gonna do the
horizontal align and vertical aligned to put them right in the
center of the art board. Now one thing was centering objects the way this
is sort of offset. So like if this was
a perfect square, it would be exactly in
the center visually. And mathematically. While this is in the center, mathematically because
this bounding box, There's a little bit more like visual negative space up here, a little bit of whitespace. And I think to center
this visually, you might have to bump
it up a little bit. If you hold Shift and
hit your up arrow key, you can sort of
bump that guy up. And I think that's
a little bit more visually in the center
because there's about equal negative space up
here as there is down here. That's just a little
design tip for you guys. Now let's create the long
shadow underneath our Cloud. To do that, we're going to copy paste this guy
a couple of times. First I'm gonna show
you the actual options. You go up to the Edit
it down to copy, and then go back up to Edit
down to paste in front. So copy is command
C or control C. Paste in front is
Command F or Control F. To paste in front doesn't
look like it did anything. But if I click and drag, yeah, we created a duplicate
of the cloud. But we actually want to
duplicates of the Cloud. And because I already
have that copied, I'll have to do is
hit Command F again. And now we've got, we've got three Clouds here,
so you see 123. And then this one, I'm
going to undo that with command Z and get
them all centered up. Now what we want to do is take that top Cloud and we're
just going to drag him off the canvas down here about the angle that you
would want that shadow to go. Now between these two clouds. So this next cloud,
the middle one, and this guy, we're
going to create a blend to create the shadow. Obviously, a shadow is
gonna be like a dark shape. Let's select both of these
by holding Shift and clicking on each
and change there. They're filled to a black
color. That's great. Let's just create a blend now. I still have these
two guys selected. Just these two guys
go up to object, down to Blend and we're gonna do Blend Options and under
blend options for spacing, Let's specify distance and do one pixel that's going
to create a cloud. Every one pixel between
these two clouds, we're going to blend these
two shapes together. And orientation wise, you can
keep it on this first one. Doesn't matter as much. I'm gonna hit OK and
nothing happens because we just set up the blend
now we've got to make it. So go back up to option, down to blend, hit Make. Now we get our shadow. But our shadow is not
much of a shadow. Yeah, it's very just
one solid black color. It's got all these
clouds in-between every one pixel and
it's created a group. So these two clouds, if I click off and don't
have anything selected, and then I click back onto it. You see it's got
both of those clouds selected with this
blue line in-between. And if I move one of them, it's going to move both of them. So Command Z to undo that, I want to keep this
cloud centered on that other original cloud. And what we want to do is
double-click into this group. And now we're inside
of the blend. You can see we have layer one, which is where everything is at, and then we're inside the blend, that's our current
isolated group. So now I can click on each
of these individually. What I want to do with this
bottom cloud is actually go to like a complete
transparency. So I'm gonna grab my
Transparency panel over here on the right
if you don't see it, window Transparency
way down here. And once I get that open, I'm gonna change
the opacity to 0. Hit Enter to commit that change. Perfect. So at this point you
actually have the shadow. We're just probably
going to want to take the transparency down or the opacity down on the entire
blend a little bit. So I'm going to double-click
out here in the gray area to get out of my isolated group
back to the center now. So I'm going to zoom
out just a touch. What I want to do is
send this to the back. And to do that, I'm going to do Shift
Command left bracket. That's also shift Control
Left Bracket on PC. And then you could just
right-click and go arrange send to back if you don't have those shortcut keys
committed to memory yet. But that's how you do that. I'm also going to send this
background layer to the back, but we need to unlock it first. So don't forget that that is well, I don't
know what it is. I think it's Command
Shift to know it's command option two to
unlock everything. So on a PC that's gonna be Control Alt to that
unlocks everything. And then we're going to
send that to the back with Shift Command left bracket. I do like that's some important
ones I use all the time. The Shift Command, left bracket, Shift Command right bracket, send to back, center front. I would recommend
memorizing those. All right, I think this
shadow is a little too harsh, so let's take it
down to something like since I prepared
this before, I know 10%, I think I just want a little bit of a shadow
underneath that cloud. That's cool. There's our shadow,
but I don't see a whole lot of difference in
the shadow going down here. So let's bring this cloud up and I can do
that by clicking. Now I've got that
blend selected. I can double-click on it and I'm inside of that isolated
blend, Grouped layer. And I can click on this cloud down here and I can
move him around. I can completely changed
my shadow around. So if you want to
change the angle of your shadow later,
you can do that. I'm going to bring this
cloud up a little bit closer and then double-click
out of that space. So now you can see the shadow sort of blends
into the background now because right in here
we go to 0% transparency. That's it. We've created a Cloud icon. You can clip this into a
circle shape if you wanted to, whichever way you
want to use this guy. I hope this was easy
enough to follow. Thanks for watching and
I'll see you next time.
11. Flat Design Christmas Lights: Alright, so we're
in Illustrator, this is what we're
gonna be designing, this sort of like the
finished product, we're going to have a
little strand of lights. It might do a loop de loop. I've got some glow on these and there are
different colors. They all have that
flat design look. We have a little sort of
highlight on the left, some shadow on the right, and then it kind of flips
on these bottom ones here. But basically we're gonna
make one of these guys and then I'll show you how
to string them up like this. So I'm just going to
grab one of these guys down here as a starter. I'm going to copy paste him
and wall head on over to a new document so you guys can start from the very beginning. I'm gonna go to File New. The shortcut key for that is
Command or Control in I just do 1920 by 1080 because I'm in the world of
YouTube tutorials. But nothing that really matters. For starters, I'm going to
bring this guy over just so I know the shape
that we're making. Let's look at this
piece by piece. I'm gonna start with
the base of this guy. That's just gonna be
with the rectangle tool, the shortcut key for that is M. And we're gonna make a
little rectangle out here, approximately this shape. So the key with this is you
can make any light you want, so it really doesn't matter. Now, I want the fill of this
guy to be the lighter green, the two greens we're
gonna be using. So I'm going to go up
to my color panel, which is in the Window
drop-down color. I think it's F6. That's a guess. Am I right? F6. Alright, I got that down. Now. I like to double-click on this little swatch there and it pulls up
this color picker. I'm a huge fan of this color picker because I know what I'm
getting out of it. I want a lighter green, but something more like a muted
tone which tends to be in this circle of colors somewhere in the grayish saturation, not fully saturated, and then pulled down
from the top and bottom. So we're gonna be right in here, I think for my lighter green, maybe something like that. Once we have that,
we can switch back to the selection tool. The shortcut key for that is VI. And we've got it, okay if we click on this guy, there's these little
dots in the corners. If you pull in these dots, it's going to round
those corners. I don't want to quite
round them that much, but I'll pull them
back a little bit. I just want a little bit
of a rounding Command or Control plus or minus. We'll zoom you in and out. I can zoom in and have
this shape select and sort of pull these
corners back a little bit. I just don't want
them quite as sharp. Now there's a couple
of subtle things here that you might
notice that I created. You see this rounded arc at the top and rounded
arc at the bottom. It's pretty easy to create
that we can select it, switch over to the Pin Tool, which is this little pin icon, the shortcut key for that as P. Then if we hold Alt
on a PC or option, we get this little icon and
it's struggling showing it, but you can kinda see it. It looks like a telephone, almost like a dot with an arc, two dots with an
arc between them. If we just hover over the line while we
hold Alt or option, we can click on that and pull it down to create this sort of arc. I just want a slight arc to
this, something like that. Just a little bend
in the bottom. I'm going to do the
same thing when a hold Alt or Option and create a little bend
up here at the top. Just like that. Now
we've got this shape that it's got a little
more character to it. It's just has a little
more fullness to it. Let's create this
top portion here. I'm gonna do that
by going back to that rectangle tool
shortcut key is M and just creating a rectangle the
size of my shape here. So from left to right
it's the same size. We need to adjust the
color of this guy. If I pop open this color
panel again, remember F6, I'm going to double-click on him and I'm just going to pull down to create a darker green. Something in here would work. Alright. There we go. Next, see how I've got this sort of
angled out like it. The light bulbs going
to sit in there. All I need to do is switch
to my direct selection tool. It's up here, it's
the white arrow, the shortcut key for that
is a. I'm going to select this top left point just by clicking and dragging
over the top of it. And then you using
my left arrow keys, I can bump that out. If I hold Shift and press
the left arrow key, it's going to bump it
out a little bit more. That might've been too much. So I'm gonna go 123 back. So I did Shift Left
Arrow key to bump it out once and then 123 back
without the shift. Once again shift
right arrow key. Then let go of shift one to
three on the left arrow key, and that matches up either side. Now I know that we've rounded the top of this
bottom shape before, but I've actually
changed my mind on how I want this to be layered. I do want this shape
on top of this one. So what I'm gonna do is just
click on this guy here. I'm going to go back
to that pin tool. The shortcut key is P, hold Alt or option right
there on the bottom. And sort of bring that up
to create the little ark. Maybe something like that there. So now if I click off of this
with the selection tool, I've got a little bit of
that arc built into it. This top part is too tall, so I'm gonna grab the
two points here and here by pressing a for the direct selection tool,
clicking and dragging. So I select those
two points only. Once I have that, I
can click on the path hold shift and drag
it down a little bit to make sure it's the
height that I want it to be somewhere maybe in there. The last thing I can do is with these two points still selected with that
direct selection tool, I can adjust the
sharpness of the corners. I just want a little tiny bit of a rounded
corner up there. Now we've got this shape setup. I want to create
the indents here. I want to make sure
they're the same color as this darker green. So what are we
gonna go ahead and do is while we have these, I'm going to switch
to my selection tool, shortcut keys V. Click on this object, go up into my swatches panel. If you don't see it
Window down to swatches, that'll pop this guy out. And if we create a new swatch while we have this guy selected, it's going to
create a new swatch based on this color green. And I want that to
be a global swatch, so make sure that's checkmarked. Hit Okay, and we've got
a new swatch in here. I'm going to click on this. Oops, I accidentally
rotated that. I'm gonna click on this
darker color green, new swatch, global swatch hit. Okay, now we have the
light and the dark green. What I can do actually is as long as I don't have
anything selected. So click off of everything. Shift, click or click one shift, click the other one that's
going to select them both. I can create a folder
called a new color group. And I'm going to call
this light colors. This will be the greens,
but we'll also add in our other light
colors as well. So we've got this folder
of these light colors and now I can go back and change
those anytime I want. Pretty, pretty cool
way to do that. We need to create these sort
of indents in this here. That's sort of what
we see on these, the bottom of these lights. So M is the shortcut key
for the rectangle tool. We're gonna grab
that rectangle tool. I'm going to create
just a skinny rectangle that goes all the way
across this element. And I want it to be
the darker green. So I'm just going to select
the darker green on that, so that changes
the fill to that. Then I can hit my
selection shortcut key, that's v, To go
back to that tool. And there we go, we've got that. Now I want an odd number
of these I think so. I'm going to hold Option. Let's zoom in a little
Command or Control plus hold Option or Alt. Duplicate this piece. Click and drag it left. And we're going to just
keep duplicating those. And in fact, you can use
Command or Control D Once you've done that once and it'll duplicate those across, we want to make sure
we have an odd number. So 12345678910. I think I'm going to go ahead
and delete the last one. And I'm going to select all of these with that selection tool. And I'm going to just
find the edge here, click and pull it across. What that did was it sort of made these a little bit wider. You can adjust these
however you want. This might be too many. Maybe you'll want to do less
and make them a little bit wider like I did in the example. But regardless, I want
these to be spread out evenly there
almost but not quite. So we need to open up
our alignment panel. I've got them all selected. I'm gonna go up to
window down to a line, pop that open, and I don't
actually see what I need. I do see what I need,
but if you don't, make sure you click this
hamburger Show Options. What I want is
aligned to selection, and I want to click
this guy right here that's Horizontal
Distribute Center. And you'll notice a little
bit of adjustment or not. These were already
pretty much centered up, but just in case they weren't, it adjusted those two,
they're perfectly centered. Now what I want is to center
this on everything else. So I'm gonna select it all. Right-click it. We can group it together,
That's Command or Control G. Now this is one big group. I can click this group and Shift click the
background object. Now they're both selected. Just click the
background object again. Now it's sort of
double selected. That means we're aligning
to it as a key object. Open up that alignment
panel again and make sure this says
Align to Key Object. And then we want to go ahead and align that to the center, which had already
was, but let's say we were off like that. You can hit horizontal
line center, it's going to center it up. Alright, so we're centered up. We just need to chop these
pieces off where they go past. We've got this group. We can select everything. All of this. That's weird. I don't know why that's
selected were out there. But all we need to do now is use the shape builder
tool right here, Shift M, and it sees all
these different shapes. What we want is to chop
off this bottom portion. So I'm gonna hold Alt or option and a little minuses
is going to pop up. It's having trouble
showing those, but you can see the cursor
now it's got the minus. If I click and
draw through that, it's going to chop
those pieces off. Now I want to do the
same thing up here, but before I do that, I actually want to go back
to that selection tool and select all of this and
duplicate this piece. So I'm gonna hold Alt or option and just duplicate
this piece out. I want to have a piece
that I'm working on. And I also want to have a piece that is gonna be my final. So over here I'm
working on this guy, so I'm gonna select all this, go back to the
shape builder tool. And this makes it easier
to where I don't have to worry about getting rid
of anything on accident. I can just hold Option or Alt, click and drag through that. Now I have these pieces with
the angles that I want here, that they run along that arc, they're gonna follow that line. We're going to
ungroup this first. And then I'm gonna click and drag through that
to select it all. Delete. We're just going to
delete that out. I'm also going to delete this
background piece. Delete. Now over here, I don't
want this group anymore, so I'm gonna delete that. Now. I've got this guy. He's going to fit right in here. But what I want to do is make
him not fit edge to edge, but just kinda come
close to the edge. So I'm gonna take my
direct selection tool, that's the white
arrow shortcut key a click and drag through
these top points. Once I have these top points, select on this arc, I'm going to hold Shift
and use my down arrow key. And that was way too much. So we're not going
to hold shift. You guys just press the down
arrow key a couple of times. That'll that'll sort of bring
those down a little bit. So that was two. I'm going
to select the bottom one is only now go up to 12. Now, if we select this as
this group together, no, So we're gonna select
all these command or control G to group together. You can also right-click group. Once we've got that
group together, I'm gonna bring this over here. All these smart
guides are helping me Center the center it up. As long as it's centered, we can we can have
that on there, but it's behind everything, so we need to right-click
and bring it to the front. So good arrange, bring to front. There we go. That's
how you do that. That was a lot I know probably a lot more
explanation than I wanted. There you go. Now what I'm
seeing here is that our darker green maybe isn't
quite as dark as we want it. So let's change that simply by going to
the Swatches panel, Double-clicking on this green. Now we can look at this with the RGB or any of these
other types of settings. If I go to lab, I can actually
sort of pull this one down a little checkmark preview and maybe pull this
down to like 20. And there you go,
that darkens it up a lot more. I'm going to hit Okay. Now that swatch, the
dark green swatches a little bit darker and
everything changed at once. All right, cool.
We've got this piece. Let's go ahead and add
the little shadow to it. To do that, just go back
to that rectangle tool. Maybe select a fill
that's straight black. Then we're gonna
create a rectangle. And I'm going to use
smart guides here. So if you guys aren't smart guides turned on and
just go to View drop-down, down to Smart Guides and make
sure that's checked marked. But anyway, we're gonna
create a rectangle. Click and drag this out so it lines up in the center there. Let go. Now we're gonna go
back to the selection tool shortcut keys is V, select all of this right there. Then the shape builder tool, that's Shift plus M, hold Option or Alt
and just click on this outside shape and
that gets rid of it. So now we have a shape
that's cut out on here. And what we can do is take the
opacity down to maybe 15%. That's going to create
that shadow on that side. What I'm seeing here
is that we might want a little more saturation
in this lighter green. So if we go back
to our swatches, we can double-click this swatch. We can select Preview. And potentially we could just pump a little more green into. That. Might be a little too light. So we can pull that
back just a touch. We can just play with
these till we get it more, more in there where we
want it and hit Okay. That might be okay,
right. Okay, so that's how you can
sort of change those global swatches though. All right, so we've
got this guy, we need to create
the light bulb part. So to do that, we're just going to
create a circle, pretty much create
novel rectangle tool, click and hold it. We can go to the Ellipse tool, the shortcut key for that is l. Then I'm going to
create an oval shape, something like that right there. Alright, let's go ahead and make this a color that we want. So not green. Click on actually
when we're gonna go into that color tab again, a double-click my swatch,
I'm going to pick a color. We're gonna make it a read. Something in here,
maybe right there. Hit Okay, there's our red. Now of course, I'm
going to want to add this to my swatch
group down here. I'm going to click
New Swatch on there. And we're just going to
do a global swatch hit. Okay, there it is. I'm going to drag it
down into this group. And there's our first actual
light color right there. We can always adjust that later. So no worries there. The global swatch really helps. We want this thing to be a
little bit more egg shaped, I suppose is the term. I'm gonna click on it,
select my pen tool. Remember the shortcut key is P. And up here I'm going
to hold Option or Alt. And that's gonna bring
up the anchor tool. If I click and drag on this
while I have those held, I can create new anchors. And if I hold Shift, it's going to lock those
into 45 degree increments. I want it to be straight
across like this. And I'm just going to
create a little bit more of a point at the top. So I'm gonna bring that
in like that and let go. So there's, there's
that what I can do with these is sort of go back to
that direct selection tool. Click and drag through the middle section where it includes those two
anchor points. And once I have them, I can use my down
arrow key to bump this down so it's
sort of dropping. I don't know the center of gravity on this
guy a little bit. Maybe down into there. Then if I select
this bottom point, bring him up with
my up arrow key. Somewhere in there. So we're looking for
that light shape. I think that's, that's
pretty close. You guys. It might come to a point
more than this one does but to each his own, right? Alright, so I'm
gonna click this, drag it over to here, right-click, arrange,
send to back. So we want it behind
this guy, right? Then we just want to
sit him in there. Find where you find where
you want them to sit. You can use your smart
guides to help you find the center there. And UV light. It's in there. Okay, so
let's hold Option or Alt and make a duplicate
of this right out here. Now with this duplicate, I'm going to make another
duplicate and bring him over. I got two on top of
each other. See that? I'm looking at the shape
that these kind of cut out on the right side to
make this shadow. What I actually need to do is
make the left shape bigger. So I'm going to go ahead
and scale this up by clicking the top holding Shift and making it bigger like that. I'm going to drag
it left a little. I'm still looking at this
right-sided discuss. So if I select both of them, you see how it's creating
this shadow over here. I'm gonna click and drag
it left a little bit more. But I don't want it
to hit the top here. So maybe right in
there is pretty good. See the overlap
between these two. That's gonna be the shadow on
the right side of my bulb. If I select both Shift M to
get that shape builder tool. And now we see all
these shapes I can hold Option or Alt and just draw
through these left two sides. Now I have this piece here, which is the important piece to creating this little shadow. Once I have this piece selected, I can bring him back over
the top of this guy. And he kind of lines up
there with my smart guides. Then I can change his color
to this, a complete black. And maybe this one
will find out, but it's like 15% or
something like that. Again. Now I've got that shadow on the right
side of this bulb. To create this little highlight, all we have to do is go
back into the ellipse tool. Shortcut key is L. Create like a really
skinny ellipse like this. Instead of black will change
that fill to a white. Go back to that selection tool. We can zoom in a
little bit here, Command or Control
plus bring him over here and maybe angle him a little bit so he lines up
with the left side of that. Might be a little bit too
skinny and long there. So there we go,
something like that. And then I would
drop the opacity back a little bit,
let's say 75%. Something along those lines. That's it. That's how
we create that bulb. Now if I go ahead and
click and drag through this piece and
group it together, Command or Control G
and group it together. It may bring it to the top. If it does, all we have
to do is right-click, arrange and send it
to the back again. Notice how there's a little
glow around this guy. We can do that by
clicking on that group. The grouping was important part. Click on that group,
go to Effect, down to Stylize and then
down to Outer Glow. Once we're there, It's
going to bring this up. We need to hit Preview. We obviously want to preview it. And then we want to click
on this little swatch. And instead of
selecting a color, go to color swatches. And if you scroll to the bottom, these aren't in folders
or anything anymore. But remember we put that
folder at the bottom. These are our global
swatches down here, and this is our global
swatch for this red light, the red color for our
lights. Click on that. Click. Okay, and there we go. We've got the glow. You can adjust the opacity, you can adjust the blur to
be whatever fits your style. So we might drop the blur back to 30 on this guy
or something like that. Just whatever you want, hit. Okay, now let's zoom
out a little bit. We have our first light. Congratulations, you did it. If you want to change
the color of this light. I don't know what's over here. Oh, there we go. We've got a point. Okay,
we're gonna delete that. All right. We've got this light. We can hold Option or Alt
and duplicate him out. Here. We've got two red lines. Well, if I use that
direct selection tool and just click on this
red color here, notice how the fill
is this color. What I would do is go
up to my color panel, double-click my little
color swatch and say, okay, I want I want
this to be a blue one. I'm going to find the blue area, find the color I want hit. Okay. Now it's blue. But what I need
to do with him is create that global swatch again, because he's not in here yet. We just changed the
color to a random color. I'm going to hit this
new swatch button, create a global swatch. Hit, Okay, drag it down into
my color folder down here. And now we have those
colors, but look, it's, he's still got
that red outline. So I'm gonna go back
to the selection tool and click on this
whole selection again. And if you notice in the
appearance panel whether you go to Window drop-down appearance
or over here on the right. And the properties we have
the effects outer glow. If you click on it, you
can edit that effect. We click on the swatch, click on color swatches, and we can find that blue
swatch we just made. Hit. Okay. Hit Okay. And there we go. We've
got a blue light now. That's how you can
go through and make all sorts of different lights. Now, to create the strand, all I did was
grabbed the pen tool and start to create a line here. And I'm going to
switch my fill and my stroke here so I actually
don't want to fill. So I'm just clicked
this little slash icon. I do want to stroke of maybe let's just do
like five pixels. That color. I think
I want it to be this lighter color,
green, for instance. So I'm gonna do a green
stroke of five points. I did all that before I did
anything with the pen tool. Now with the Pen tool selected, we click and drag. We click and drag in the direction we want
our strand to go. I want him to go
out to the right in this direction. Let go. Now we actually see where
this line is gonna go. I'm going to maybe make click
another point up here and drag in the direction I
want to go out this way. We can do that to
create this strand. If you want, you could
create a little loop, de, loop part of your strand. All right, through here. However you want this
to sort of behave. We can click and drag, just keep clicking and dragging in the direction you want to go. When you're done with
that, just go back to that selection tool
and now you have this whole strand here. And one little thing
I like is I click the Stroke option and
click on the caps, round cap that just rounds the end of either sides so it doesn't cut
off quite as harsh. Now all you have to do is take your little light which
we can click and drag, select them all
right-click and group. You can take this guy and just bring him down
here along the strand. You can resize them if you want. So resize this group hold Shift while you do it
to keep them in line. Maybe something like that. Then we need to bring him
on top of the strands to right-click arrange,
bring to front. And what you might do
is click on the strand, right-click, arrange,
send to back. That way everything's
on top of it. But now we can just click on this guy and I'll
zoom in a little bit. We can rotate them
around if we need to. Insert just place him in here. All right. Just like that
as if he was on the strand. Now, we can bring this guy, he needs to be grouped
together, group them together. We can do the same thing. I'm holding Option or
Alt to duplicate them. I'm going to bring him
around and do the same. I'm gonna kind of
scale him down to, it might be I would
advise you to scale these down
at the same time, so they're the same size. But once you have one, you could go in and just adjust the colors of
them if you wanted to. But if we flip him
over like this, what I would do is click on this little flip along
horizontal axis. Because imagine the light
all coming from the left, like whatever's hitting this. I want all the shadows
on the same side. So now the shadow is
on the right side instead of just rotating him. But there you go
and you can kinda mess with the angle of him, bring him in here
just like that. String these along. Just like in the
thumbnail image. That's exactly what I did here. I hope you guys
enjoyed that tutorial. We created a strand
of Christmas lights. If you have any
questions or comments, hit me up down below and I'll see you guys
in the next one.
12. Flat Design Birthday Cake: We're gonna be creating
the birthday cake that you see here. I just made this guy and I played around with some
different options. And I think there's
a lot of really cool techniques that I'm gonna show you in this tutorial. The first thing I'm gonna do. The first thing that
you should do is open up a new document. You can go to file new for that and it's gonna pop
up the little dialog box. Now I haven't 1920 by 1080 document opened
in RGB color mode. And that's all you really
need to have set for this. And go ahead and
hit Create on that. I'll hit close because I
already have one open for me. The first thing I want to do is get all my colors in order. I'm going to select
all of this artwork I like what I came up with. I'm gonna go up
to where normally the fill would be up
here in the color, color picker selector thingy. And I'm going to add
a new color group by clicking this
folder icon here. And that's going to ask
me, what do you want to add this from wherever
these colors coming from. And I'm gonna say
Selected Artwork. I'm also going to
make sure to uncheck Include Swatches for tense. I think that might
include the swatches for the different multiply
effects and stuff like that, which I don't necessarily want. I'm gonna hit OK and that's
going to set up all of my swatches for every color that I've used in this
art piece here. Now, that's a quick way for me, but you don't have
the artwork already. So if you want to, you can grab all the hex codes from the description down below. I'll put them in there
and for each hex codes. So if I click on a, whoops, I didn't
mean to do that. Let's undo that guy. Okay, so if I click
on a specific color, Let's double-click
in here on this blue and go to the colors panel. Whenever you adjust
some of these colors, if you double-click on this guy and you pull up the
color picker down here, there's a little hashtag that's where you paste the hex codes. So whenever you want to grab one of the colors that I used, just paste it into here, and that will equal the exact
same color that I'm using. Then once you do that, you could always add those swatches, just like I did here. Now that you've got your
colors figured out. And if you need to
pause the video and go add all of those, you can. We're gonna get started. And this is, I mean, this is a birthday cake, but a birthday cake
has made out of quite a few simple shapes. There's a lot of
rectangles in this. There's some other little
things that we're gonna do. Some tricks and tips that I've figured out while
making this guy. As a matter of fact, Let's go over here and
let's start fresh. I'm gonna start on the just this gray space because it's a little hard to see on the white some of the stuff
that we're doing. Let's begin by
creating a rectangle. And we're gonna do
that by selecting the rectangle tool over here, the shortcut key for that as m. And we're going to
create the base layer of our cake. No, we're not. We're gonna create the
plate that sits on. Let's create the
plate that sits on. So it's gonna be like
a skinny long platter, I guess if you will. And we'll just create
that rectangle. And I'm going to switch
back to my selection tool. And that shortcut key is v0, the shortcut key
for rectangles M, shortcut key for selection
tool is V. I'll be switching back and forth
between those a lot. Let's make this more
of that reddish color. How about maybe this color here? And that'll be our
little planters. So let's go back to the
rectangle tool shortcut key is M Once again. And let's create that first
cake layer on this guy. And we're just going to make
him a little bit taller. How about right in here? You can kind of eyeball it. This is your cake. Make your cake what
you want it to be. Let's change this color to
more of this tarnish color. That's gonna be like No, we'll go with the yeah, we'll go with the
tanh the tan color. That's gonna be like
the color of our cake, I guess the actual cake
part and not the icing. I'm gonna shift, I'm
going to click on this guy with the
selection tool and then shift click on the platter and then click on
the platter again, it's going to
outline it in blue, and that means we are now
aligning it to a key object. You can see that up here we're
aligning to a key object. And I'm going to hit the
Horizontal Align Center. And that's going
to bring my cake just shifted over ever so slightly to make it lined up in the center
with my platter. Now, I'm going to
duplicate, duplicate, duplicate this cake layer by holding Option
or Alt on a PC. And I'm gonna hold shift
to keep it in line. And we're going to bring Up
until it intersects there. And all of these pink
lines that you see, that those lines are
called smart guides. They're very, very helpful. I would turn them on
there in the View tab down to Smart Guides, That's Command U,
Control U on a PC. And from this point let's make
him a little bit shorter. Remember this is our top
layer and we're going to squeeze him in from
the outside in. I'm going to hold Option while I click and drag those
outside edges, make sure you have
the two arrows pointing in opposite directions. And we're going to just make
this top layer a little bit shorter than the,
the base layer. From here. I like what's going on. What I want to do now though, and you will need Adobe CC
to access this feature. And I think CC 2015. But I'm going to switch over to my direct selection tool
with the shortcut key. I'm going to grab the
top right and shift, click on the top left points. So I've selected both
the top points here. You notice that I've selected them because they're
filled in with blue, whereas the points that aren't selected are
filled in with white. From here I have these little
icons that pop up there are these little corner
widget icons. And when I roll over
them, my cursor actually changes to
an arrow with a, a rounded corner in
the bottom of it. And that's because if I
click and drag these, I can actually round
those corners. And I'm gonna do
that just a little bit to each of these corners to make this cake a little more friendly and rounded
on the edges. If you're not seeing
those pop-up, you can always go up to View once again and then
there should be, yes, there's a little Hide
Corner Widget button here. It'll either say show
or hide corner widgets. So you can select
that to show or hide those little icons
that you get when you have an object selected with
the direct selection tool. Let's go up here and
select both the top points of the second layer,
the top layer. And I can do that
by clicking and dragging with that
direct selection tool. And it goes ahead and select those and we'll bring
these corners in as well. In fact, let's go
back down here, and I'm gonna select
these two points here. To select this corner,
I'm going to find out what my corner radius is. It's actually written up here. Let's make that, let's go
ahead and make that 25. That's easy to remember. And I'm gonna select these
two top points and we'll make those 25 as well. Alright, we're
getting somewhere. We're getting
somewhere, I promise. Next thing I want to
do is maybe around the edges of my
platter a little bit. But let's only do about
five pixels on that. That may even be too much. That'll be okay. Maybe we'll go back to
about three pixels. And I just want that to
soften up a little bit. I'm gonna zoom in here
just so that we can work with this cake
a little bit closer. Alright, so what I want to
do next is add the icing. What I'm going to use is something that
I've almost never, ever used in Illustrator, but that is the brush tool. And the reason I'm using
it is because this combined with the
shape builder tool, allows us to create really
unique icing effect. Let's select maybe one of
our white layers here, white colors for the icing. And I'm just going
to draw right here. And we're gonna draw
through this cake. I'm just going to kind of swoop down like we've got
some icing on there. And I'm gonna circle back
around outside of the cake just enough to come back over to this edge and you can
meet that if you want. We've created and you'll
notice once I let go, Illustrator actually smooth, smoothens out all of
those paths so that any irregularities that
I have when I'm drawing, I'm just drawing with my mouse. It actually smooths
those out very nicely. And if I double-click
on my brush, my paintbrush tool over here, it'll actually bring up the
paintbrush tool options. And I can adjust the
fidelity of this to be accurate to what
I draw or smooth. And I want that to
be as smooth as possible because when I'm
drawing with my mouse, it's, it's gonna
be kind of choppy. I want Illustrator to help
smooth out those strokes. And I'm just gonna
hit Okay after that. And I can select this
with the selection tool. And instead of a stroke, I can actually go to my color panel over
here on the right. If you don't see it, you can
go to Window Color panel. Once I pop that out, I can swap the fill and the stroke so that
instead of a stroke, I can actually have
a filled shape. And once I do that, I'm gonna go down to Pathfinder. Once again, you can
go to Window and find Pathfinder if you
don't have that option, let me go down to Pathfinder
and just for safekeeping, hit the Unite button just to make sure this is
all one nice shape. And then I'll just
minimize that. Okay, Cool. Boy, that looks
great, doesn't it? How about we do this? I'm gonna show you the
shape builder tool. To use the shape builder
tool with two shapes. I'm going to need to
select both those shapes. So let's select the bottom
layer and I'm gonna hold shift and select the icing. From there. I'm going to go over and
find my shape builder tool. It's usually hanging out
over here somewhere Here it is two circles and a pointer, shape builder tool,
shortcut, key Shift M. I'm gonna click that.
And once I have that, if I roll over with the
shape builder tool, you'll notice that it does
this little grid pattern on each of the shapes
that it's recognizing. It sees that I have these
two shapes selected and it's recognizing here's
where they overlap. What I can do with that,
you'll notice that right now my cursor has a plus icon on it. If I hold the option key that
turns into a minus icon. And then if I want to get
rid of this outside layer, I'll have to do is click on it and it completely
gets rid of it. It clipped, well,
it doesn't clip, it actually deletes that
shape and it leaves this other ships on
now for switch back to my selection tool. I actually have the icing
masked into the bottom layer. From here, I'm going
to select that icing. I'm going to scale it up a
little bit and I'm holding Shift and Option while
dragging from this corner. I'm just, I just want
that ice into go outside the edge of
the cake a little bit. I think I need to zoom in here. So Command plus and minus. Let's see, zoom in and
out really easily. So I don't want it to go
too far outside the edge. So I'm just going
to grab this and move it up about that much. For me here, what
I don't like is this sharp little
pointy edge down there. I can go back to my direct
selection tool shortcut key, and click on that anchor point. And I can use my little
corner widget to pull that in to create a much
more rounded corners. It's like that icing is in 3D going around
the edge of the cake. And I can go back to this side, click that same anchor point on this side and
do the same thing, just round that off. Now what's cool is
that icing isn't perfect and so
you're drawing with the paintbrush tool doesn't
have to be perfect and this looks pretty decent for
icing on that bottom layer. Let's go up to the top layer
and do the same thing. We'll do it a little
bit quicker this time. Shortcut key is B
for the brush tool, we're going to, I'm
going to click on this icing just so that my swatch changes
to that same color. Shortcut keys B for
the brush tool. Alright, now I'm just going
to draw through here. We'll just make some waves here. Looks good. Kind
of go like this. All righty. We're gonna go select that shortcut key V for
the selection tool, select that icing,
go to color swap it. Then we're gonna go to
Pathfinder and just kinda unite that
emerge that together. It closes in any
paths that aren't. They're still open. And from here we're
going to select the top two pieces here, the top layer and the icing. I'm gonna hit Shift M for the shape builder tool hold Option and click on that
outside icing layer. And now we've got that
clipped in there or deleted so that it's
a shape in there. I'm going to hold shift and
option scale it up a touch. And we're going to
grab that corner, pulled in a little bit
as much as we can, and grab that corner and pull
it in as much as we can. Now we've got icing on the
top and the bottom layers. While we're at it,
I'm going to add this little double layer. It's kinda like mimicking like that cake has layers
of icing inside of it. We're just gonna do that by hitting the line
segment tool over here. The shortcut key for
that is the slash. I said a forward
slash or backslash. I don't know. It's not that angle slash Actually,
that's confusing. It's that angle slash. So the one that
goes from the top left down to the
down, lower-right. And I don't know,
wasting time here. Next thing we need
to do is just use that line segment tool and draw a line all the way across. And then there's nothing. Well, we need to give
that line a stroke. So let's do maybe
ten points on that. Perfect. I liked
the white south, the same frosting color. That's what I want. I'm going to switch back
to my selection tool. I'm going to hold option. I get the double
cursor there now. And if I click on this
and I drag it down, it's actually going to
create a duplicate of that. And that's what I wanted. I wanted too little. I don't know. It's
not a swirl of like an icing layer in
there. That's perfect. Now what I'm gonna do
is actually select these two guys and go
up to Object expand. And that's gonna take
those from being strokes to be an actual shapes. I'm expanding that
stroke into a shape. So now I actually have
edges to all of that. And let's go ahead and
select everything. So the whole bottom layer here. So I've got the
bottom layer cake and these two icing things. And now that I have
those three selected, I'm gonna hit Shift in. I've got that shape builder
tool selected, hold Option. And I'm just going
to draw through the outsides of those to
kind of cut them off there. Because I want that
icing to just be on top of the cake and
inside of the cake there. Perfect, so I've got a little, too little icing layers there and I'm gonna
bring them up and touch. So zoom in Command Plus and
click on both of these. I'm gonna hold shift
to get both of them. I'm just going to use my
arrow key to kind of shift that up a little bit just to bring it away
from the bottom. Some cool, We're looking good. Actually, we've got pretty much the cake done
here we're gonna make, let's make a candle
up top candle, right? Yeah, vertex, birthday
cake, candle. All we are going to do for
that is the rectangle tool, that's M shortcut key. And let's just create a
candle shape up here. Just like that. Now it's still the icing color, so let's switch that to
maybe something more red. We've got a red candle up there. I'm going to hit that
selection tool again. And I always go back to that
selection tool a lot of times by pressing the
shortcut key V. Now I'm going to send this to the
back and I can do that by the shortcut key for
that is Shift Command, left bracket and then right
bracket to bring to front. But you can also right-click, hit a range and
say Send to Back. I just want that candle to
be behind this cake layer. I think I'm going to add
some stripes in the candle. So M for the rectangle tool. And then let's just draw
some little rectangles straight across here. I'm gonna change the color
of that to white color, maybe that icing color. I'm going to create a
couple more of these by holding Option and Shift and
just dragging them down. How about we create? I don't know, six of these are, so I did that once I did that transformation
wants what I can do now, since I did that transformation wants it to go up to
Object Transform. Transform again, I'm just gonna do the exact same
transformation down. Then if I hit command D, which is the shortcut, I can just hit that a couple of times. It's going to transform
that all the way down. Now I wanted 66 stripes,
so that's good. I'm going to actually bring
this guy down a little bit. And I'm going to select all of these and go up to my
transformation options. And instead of
aligned to art board, I'm going to align to selection. And I'm going to distribute these vertically
so that it's going to evenly space them
out from there. How about we select
them all again? Rotate a little bit. We want, obviously
for the stripes, we want those to be a
little bit rotated. And from there Let's select all the stripes
and the candle. And then Shift M for that, that famous shape builder
tool hold Option. And just draw through
everything that you don't want. I don't want anything
outside of the candle because I want those stripes
right there on that Candle. Want them to be a
part of it, perfect. V to go back to selection tool, I'm going to click off of it. And there's my striped candle. Now one thing I don't like about this guy is the pointy edges. So let's go back in there. I'm going to click
on him and then switch to my direct
selection tool. That's gonna pull up all my
corner, corner widget stuff. And let's just bump this up by using the
arrow keys to see, I think just once I think one pixels all I really
want on that candle, just a little bit of a rounded
edge that looks perfect. Be careful that you
don't round that edge too much that it brings it up. You can actually,
and you can see if you round this edge too much, it's going to bring
it above your cake. You don't want that, you
want that, you want that Canada goes straight
down into the cake. I'm going to undo
that and make sure that there's no curve
there and that's perfect. All right, One thing we want
to make here is the flame. How about a flame
at the top of the, top of the candle here? This tutorial for teaching
a bunch of stuff. I'm going to hit the L key. That is the ellipse tool. You can also click and hold
on that Rectangle tool and drop down and select
the ellipse tool. But the L key is the shortcut
key for the ellipse tool. We're gonna make a
circle by holding Shift and Option that's going
to create a circle from the center out
there right there. That's good. Let's change the color of this. So I'm going to change this to maybe this orange color.
Let's create a flame. Alright, so if you notice, when I have this
circle selected, there's four points
and there's one here, here, here and here. Let's select the top point O there you can see
the points better now. So four points,
four anchor points. I'm going to select just
the top one with the direct selection
tool shortcut key. And once I have that, I'm going to click and
drag it up a little bit. I'm holding Shift to drag it up. Right now we've gotten
like an egg shape, so we need, we need
this to be more flame. Let's zoom in a little
bit and zooming in. And what I want to do now is actually switch over
to my pen tool, which the shortcut
key for that is P. And I'm going to hold
Option or Alt on a PC. And that's going to
switch to the anchor. What's it called the
anchor point tool? I think that's the
anchor point tool. Maybe. Yep. Anchor point tool. It's going to switch to the anchor point
tool momentarily, as long as I'm holding Option, it switches to that
and I can grab that handle and then drag it down and start to
create kind of like a teardrop or a flame shape. Once I do that, it actually
gets rid of the other handle, but it doesn't really say switch back to your direct
selection tool. Click on that anchor and
that handle show up again. Switch over to the pen
tool shortcut key P. And I can hold Option or Alt to affect this handle as
well and bring him down. We've got this flame. I think I'm going to not
bring him down as much. This flame is kinda like
swooping down on this side, but a little more
rounded on this side. I'm gonna hit V. And there we go. We just created a little flame. I'm going to create that
white center of it. The white hot center of a flame, just by clicking on this shape. And we're gonna copy
with Command C, That's Control C on a PC. And then we're gonna hit
Command F to paste in front. Those options are
also up in edit. You can hit Copy
command C or control C, and then paste in front, which is Command F or Control F. And that creates a layer right
on top of my other layer. I want to do that
because I'm going to use the same shape
for that inner flame, the inner like hot
center point of it. And I can just
click and drag this down from the top
while holding shift. If I don't hold
Shift, it's going to make it all wonky and skewed. So I'm gonna hold shift
and just create down maybe to where that tip
is about halfway down the flame and let go. I need to change
the color of this. I'm going to select
something a lot lighter, like a lighter tan or something. From here. There we go. We've got the
white hot center of our flame. I'm going to zoom
out a little bit. The only thing we're
missing here is the wick. So let's create a little wick. I'm going to create a line, just a simple stroke. So we're going to use that
line segment tool again. And we're just going to create a small line coming up
from our candle here. Let's give that a stroke
of maybe 33 points. Oh, that's way too much. We'll drop that down to actually 1 for the scale that I
have everything set up at. With that stroke,
I'm going to make it more of a charcoal color. And then I'm going to actually
go to that stroke panel. And I'm gonna do a
rounded cap on that. You'll notice that that
rounds each of the ends. It's a little hard to see here. We'll zoom in on him. But each of the ends is now
rounded on that stroke. I like that shape a lot. So what I'm going to
do is go to object, expand and just fill
in that stroke. So now it's an actual shape. But I do want him to
be behind this candle. So I'm going to select
him right-click arrange and send to back. But I also want him to be
in front of the flame. I'm going to
right-click the flame. I've selected now I've
selected both of these. Let's go ahead and group
those two together. So we're going to
select both the flames right-click and
group them together. And we're going to send him to the back as well by going
right-clicking on it, arrange and then send to back. There we go. And we're
just going to maybe bump this down a touch. And that looks pretty good. We've got a wick and a flame. I think they had flames
like little too big. So we'll select them again. And I'm just going to
hold shift from the top here and kind of bring him
down in size a little bit. Bump him up with the arrows. Human not and that's
a little too much, so I'll just kind
of drag him down. There we go. We'll see if that flame
looks a little bit. Yeah, it does. I think
there we have it. We made a birthday cake. The only thing left
we have to do is the background and the shadows. So let's create a background. I'm going to go back to my ellipse tool shortcut
key for that as L. And then somewhere
in the center here, I'm going to intersect in
the center of everything. I'm gonna hold shift
and option and create a circle from about
there in the center. Once I've got it
about the size I want it to be, I'm
just going to let go. And that made it whatever
color we had selected last. So let's change that to some
sort of a steely blue color. From there, we're
going to send him, he's got to go all
the way to the back. So we're going to
send him to the back. But right-clicking go to
arrange and then send to back. All right. We're getting close. You guys. I think he's maybe a
little off center. Let's just bring
that circle down, some center, that cake up. And I think we're also
going to go ahead and group all of
this cake together. So right now it's a bunch
of separate elements. I'm going to select everything, deselect this circle by holding
Shift and clicking on it. Now I'd have just
the kick selected. I can hit Command
or Control G to group it or I can
right-click and hit Group. Now that I have it grouped, no matter what I select, that group is going to
move together as a unit. Now that it's centered up, I'm going to select both
of these and right-click. I'm going to select
everything and then click on the circle. We're going to hit this
horizontal lines center button just as you saw. Nudge it over just a little bit, just want to make sure
that's in the center. Then I'm going to eyeball
the vertical center. I kinda like where
that is, right there. Alright, let's create a shadow. I think the first shadow
I'm going to make is the shadow on the
entire cake layer. And I'm gonna do that by copying this remember object
or I'm sorry, Edit, Copy, Control
Command or Control C. And then we're going
to paste in front with Command F. It doesn't look
like I did anything but I did, I made a second layer of that
cake right in front of it. Now what I'm gonna do is
actually double-click on that. I'm inside of the cake, the top cake group layer. Now I can select all of these objects because
I haven't isolated. You can see I'm on layer
one inside of this group. I've got all of these
elements isolated. What I'm gonna do is
interesting here, I'm going to actually use the rectangle tool and
that's shortcut key M. I'm gonna draw a rectangle, make sure it's big enough
to cover your entire cake. But then I'm only
going to bring it across half of the cake. To about there. I don't really care
what color that is. I'm going to select all. That's underneath. Select all or Command a or
Control a to select all. I've got everything,
all these cake elements and this big old rectangle selected Shift M for that
lovely shape builder tool. And notice that I've got
all of these shapes. Let's get rid of everything
on the left side. I'm going to hold
Option and just draw through everything that I don't want while holding option. So I've got all these major
shapes taken care of. Let's zoom in a little bit now. This candle, and we'll
do the same thing, shift M and then hold Option and draw through all the
shapes that we don't want. There's a couple
more in here, so let's zoom in here again. That's a shortcut keys
x0 for the Zoom tool, you may have a scrubby zoom
or you may have the zoom to selection like I'm showing
you right now where you just draw on
it zooms to that. I've got this wick in here, and I really need to get rid of the left side
of that as well. So hold Shift and M, just draw through that while
holding Option or Alt. And there we go. So I've gotten rid of who will zoom out here, gotten rid of the entire
left side of everything. I've got this layer of
just the right half. The reason I did that is because now that I've got this
right half layer, all I need to do is go to
transparency and switch that the blending mode to multiply to create a shadow on the right side of the cake. From here, I think
that's a little harsh. So let's maybe drop
that back opacity. And actually you can
grab opacity and the transparency panel as well. That may be mixed a
little more sense hit seventy-five percent just to pull that shadow
back a little bit. I don't want it
to be too strong. There you go. There's
your shadow of your cake. All right, We're almost done. If you want to stick
with me, I'm gonna show you how to
create a long shadow. And another tutorial showed people how to do it
with a blend method. This one, I think I'm
gonna just gonna do a quick shape building
method with the pen tool. So I've got everything
selected here. Let's, let's get rid
of some of this. So I'm going to lock
this in with Command to you can also go up
to I think, Object. Yeah. And then lock selection. I'm actually going to just grab everything and lock it
with command or control. To. Now I cannot grab anything. Everything is locked in and I can't accidentally click on
something, I don't want to. But because I have my
smart guides enabled, notice how it recognizes all these anchor points
and the paths are, I can go in there
and create a point right at the very tippy
top of this flame. Create a point there.
Then I can create a point in the
bottom left corner. We'll create it somewhere. You don't want that will
create it somewhere down. Just along this edge here,
maybe right in there. I've got those two
points created. I'm going to switch back
to my selection tool. Shortcut key is V. With this, I want to
duplicate this out. So I want to have that selected. I'm going to hold
Option and duplicate it out outside of our
circle background. Once I have that, I
basically have two objects. Now I've got these
two parallel objects. It's the most important
part right now is that these two are parallel. Now that I have
that, let's go back. Let's hit P for the Pen tool. And I'm going to
select this anchor. You'll notice the slash
underneath the Pen tool. It means I'm gonna
continue on this path, select that anchor,
and then let's combine it with this
side over here. Once I do that, it may fill that in
automatically for you. As long as I have three
points that it will. Let's change the color
of this so we can see it maybe something more like a really light gray color or maybe something
in the middle there. And it's just a gray
just so you can see it. This path isn't closed. So I'm going to go ahead
and go to pathfinder, that Unite button or
merge one of the other. We'll close this as one shape. Let's see from here actually let's go ahead
and create a gradient. How's that? Will create a gradient shadow, not just a shadow but a
gradient long shadow. I'll have to do is
go to gradient and click on this gradient area. This is already set,
this is already set up. I'm going to switch this
back to what you'll find. You're gonna find this
being like a white to a black gradient. And there's the gradient tool over here in the tool panel. I believe the shortcut
key for that is g. You see the gradient here,
that's the gradient tool. You see this bar here. You can actually
redraw the gradient. So I could click in
the top here and then draw down at this angle to redraw the angle of the gradient and where the
gradient starts and stops. Now I want this to be
from black to white. So how about I just
switch these two colors? I also don't want it
to be as stark black. So let's double-click
on that black. And we'll go to maybe
something more like 40% black. And then this white is fine. The other thing I want is for this shape and I'm going to go to my selection tool and
just select that shape. I want him to be multiplied. You can see now where the shadow is going
to becoming from. It looks kinda wonky,
but that's okay. What I want to do now
is unlock everything. So I'm gonna go up to
Object Unlock All. That's also option command
to or control command to. Once they do that,
everything's back in play. All of these elements can
be moved and whatnot. Now I don't want to move
them all at this point. What I do want though, you can see how this is actually not going to be
the shadow that we want. I need this shadow
to start here. And what is this? This, there's no shadows and nothing casting a
shadow over there. So I'm going to add a couple
more points to our shadow. As long as my shadow selected, there's a little plus
icon that pops up. I'm gonna hit Plus there. I'm going to hit plus
here and I'm gonna hit plus down here. And then I'm going to switch to the Direct Selection tool
with the white arrow here. And I'm gonna click on that
point and only that point, notice the other ones are not selected, they're still white. This one is filled in. Then I can click and
drag and just drag that point directly
below the candle. And I can do the
same thing here. I can drag that in to
make sure that shadow doesn't crossover
anything behind the cake. And same thing down here. We'll just make sure that that doesn't go behind the
cake on the left side, we want it behind on the
right but not on the left. There's another thing happening
down here and I think I'm going to change how
this platter is set up. So because I've got rounded
corners at the bottom, there's not a good spot to
really start that shadow. And I'm gonna select this guy. And we are going to actually, we're actually
going to select him with the regular selection tool. Just have him selected. And we're going to
double-click on him. And then I've got him isolated or I've got the
whole cake isolated, but at least I won't select
anything on accident here. So I'm going to use the direct selection tool to select all of the bottom points. And we're just going to get
rid of the corners on that. So I'm gonna go back to 0. So that's gonna be rounded here, but then flat at
the bottom there. And I think that
that's gonna be more like the platter and where
it stops right there. Now I'm going to
double-click out of this and I think one
thing we need to do, Let's go ahead and let's go ahead and
finish this shadow out. Let's go ahead and
finish the shadow. So I'm gonna hit Z
and I'm going to zoom in here a little bit. And this shadow actually
needs to be parallel. So anytime I move one
of these two points, this point or this
point up here, what I actually
want to do is move this entire line segment because I want it to be
parallel with this one. I don't want to affect
the angle of this guy. I need to select this point, and I need to select this point by holding Shift
and clicking on it. So now I've got
the two selected. I am safe to zoom back
in and sort of move this path till that
anchor point intersects with the bottom left
of our plate here. Once it does that, I've actually moved this
entire line segment, so we're still parallel
with this guy. So that's all good and
that's all fine and dandy. We're looking pretty good here. There's one mistake that we're gonna correct
and then I'm gonna show you how to get this
shadow behind the cake. What are we going to do is take this shadow layer and I know
it looks weird right now. We're going to fix that. I'm going to send
him to the back, arrange send to back. Then I'm gonna take this
background layer and we're going to send him to the back
because I want him to actually be the furthest back. That's looking pretty good. So before we clip
this shadow in here, Let's zoom in and fix
one little problem. It's hard to see. But when we unrounded our corner
of our platter, we didn't and round the
corner of the shadow. We need to double-click
in on that shadow layer. And then a for the
direct selection tool, select this and get
rid of the corner. We can pull that all
the way down or we can select 0 up here on corners. And then I'm gonna hit
that selection tool and double-click outside of that to go back to
our main canvas here. And that's fixed that. So I kind of liked that better and I like how the
shadows go from there. What you can do is define
the angle of your shadow. And to do that, you just the direct
selection tool, select both of
these points here. And because, and that's
because you want to keep this, every time you move
any of these points, you want to keep
this parallel with this or this segment
parallel with this segment. But as long as I
keep that parallel, I keep that shadow
inside of the cake. I mean, I could bring
it down if I wanted to. It's up to you whatever the
angle is that you want. But I think that
you want to keep that shadow above the cake. So then above the platter. So anything from here all the
way down to maybe in here is where I would
probably move it just based on other flat
artwork that I've seen. But you can find your angle
of the shadow that you want.
13. Flat Design Heart: The first thing I want you to
know is that we're going to use the technique not
available in CS6. So this will be CC or later as long as you have the
rounding corners tool, we'll start with a rectangle
and I'm just going to create sort of any sort
of size rectangle. You'll understand and
be able to create your own here and adjusted
if you want. Now, I'm gonna take, after I created this rectangle, I'm gonna take the
direct selection tool, click and drag to select
the top two points. After I've done that, I
should see the corner widget on those two points
and I can just click and drag to pull those in. I'm gonna pull them in
until it shows red, which means I can't
pull those in anymore. It's going to create a
little half circle along the top if you don't see
the corner which it go up to View and then down to
hide or show Corner Widget. And if you're in
CS6, like I said, you're probably not
gonna see it at all. Okay, So we've done that
much now what I can do is maybe swap the
fill and stroke on this, Get rid of the stroke. Probably I'm just going
to type in 0 there. And for the fill, Let's
go with a red color. And actually this is
a little bit too hot. I want to more flat
design and flat color. So I'm gonna pull
it down into here. I just double-click
this swatch over here and it brings
up my color picker, make it a little
bit more grayish. And that's going to be
a much more muted tone. I'm gonna rotate this guy to the left 45 degrees by holding Shift and clicking and dragging with that
double ended arrow. And then I'm going to
duplicate by holding Alt or Option also hold Shift to keep it in line,
straight horizontal. Duplicate that
piece right there. Now, I can actually
just rotate this guy back around 45 the other way. And you see where
we're going here. Click and drag hold shift until it locks almost into place. It actually might not lock
very well into place. So we're going to want to
zoom in on this guy That's Command or Control plus and
minus to zoom in and out, I'm gonna click this top
layer and just drag him over until I feel like he is
flush with that edge. And that's going to make this
edge over here the same. Now we have a heart, and depending on the
size of your rectangle, this heart is going
to look a little bit different each time. I'm just going to
stick with this one. We're going to select
everything because right now it's made
out of two shapes. I'm going to grab my shape
builder tool over here. Shift M is the shortcut key. I'm just going to click and
draw through this real quick to combine all of
those shapes together. Now we've got a heart that's a single, single element here. What we could do
is if we wanted to add back in some
kind of a stroke, we could add in a line
around the heart. If we want, we can add in some shading on one side so we could add
another rectangle. I'm gonna make this
rectangle a darker color. Hit. Okay, and then I'm gonna
draw this so that it locks into the center. And my little pink guides, our Smart Guides go up to View, down to Smart Guides to
turn those on and off. Once I have this drawn, I can do the same thing with
that Shape Builder Tool. Remember Shift M,
I can subtract out this outside part by
holding Alt or option. And now I have a slice the
size of half of my heart. What I can do is just turn
the opacity down on that guy. Maybe like 10%. That's gonna give you a nice
little ten or 15%, a nice little shadow on
one side of the heart. I suppose the last thing
that you could do is maybe grab a pen tool, for instance. And we could click here and then click and drag down here to
create sort of a curved line. And if we try to
match the curve or the arc of the
outside of our heart. And then go back to
the selection tool. We want to swap the
fill and stroke here. We don't want this to be filled. We were actually want
it to be a stroke. So I'm gonna click
this swap fill and stroke button that's Shift X. I want to bring
that stroke up to maybe something
like five points. Change the stroke
color to white, and then change the stroke
settings to round cap. It's going to round
the two ends. And we could actually make this maybe more like ten points. And that's gonna give
me like a little shine, a little highlight on that
upper side of the heart. And if we don't want
it to be full white, we can always bring
that opacity down. Something like 75% maybe would be a little bit
softer of a highlight.
14. Flat Design iPhone: This is the flat design phone mockup we're gonna do today. It's simple, it's pretty basic. We got a little bit of a hint of a shine on it and
some shadow there. So let's go ahead
and get started. It's pretty easy, really
when you break it down. It's just some simple shapes. I'm going to start a
new document so we can start this thing from scratch. It's gonna be 1920 by 1080 only because it's just a
pretty standard size. Alright, so we need
to make a rectangle. That's pretty easy, right guys? If we go over to
the rectangle tool, the shortcut key for that is m. We can just create a rectangle. This is gonna be the
shape of our phone. Phones are a lot more vertical
than I thought they were. So maybe something like
this is going to work. We're just guessing. And then in the appearance
panel over here, anywhere you find, Fill and Stroke, we've
got to adjust these. I'm gonna do no stroke. So I'm actually just
going to maybe put a 0 in to this box here. Hit Enter and it's going
to put a slash there. Strokes, we have no more
stroke on the fill. I want it to be black, but I actually
don't want it to be the starkest of blacks. So I'm going to go
up to the color tab, which you can go up to
the Window drop-down, down to Color F6
to pop that out. If I click on my fill
and select it as the primary color that we're editing and then
double-click on it. This is my, this is just my
favorite little color picker. If I drag this circle
over to the left, I'm not gonna have
any color in it, it's just gonna be
black and white. Now another thing I like
to look at when I'm over here Is this a
little b right here? It's kind of a trick for me. This means 85% black, so it's sort of the reverse
of what we're looking at. It's as if it's 15% white
is applied to this. So what we're gonna
do here is maybe set the phone color to something
like 10% right here. And that's gonna be like in 90% black has a lot of explaining
for that little piece, but that's the way I like
to think about it when I select blacks and stuff. So now we have this rectangle
in our phone shape. If you have Adobe Illustrator
CC 2015 or later, you're going to have
the corner widget, which is in the View drop-down, down to hide or show corner widget we
haven't shown currently. So we see these little dots in the corners of our rectangle. Just click that dot
and pull it in. It's going to round our corners. I'm going to round them
to be maybe about 2525, 27 pixels, something like that. Something just to have
slightly rounded corners, maybe a little bit more. Maybe we'll do
something like 30 ish. And we can actually set that in our Properties panel in the
transform dialogue box, which once again, you can also find in the Window drop-down. If you find transform, it's going to pop that out
and its own dialogue box. We have all the advanced
properties shown. It might require you to
click on the hamburger menu. But once you're down
here, check this out, There's corners and
we can actually set the corner radius
to a specific number. I could do 30, as long
as this is linked, they will all change. As soon as I click out of that, I'm going to minimize
this and we have rounded, a rounded rectangle. So this is starting to look
more and more like a phone. Let's add the screen
with another rectangle. So we're just going
to create something in the center of this guy. Given us a little
space for the bezels, doesn't really matter, just create a rectangle right there. We're going to adjust
the fill of it, make it something like just, let's just go with
white for now. And then backup to the selection
tool shortcut key is v. Let's center this first. So I'm gonna select
both of these. And then I'm going to click
on my black phone rectangle. From here I'm going to find my Alignment panel, which
is down to the right, but first up in the
Window, drop-down, down to a line, you can pop that out if you can't
find your panel. Now since we clicked on this and it's highlighted in
a double blue stroke, we can actually align to it. So we're going to align horizontal and vertical just to get that rectangle
right in the center. Once we do that, we're
pretty good to go. I'm going to decrease the bezel on the
left and right just by increasing the width
of our rectangle. And I can hold Alt or Option to increase it
from the center out, which allows us to keep it in the center and increase the width on both sides
at the same time. Now at this time I'm
going to maybe give us a little bit more bezel
on top and bottom, just by clicking on the top and decreasing the height of this holding Alt
and Option as well, just to give us a little bit
more up here and down below. And at this point, if it's starting to
look like an iPad, Mini, not a phone, what we can do is just
go to the law actually, since we don't have any
shapes that matter, as far as the skewing of it, we can just select both. We can do the same thing. We can pull in an
edge just to decrease the width of our entire phone and create more
of a phone shape. Phones are way more vertical
than I thought they were. Now we're gonna do the button on the bottom with the
rectangle tool. Once again, we can click and hold that and find
the Ellipse Tool. The shortcut key for that is L. If I hold Shift
and Alt or Option, I can create a circle from
the center out, just like so. We want to create a circle
that's not too large that it can fit down here below
in that bottom decile, this circle, we want him
to be filled with black. I'm going to go up
to my color panel. Remember F6, to pop that out, I finally remembered
that color picker. Let's go down here. Remember how we picked
a color that was, Let's see, I don't
know what we picked. We picked ten for that. So for this one maybe
we're gonna do five. We want it to be darker
than the phone itself. So now that we have that, we're going to select
this and maybe drag it over the
top of this phone. You see this little pink
line that's a smart guide. Smart guides are pretty helpful to align your objects together. Underneath the View drop-down, we can turn on Smart Guides
if they're not already on by clicking smart
guides right there. We've got the button down there. I think the background color of our phone is a
little too dark, so I'm going to click on it
again, double-click that. And then instead of
like eight or 9%, we're gonna do something
like maybe 13%. See what that ends up. Once we do that, we
can actually see this other circle a
little bit better. Now, I need to, I
need to center him between these two points here, just on this bottom bevel, but this whole shape
isn't going to help me. So I'm gonna create a new
shape that's going to be sort of like a guide just
with the rectangle tool. I do this all the time. I'm going to align it up here
so that it's linked into the world that the path, you see, the path right there, it's going to intersect that. And then I'm going to
create just a rectangle that hits the bottom
of our phone. Got it there. I'm going
to just slide this over to green so we can see it. And now I know that's
not a piece of my, that's not a piece
of my artwork here. I'm going to click on
this circle hold Shift, click on this green rectangle, let go of Shift and click on
the green rectangle again. Now we're aligning
to that key object. We find our alignment panel window drop-down if you need it. And vertical lines center, it's gonna bring
that circle down. And then we already lined
it up to the center of everything with our
smart guide earlier. So it's right here
in the center. I'm actually going to
bring this guy up to the top because I
know this top part is the same size and I need
to get it locked in there. If I'm a little
worried about that, I can just go ahead and
decrease the size of it and increase the size until it locks into the top of our phone. Same thing here to it locks into the top of our
screen portion. And I can keep this
rectangle right in here for now because
we've got to create the, actually, I don't really know
what this is. What is it? A speaker and a camera and all the gizmos and
gadgets up here. We're gonna do that with
the line segment tool. Click on the line segment tool. It's a little slushie button. We're going to create a line. I'm gonna hold
shift to make sure it is perfectly horizontal. We're gonna let go right there. Alright, so it's
given me no stroke, no stroke and no fill. I need to add a stroke to this. And this stroke should be the same color as
this guy down here, which as we recall, if we just click on a color, as we recall, it
was about 5% black. I think if we go back
up to our color panel, click on the stroke and
then double-click on it. We can bring this over here and set B here are black to 5%. Hit. Okay? And now we have a tiny
little stroke there. I'm going to just
guesstimate here. Maybe five pixels
are five points. You guys can choose
whatever size you want, whatever it looks the
best for your phone. I'm going to go back to the stroke settings here
by clicking on stroke. And I'm going to round the caps. It just creates a nicer finish, a little cleaner look. We're gonna go back to
the Selection tool. I've got my little speaker here. We're going to center it
on the phone by clicking both are shift clicking both
the speaker and the film. And then we're gonna
click on the phone. And that's going to
highlight it again. And we're going to
use the horizontal align center to center that. And it looked like it
was already in there. So that's good. Now we want to center it
on this little guide here. So I'm going to Shift,
click on both of these and then let go of Shift
and click on our guide. A lot of aligning
to key objects. So this time we're going to
align the vertical to put it right in the center
of this top decile. Now that we have that in
there, we're pretty good. So we can delete
this guide piece just by clicking and
hitting the delete key. And let's go ahead and
zoom in a little bit. That was Command or Control plus and minus to
zoom in and out. And then hold shift, I'm sorry, hold space bar to get the little hand tool
so you can move around. So this might be a
little bit wide. I'm going to click on it and
then hover over this point. Click on that anchor point, hold Option or Alt, and Shift to drag it in and out. You see how we can just skew
it in and out like that. So I'm gonna make
it a little bit smaller, maybe like that. We need the little camera and
then maybe a little dot up here for whatever that
is on your phone. Alright, so let's
create a little circle. I'm going to create it with the ellipse tool,
shortcut key L, hold Shift and Alt or option to create a circle
from the center out, maybe something like that. Now because we have
this selected last, it went ahead and did
the stroke for me. I can actually flip these with
this little swap fill and stroke icon that's Shift
X as a shortcut key. And so it's gonna take
that stroke color and just make the fill
color and no stroke, It's going to just swap
them exactly what it says. Okay, so now we need this little circle
to maybe be a little bit left of our
speaker, like there. And then I'm gonna hold shift
and click on the speaker. So I've got them both selected. And then let go shift click on the speaker aligned
to key object, you know the drill. Alright, Vertical Align, Center, boom, right there, right there like that,
That's pretty good. Then I can actually duplicate
this guy by clicking on them holding Alt or Option. And I'm not zoomed in enough
like barely to select that. So this is where like a
command plus Control plus zooming in is gonna be
helpful because now it's not getting messed up
with the edges of my shape. I can hold Alt or Option
and duplicate this guy out. Let my smart guides tell
me where the center is. It's somewhere right there. Then once I do that and let go, I'm gonna grab this top corner. Start skewing it, hold
Shift to keep it in proportion and then hold Alt or option to keep it
from the center out. This guy is pretty small, so we're gonna make them
kind of tiny like that, but maybe not smaller
than my line down here. Something like that works. Let's zoom out and
see where we're at. Let's zoom out and
see where we're at. That's a pretty decent really. What we can do now
is maybe change the color of this shape. So this is our screen
and it looks right now like it sees through
to the back of our page. Let's change the First off, let's change the opacity. If we go to the Appearance tab, which is of course in the Window drop-down
if you need it, we changed the opacity
is something like 50%. That's gonna pull a little
bit of the darkness of the rectangle
underneath through it. So now we have sort of
like a gray screen. I like adding just a little
bit of color into it, I think so if we go back
to our color panel, remember F6 is the shortcut key. Double-click on that fill. Maybe we want just
like, I don't know, just a little bit, just a little bit of color. And this is sort of like a
little bit of red, orangeish. I'm adding to it Not much. Do you see the difference here? This is before. This is after I'm gonna hit OK. And it's just, it's just a
little some added in there. Alright, so that's pretty good. We got this screen color in there and we can always
adjust that however you want. I'm just showing
you how to do this. You guys can adjust and make your own phone in
whatever way you want. So let's go ahead and do
the reflection up here. That's the right word for it not shine, it's the reflection. Alright, so I think
the easiest way maybe here is to go grab the pen
tool shortcut key is P. I'm going to create
a point out here. I'm going to create a point
somewhere randomly over here. And then we're gonna
create a point down here. And this is going to dictate
where it crosses over. I wanted to maybe be like just this upper
left-hand corner there. Then the last thing I'm gonna
do is close up this path. Not not anything too complex with the pen
tool didn't hold Shift. I just clicked three points
and made a triangle. Now I'm going to go back
to the selection tool. This time we're going
to select everything by clicking and dragging
over everything. And now you see where that
reflection is going to be. We use that shape builder tool
Shift plus MB hold Option. And my little cursor is going to switch from
a plus to a minus. We can just click on
this outer shape. That got rid of that. You can go back to
the selection tool. We can change the color
of this to maybe just a full white if we
want, just like that. And then the opacity,
we can take that down. I don't really know
what it should be. Maybe 5%. We don't want much, just like 5% or so. We're pretty much there. What we need is maybe a
background and a shadow. What I'm gonna do is
just create a rectangle. The shortcut key for that is M. It's right here. By the way, we've used it all
throughout this tutorial. I'm going to kind of create
something like a background. This rectangle is going to scale the entirety of my
background art board. And then I'm going to
change the color of it. I think I like blue, like we did in the thumbnail. So we're going to
double-click on this fill. And then I like it maybe
something like a blue or green. I don't remember now,
let's make it green. Something like
this. It's gonna be like a little minty green hit. Okay. Something like that. Yeah. Okay. Now this shape is on
top of everything, so we're gonna click
on it, right-click. Arrange, send to back, and you can use that
shortcut key like I do, or you can just right-click
once we have it in the back, an easy way to lock in
backgrounds is to click on them and use Command
or Control to, to lock it in. You can also go up to object, down to lock, to lock
whatever object is selected. Now we need to add the shadow. I used to do this
with the Blend tool, but I'm not doing that anymore. I don't like it. Let's just do something pretty
easy with the pen tool. So grab the pen tool, I'm going to hit on wherever
the corner of this phone is, somewhere, somewhere in here. And then I'm gonna hold shift. And you see that
we're doing like a 45-degree angled down here. I'm gonna go off
the art board and click Space-bar to sort of move my screen
down a little bit. I'm gonna go 45 from this
guy as well down here. So it's past where I
think 45 would hit, coming down from
the other corner. Maybe like down here. Now we have that piece. And what I need to do now is get off the pen
tool by hitting V. That's the shortcut key
for the selection tool. Click off of it and I'm gonna do another shape or
another line here. So P for the Pen
tool once again, go to this corner. Click. That's my first
anchor point hold Shift, and I'm going to go past
my shadow right here. Just like that. So
now I have that line. That's all I really needed. Back to the selection
tool shortcut key V, select both of these objects and utilize the shape builder tool. Got it. Okay, So I want to
slice off this portion. So hold Option or Alt, switch that to a minus click. Okay, so it's gone right there. Now that I have an
anchor point right here, what I can do is actually just get rid of
this little line. It was almost like just a guide. You can delete him. And now this shape has the anchor point
I need right here. So I'm gonna switch to
the direct selection tool to just grab this
one anchor point. We're going to move him. And if I don't hold Shift,
I can move them anywhere. So I got to hold Shift to
keep them at 45 and he should line up right with the corner of this
phone right there. That's one way to do it. There's about a million
other ways to do it, but hey, that's
one way to do it. This guy, we need a
shadow color obviously, but I want to do like
a gradient here. I'm going to find
my gradient tool, maybe just by going up to
window down to gradient, that's the gradient panel. If I just click on
this gradient slider, it's going to apply a gradient. I need this to be from black to black, not from
white to black. So I'm going to double-click on this color, select that black. I'm also going to double-click
on this color and select the same black just to make
sure we have the same black. Now, this end point here is
gonna be an opacity of 0. So we're going from
black to black, but from a 100% to 0% opacity and click out of that
box to apply that. Now the other thing
we need to do is adjust the angle
of our gradient. I can do that by grabbing the gradient tool which
is right over here. The shortcut key for that is G. Now I can actually see where this gradient is applied
from left to right. Everything is left to right. I could click up here, hold and drag my gradient down, which the latest update has
this awesome preview feature. It's pretty cool. All right. I hold shift. It actually doesn't lock it into 45 degrees. That's a missed
opportunity by Adobe. So you can just kind of eyeball your 45
degree angle here. I think I'm gonna have
this go off the art board, just barely, just
something like that. Let me just show you here
where you can adjust where this falls off by using this little slider right
here to adjust where the, how steep or how quickly it goes from 100% opacity
to 0% opacity. Then the other thing
we of course can do, if we go back and maybe
zoom out a little, we can click on
this entire shape and we can adjust
the opacity of it, which will need to maybe
down to twenty-five percent. We don't want that full
full-blown shadow. Last thing we need to do
here is send it to the back. So we're going to
right-click on it. Go down to arrange,
Send to Back. Now it's behind my background so we need to bring
it forward one spot. So right-click, click on it. Right-click. Arrange should
be bringing forward, not bring to front,
bring forward. And now we're on top
of the background. Now I actually would
rather this have an effect the background
a little bit differently than just the opacity
of the black. So what we can do is click
on our little opacity tab. Now, this is gonna be under Window appearance if you
can't find it or you don't have it over there
in the Properties panel. And on this we need to
look at the fill opacity. When you click on that opacity. Once we do that, we can actually select a blending mode here. The blending mode, I think
I'm gonna pick as soft light. And then it looks like
it got rid of it, but just hang on a
second so we can go out of this backup of
the spec out of this. It's there just a little bit. We might need to pump that
up a little bit more. And it looks like we messed up the opacity here, which is fine. What we can do is
open that window appearance panel back up
and we can adjust it here. So the capacity
is actually here. We sort of screwed it
up, but that's fine. This appearance panel is
going to show you everything. So I'm gonna click
on this opacity. And we can bring this up
to something like 50%. And that's going to help pull this shadow out a
little bit more on our, wherever our background is, it's gonna kinda see
how it's sort of tweaks the color a
little bit more than just the darkness of the
black gradient does. I think we did it right? And then we can grab all this. We can right-click it and
we can group it together. Now that it's grouped together, no matter what I click on here, it's all gonna move together. So you can do this with
or without the shadow. You could describe the
whole phone and then you'll have the phone as a single group that you can move around
on your on your document. I hope you guys enjoyed that. If you have any
questions about it, let me know this
flat design stuff, really it's just
looking at whatever, wherever your thing is
and then breaking it down into the most simple
elements that you can. And you can add, you can add more
strokes to this. You can add a gradient
to the button to make it look a little
bit more realistic. But it depends on what level
of realism you're going for. To me. Flat design, it's all
about communication. If I can do that in a
single color shift or color change with two shapes
laying on top of each other. And now that circle
is a button instead of having to do an outline
and a gradient and all that. Then, then that's
what I like to do. That's a personal
preference for me. I hope you guys learned
a lot in this tutorial. Thanks for watching and I'll
see you guys next time.
15. Flat Design Pilgrim Hat: And we're gonna be making
something like this right here. It's like a little
Pilgrim hat thing. Let's get started. I'm gonna come over to the side, not that side, and
maybe this side. Let's keep it on screen
a little bit and just model everything off of
this first one that I made. It's gonna be out of
shapes and everything. So let's start with
the shape tool, the ellipse tool, specifically the shortcut key for that is L. You can get to it by clicking
and holding and going to the Ellipse tool in the shape tool over
here on the left. I'm going to click and drag
and I'm gonna make an oval. And this is the
bottom of the hat or the brim, if you will. Now, whatever color it shows up as it will likely
be black for you, we're gonna make it sort
of like a slate color. So I'm gonna go to my color
panel up in the Window, drop-down, down to color
that's going to pop this out. It's also F6 as a shortcut, I should remember that one. I like to double-click
on this fill right here. And then I can select with this color picker whatever I want. Let's do a slight color, maybe 20% black right there. I'm just looking at
this B right here and till it said 20% hit. Okay, there we go. It's a little light,
but that's okay. All right, Now the next thing
that I want to do is create from the center
out another oval. So I'm going to select that
ellipse tool once again, click and drag from the center. And apparently that
moves that guy. So I'm gonna go a little
off center right in here. Click and drag to
make another oval. This time I'm going to
hold Option or Alt, and that is going to create
it from the center out. I'm going to try
to get somewhere into that sort of cone shape on top of this, this hat. And let go. There it is. Let's
center this guy up on the brim of the hat. Go back to the
selection tool shortcut key is V, select both, then click on the brim
or bottom of the, heck, I think it's
called a brim, right? That highlights it.
That means we're aligning to a key object. Now I'm gonna go up to window, down to my Align panel, get that to pop out and have all these little options we're
aligning to a key object. I'm going to just
center it up like that. And then also make sure
that it's centered this way, like that. There we go. So now
we're in the center. I'm going to select both. Again. Go to the Shape
Builder tool that is Shift M. It's my favorite tool. I'm going to hold
Option or all until that little cursor turns to
a minus instead of a plus. Click and drag through this bottom shape
and it goes away. Okay, so if I go back to the
selection tool shortcut key, now I've got this sort of shape. It's looking good. Let's create the little belt. We're doing this out of
shapes and I want it to have the same arc as the
bottom of this hat. I clicked on the
bottom of the hat. I'm going to hold Option or Alt to that double arrow pops up. I'm going to click
and drag upward and hold Shift at the same
time to keep it locked in. And we're gonna drag to where
we want the bottom of, the, top of the hat to end
up some maybe right in here would be good. I'm just eyeballing this. We're looking at the bottom
here because that's going to make the bottom of this. And then we're going to do
the same thing to this shape. Click and drag up while holding Option or
Alt to duplicate it. And we need to make
the size of the belt. So I'm just going to let it lock into the
center right there. Okay, this looks
super complicated, but basically what we have if we click and select all of this, the shapes are in there,
they're in there somewhere. So we need to hit Shift M to get back to that shape
builder tool and when you start cutting out our shapes, so all these things on the side, notice how I have
everything selected. If I just hold Option or Alt, remember I can click and drag
to minus out these shapes. I'm gonna do that to that side. And I'll do it to this side, all these extra
pieces we don't need. Now, you can kind of see where that belt around the
hat is gonna be. It's gonna be right there. So let's go ahead
and get all these merged together up top here. I'm gonna click and drag
through these top shapes, stopping when I reach the top of the belt
and I'll let go. Now I have a top shape. I'm going to click
and drag along the outside of where
the belt should be so that we now have
that bottom shape. Now, this might require a
little bit of zooming in. So Command or Control
Plus to zoom in. We're going to look
into this really close. I'm going to select both again. And notice we have these
little corner pieces that I need to be a part
of the belt as well. So I'm gonna hit Shift M. We're back on that
shape builder tool. And I'm going to
carefully click and draw through the corner piece, the bigger belt piece and
then the other corner piece. Once I've done that, I let go. And now we have three pieces, the top, the belt,
and the bottom. Let's zoom back out. And I'm gonna switch
over to switch over to the selection
tool shortcut key V. And now I can select these pieces independently
of each other. I'm going to select the belt and we're going to pick a color. Let's go up to that
little color panel. Remember it's in the Window
drop-down if you need it. I'm going to double-click
on this guy here. And as long as we're sort of in the orange hue around here, I'm gonna select something. Select something maybe a
little more red tint to it. Something like this,
maybe right in there. Hit Okay. And there's our belt. We need the buckle,
little buckle. Alright, so let's do that, But actually let's
get it a little more red like this one. So let's do, let's go back
to that color picker. I'm gonna go a little
bit more red and a little bit more
muted right in here. Something like that
little peachy color. We need to create this
little belt buckle. We're gonna do that with
the rectangle tool. The shortcut key for that is M. I'm gonna create a rectangle about the size that I want it. There it is. It's just pulled in the same
fill is what my belt is. Let's switch the fill and
the stroke over here, so we're gonna flip that. And then up in our color panel, that stroke, we're
going to click it, double-click it to open up the color picker for the stroke. Let's get something a little
bit more golden and a little bit more
saturated up in here. Maybe it will, maybe we'll do a little orange ear,
something in there. It okay. All right. Now we need to
increase the stroke size. It could be up here at the top, it could be over
here at the right depending on which
version you're in. But this is my properties panel and this stroke size over here, we're gonna guestimate
here 45 maybe. That seems like a little
much for this size of a hat. So let's do, let's do
35, something like that. Now I need to click on this stroke icon and I
can select a few things, the corners I want to be rounded and I don't mind
the align stroke. I'm going to keep
it in the center. So from here what I can
actually do if I zoom in on this guy again to show you
guys Command plus or minus, remember, or Control
plus or minus. If I click on this guy, there's
these little dots here. Those are available in CC. So if you're in CS6, you're
going to need to find my head around corners CS6
tutorial, but in CC, which most of you are
the View drop-down, down to corner widget is either hide or
show corner widget. You can do that here. If you're not seeing
these little dots, but with these dots selected, you can pull them in
and sort of round off these corners like that belt buckle look that we
wanted to go for. All right, so I'll
zoom back out here. Let's drag this guy over
the top of this hat. I want him to be centered. So I'm gonna have him selected Shift-click on the
top of the hat and then click on the top of
the hat that's that align to key object. And now with this
alignment panel, I'm just gonna make sure I hit the Horizontal Align Center just to center that up. And we can center
it on this belt buckle sort of visually
if we want to, we can use the up and down arrow keys to bump that into place. Now the last thing
we want to add here, It's a little like the actual
latch part right here. I'm gonna do that with a little tool called,
It's actually right here. It's called the Line Segment
tool with the slash icon. And I'm just going to
find the center of that click and drag out
while holding Shift. Not quite halfway,
maybe a little short of halfway and let go. That creates a little
line with that stroke. If it doesn't, you
can go ahead and edit that stroke if you need to. And to create a
rounded end on this, we need to go into
those stroke options on the cap and just
click on round cap. That creates like a nice rounded little, nice rounded little. Oh my gosh, I keep
hitting that button. I'm trying to get back
to the selection tool. Nice rounded little buccal. Now as this buckled
too big, I don't know. Maybe we can bring in
this side as well. I think it should be a
little bit more square. Now, I'm going to shift click to select both of these pieces and maybe drag them back over to line them back
up in the center. Something like that. This bug goal looks huge
compared to this one. I did a much better
job on this side. Let's zoom back in. And maybe we need to click
on both of these again. And with them both selected in the upper right-hand corner, I can click and drag, hold shift and option to scale in and out
from the center. Maybe I can scale it down
just a little bit like that. Then maybe we can add
a little bit more from the stroke standpoint
to be like 50 points. Oh wow, That's too much. It to be like 40 points, maybe just to have a little
more stroke on that buccal. Okay, So there's our little hat. We need to add the final
little shadow on this guy. You know, these flat
design tutorials always come with a nice shadow. Back to my rectangle
tool this time, let's go ahead and set
up our fill and stroke. In the appearance,
I'm gonna go with just a straight black is
as dark as I can get. And then the stroke, I'm
going to say none, 0 please. No stroke on that. We just want a black rectangle. I'm gonna make that rectangle
big enough that it covers our entire hat and then let
it lock into the center. By the way, these are smart
guides, all these pink lines, you can turn them
on up and view down to Smart Guides checkmark. Alright, now that we've
drawn that rectangle, Let's go back to
the selection tool. Let's select the hat
and the rectangle. Switch to the shape builder tool now that everything is selected, and let's get rid of
this outer piece by holding Option or Alt
and just clicking on it. Boom, it's gone. Now back to the selection
tool, shortcut TV. And I've got this shadow. It's obviously too
dark so I can click on it and just do the opacity at something like 15% to give us
a little shadow on our hat. And of course, we can
always just create a rectangle background to sort
of accentuate our design.
16. Flat Design Puppy: Here's our little dog that
we're gonna be creating. And he's got about five
different colors in Him. We're gonna make him actually
use the pen tool a lot more in this than I'm used to using to make the
different shapes. So I'm gonna go
ahead and start out with the pen tool shortcut is P, and we're gonna start
by making the head. Then we'll make the
body and we'll put them together and do the shadows. The heads kind of
a different shape. I'll go ahead and start
at the very bottom. And this is like
the center point. I'm holding Shift. So this, these handles
will go straight out. They're not going to be
crooked or anything. And I'm going to point it in the direction that I
want my lines to go. Same thing for everything
you do with the pen tool. We're going to click and point, click and point and
just create this sort of oblong half circle, half oval shape with these two corners being slightly different,
something like that. And then I'm gonna
connect it down here. Then what I can do is with the Pin Tool selected
hold Option or Alt, and just bring this
extra handle back and it'll snap in to that point. And so now I have this
half circle shape. Now with the new
Properties panel. After I duplicate this by holding Option or Alt
and dragging it out, I can flip it. We can flip that along
the horizontal axis. Really easy. If don't have the properties panel
over here to the side, you can probably go up to object transform and do reflect
to do the same thing. I'm just going to make
sure that this kind of snaps in place like that. And then we're going to add these two together
by selecting them both Shift M for the
Shape Builder Tool, it says to circle right here Shape Builder tool and we can just swipe
right through them, add them both together. Now, I don't like
the shape of this, obviously it's too wide, so we're just going
to squish it down. We can squish it down
to make the shape of our dog's head. Just like that. We need colors. So I'm
going to go over here. You can just create
squares with colors on your Illustrator document. I like to do that a lot so
I can just eyedropper them. And if you make them
global swatches, you can change them
later as needed. This is gonna be sort of
that middle brown color. We've got a lighter brown
middle and a darker, and then we've got a really, really dark, almost black. This is his head. And now we're going
to create his little, I don't know, his
a little snout. And it's pretty much
the same thing. I could just almost
duplicate this guy, bring him down and
then make him smaller. And I'm just going to
grab the color from here. Same thing. And we want him to be a little
bit more oblong. I think. Something like that. I feel like the tops of these could be a little
bit more squared off. I'm just going to switch over to the direct selection tool. Click on the anchor
point here and I can pull this handle
up a little bit. And I can do the same
thing over here. Just pull this handle
up a little bit. Maybe even to where it
intersects up top here. So I'm gonna go
ahead and do that. Make sure it intersects all these pink lines
are smart guides. You can go up to View, down to Smart Guides to turn those on, Let's create the cut-out where
the tongue is going to go. To do that, I'm actually just going to create a rectangle. If M is the shortcut key
for the rectangle tool, I'm gonna switch that to pink so that we can kind of see where we want
his tongue to be. I'm going to round these
bottom two corners by pressing a that's
direct selection tool. By the way, the
selection tool is V, the direct selection tool is a. These two arrows up here, if I click and drag to grab
the bottom two points, I can pull in the corners. And if you don't see
the corner widget, it's going to be up in view, down to show or
hide corner widget. You might be on CS6. I've got tutorials
on the channel, Just search for CS6
rounding corners. And there's some different
ways that you could do that or you could put two
shapes together, like adding a circle
and a rectangle. But I'm going to assume that everyone's sort
of upgraded by now. It's been out since
at least 2017. So it's been a couple
of years to guys. This is actually the tongue, but I'm going to go ahead
and duplicate this over and create the sort of mouth
opening here as well. Just by bringing this up into on top of this shape,
holding Shift, clicking both Shift M, shape builder and this
time hold Alt or Option to subtract out the two pieces
in the center there. We've created this
sort of opening. Now we need to finesse
this a little bit. First, we need to get rid
of a couple of points here. So I'm gonna switch to
the pen tool with p, subtract that anchor point, and subtract that anchor point. There's an extra one here.
I don't like that either. So subtract him. Now we just have 123,
hold Option or Alt. Click on this one and
figure out which way my handles need
to go hold Shift. And we're just going
to open that up. Just like that. Go back to a which is the
Direct Selection Tool. Select both these bottom points. And I'm going to round
these off a little bit, kind of like that. Don't want them to be so sharp. Now, we need the tongue to
go right inside of here. So he needs to be on
bottom of this shape. What we can do is
actually bring this guy to the front by right-clicking. Arrange. Bring to front. There we got a little
tongue sticking out. Now, this is probably a little
too much so we can bring this up a little bit more. Just like that. I
think that maybe we can bring this
down a little bit. So I'm zooming in and out with Command or Control
plus and minus. I'm going to hit a for the
direct selection tool and grab this anchor point and we're going to bring him down some, I don't want his mouth
to be quite that open. Maybe something more like that. That looks pretty good. So I'm going to create his
little nose shape there. I'm gonna use the
pen tool again, similar to how we
did with his head. Just going to click and drag
to start out this shape. And I want them to come out here like that and then come
down here like this. Click and drag and just use these handles to
sort of round out. That knows, you can hold Option or Alt and grab this single handle,
bring him back. And then we're going
to finish that shape going up there and
just clicking. And then what we need to
do is duplicate this guy. So we hold Option or Alt
click and drag him out, flip him again or reflect him. And we want to merge
these two guys together, grab them, shift M, swipe through, and we got that. Now he's obviously
it's way too wide. So we're just going
to click on this. And if I hold Option or Alt, I can kind of pull it in from both sides
at the same time. So that's how we
create that no shape. I need him to be
that darker color. So we're going to go over
here to my swatches, kind of grab that darker brown. You guys can make
whatever colors you want. These are just the
ones that I chose. This nose is way
too big, actually, looks goofy sort it looks like maybe more cartoon
version of a dog. But I'm just going to
grab the corner here, hold Shift and Alt or Option and scale his
nose back a little bit, maybe something like that. All right, Let's add
some little beady eyes. We can just use L, that is the ellipse tool. It's in the rectangle tool. Click and hold, go down to the ellipse tool and just create some vertical little ovals here and these are
gonna be his eyes. So I need to grab that
darker color again. And then just plop some eyes
right here on his face. It can be anywhere. It doesn't really matter. Duplicated out by
holding Shift and Alt or Option if you're on a Mac
and just bring it over here. Just like that, we
can do anything with these eyes and to center
them on the head, I would shift click
both of them, then right-click,
group them together. And now that they are a group
and they move together, I can actually Shift-click
his head as well. Then click on his head
again and go through the alignment panel
on the lining to key object which
would be his head. Horizontal line center brings them right to the
center like that. All right, now he
needs some ears. We're going to create some up here with the pen tool again. Got the pen tool out. I'm gonna find a
spot on his head. And I actually think his head
prime needs to be a little, it needs to probably
be a little bit taller and a little
bit more squared off. I'm actually going
to switch to the Direct Selection tool and find out what kind of anchor
points I have to work with. First, I'm gonna take
this one up like that. And then second I'm
going to switch to the pen tool shortcut key is P, hold Option or Alt and fix
these anchor points again, I'm also holding Shift
and I'm just going to square this off a little
bit more up here. It's still rounded, but it's still a little bit more squared. Now from here, we're going
to take the pen tool. We need to deselect his head. So just click off of his head. Go back to the pen tool. Click somewhere around here is where we're gonna
start his ears. I'm going to select a
darker color real quick. So just I, for the eyedropper. And we're gonna select
that knows color just so that we can see our
shape as we're building it. I'm kinda pick a spot here, click with my pen tool. And we're gonna go out here
and just create his ears. So we can use the Pen
tool, click and drag with those handles and just create some years that
kind of dropdown here, the droop down a little bit. Maybe they come up this way. What we could do is click and drag and sort of bend
them out like that. We can kind of mess with these
handles some on this guy so I can pull this handle
out a little bit more. He's got an ear a little
bit more like that. And then we just place this
on here wherever we want. Essentially, the one
thing you want to do is make sure this top part
kind of lines up better. So what we'll do here is sort of rotate it a little bit
and then place it back. And then we can zoom way, way, way in and just make sure that we get that
lined up just right. And if anything is not
lining up for you, you can go to the View
drop-down and make sure depending on what you want, you can do snap to
points, Snap to Pixel, snap to grid, or you
can turn them all off. It's not going to
snap to anything. That's super-helpful when you're trying to align something out. The other thing that's helpful. Is Command or Control Y will
shift you to outline mode. That's also in the
View drop-down. Believe actually, I don't
know where it's at. It's right here. It's a preview
now they call it preview. Apparently. It's outlined in preview mode. So outline in preview mode, you can switch back and forth
with command or control Y. You can really zoom
in here and see exactly where your
paths are lining up. And you can kind of move
that so that it lines up exactly in the right spot. Once you do that, You're
pretty good to go. He's got these little ears. And you can adjust the handles on these
as much as you really want to get the type of ears
you want out of your dog. So we can move that
around a bunch until we find something that
we'd like pretty much. So I'm going to duplicate
this year by holding command or control or I'm sorry, by holding Option or Alt
and bringing it over, also holding Shift
to keep it in line. And I'm going to flip it
just like we did before and then find the spot
where it lines up again. I'm going to make sure
to sort of zoom in here. We'll switch to the outline
mode command or control Y and zoom way in and
see all these lines. It's kind of technical looking. But if we just click and drag that over to where they line up, that's gonna be
good right there. So Command or Control Y. To get back out of that
mode. There we go. We have the head. Now we've got to do the body. And the body is pretty easy, actually, a lot
easier than the head. You can move all these elements around just by clicking them, selecting the
different portions. I could select just this. Now,
I can group that together, Command or Control G to
group things together. Now that whole piece moves
around and I can move that up. I can widen his eyes, I can do whatever
I want with him. But let's make his body. So I'm going to make his body
sort of separate over here. I'm just eyedropper
his I guess skin tone. If you want to call it that, then we're going to
grab the rectangle tool and just create sort of a taller rectangle,
something like this. And at the top of it we're going to use the direct
selection tool to grab these two top points
and just bring these in completely
just like that. Then I'm going to duplicate
this by clicking it with the selection tool
shortcut key is V holding Option or
Alt bringing that out. And then I'm going
to make it smaller. First off, something like that. And I'm going to switch
the color eyedropper, just one of these darker colors. Then I'm going to center it up. So I selected both, clicked on the larger body shape and just align it
right to the middle. And we needed to
make it skinny two. So if I click on the edge and
I just hold Option or Alt, I can bring it in
just like that. Now he's got a couple of
little legs right there. I can just scale this
down if I click on the right part using those
double-ended arrows, scale it down like that. Now we need to create
his little feet. So we kind of zoom in here. These are going
to just look like little biscuits
down here honestly. But if I start with my pen tool, once again, I'm actually going to start up top here
just like that. I'm going to bring
it down to here. And kind of just rounded
off just like that. Going to hold Option or Alt
to bring this handle back. Kind of go outside of
his leg just a tiny bit. Something in here just
going to click once. I'm going to round this
off right up here, what I can do is
actually redo this here. If I, after I've closed it up, I can redo any anchor points just by holding Option or Alt, having the Pen tool selected. And that's what we're
gonna do on this one. Because I don't like
that they're unequal. So I can just grab that
again and make them equal. And I can actually just
remove this handle as well. And so now they're totally
equal on either side. This anchor point is not in the middle,
so I'm gonna skip, scoot him over a little
bit and then bring him down some just like that. So there's this fee that was a horrible way of making that, but that's one way of doing it. You guys can find a better way. It's kinda like a half circle, but I want it a
little bit oblong. Like I don't mind things being sort of organically not
perfectly symmetrical, if that makes sense. All right. His paws are gonna be the same color as his
nose or his snout, I guess, someone who
just eyedropper that. And then the other piece that
I want to do on these is use the direct
selection tool and just pull in these corners
a little bit. I don't want them to be
perfectly squared off. I want them to be a
little bit round. Now we can just duplicate this guy and bring them over here, kinda cover up where
these two colors match. And there he's got, he's
got some pods down there. Then we just want
a little bit of a body sort of poking out
on the left side here. So I'm gonna
eyedropper this color. Use that pen tool again. I'm just going to go all
the way down to the floor. Kind of been a little bit. Get rid of this handle just by pulling it back,
Option or Alt. We've done this a lot. Click over here and we
just want to click. Underneath because this is
going to be underneath. So I don't mind
that that's sort of pointy like that because I'm just going to
right-click that piece, arrange and send to back. And it sent it to
the back of what is actually a background
color that I forgot I had, but it's behind everything now. Then I can just bring
this over a little bit. And I can play with
these anchor points. I'm switching to the
direct selection tool while it's selected. And I can kind of grab that, sort of play with these
anchor points some, round this off a little bit because he's not perfectly
squared like that. He's going to be rounded or have a little bit
of a rounded body, something, something like that. If you want. We can bring this a
little bit closer as well and then pull on
these handles some, this is just how you
sort of morph this shape and he's got a little bit
of his body poking out. Now, we'll finalize this
once we see him up here. But he's also got a tail. I like to do that
with the Ellipse Tool and pull out the Ellipse
tool shortcut key is L. Can I just make one circle? Then I'm going to duplicate
that circle and then make this one a little bit bigger holding Shift to scale that up. I'm looking at the negative
space that I'm creating here, selecting both Shift M and I'm looking at this
little piece right there. I actually just want to
hold Alt or Option to slice everything off
except for that piece. Select it with the
regular selection tool. Shortcut key is V on that. Use the eyedropper
tool, grab a paw. We've got that nice
color and then we're going to place this in the back here and also
send it to the back. Arrange, send to back. Just like that, we can
make this smaller, of course, holding shift the
kind of scale that down. We can rotate it
however we want. Just got a little
tail back there. Now, we want to grab his
body and everything. I'm going to group that
altogether just to make it easier to
bring it over here. And we've got to
send it to the back. We've got to make
it behind the head. We're going to go to a range, send to back, just like that. And then we can just
move it around. And actually what
we can do is we can center it on his head. So I've got the whole body
groups like his head selected. I'll click his head again, aligned to that key
object and press center. Now I just realized
that because we have the tail that's going to
offset it a little bit. So what you could do is look and see if we can't find
a better center point. We can actually center it
without the tail if you wanted. I don't mind too much. If this is sort of
offset a little bit. It's not a big deal to me. What we're gonna do here is maybe you don't want
these touching, so you want his snouts to be
maybe a little bit bigger. So I'm gonna grab
everything up here and then Shift-click to not have
the body selected. I have this whole head
section selected. I can right-click
group that together. Then we're going to make that
just a little bit bigger. Just like that. So that his snout comes a little bit closer to where these
two colors touch. I want them covered up some, if that makes sense. Okay. So there he is. Now if he's too tall
or not wide enough, we can grab the whole
composition and just kind of scale him out a little
bit or squish him down. However you want your
little dog to be. I think his head is pretty
wide at this point, so I would like that to be maybe pulled up just a little
bit, something like that. You kind of looks like a puppy. He's got a big head,
cute little dog there. We want to add the shadows now, pretty easy to do that. I'm going to go ahead and group the entire dog shaped together. Now this is one piece. I'm going to use my M key that's going to
create a rectangle. Just going to create a
rectangle that hits on the center of my dog. Just like that. I'm going to make
this rectangle my darkest color over here. Now I'm going to select
everything I have right there. Shift M for the
shape builder tool. And we're just going
to subtract this piece out holding Option
or Alt and clicking. Now I just have this
really dark shape on the right side of my dog. And I can turn the opacity
down to something like 15%. You could do 10%,
whatever you want to do here for that sort of
shadow on that side of dog, then we can create a little
shadow on the bottom like he's sitting on the floor just by creating a
really thin ellipse. L is the shortcut key
to get that tool, we place it down here. Let the center line up with the center of our
shadow we just created. Send it to the back. Of course. Like so. So he's sitting
there on that shadow. I actually wouldn't mind
just offsetting it a little bit to the left since
he has a tail over there. And we can create by
double-clicking on this swatch, we can create a different color. I like to pick
colors for shadows. I want it to be matching the background but kind
of gray a little bit. Hit Okay, Just like that. That is a dog in Illustrator.
17. Flat Design Umbrella: In this one we're not going
to be using the pen tool. We're gonna be using shapes
to create an umbrella. We're going to start by
using the ellipse tool, and that's like the circle
tool over here in the toolbar. Just grab that, the
shortcut key for that as L. If you don't see it over
here, you can click and hold and then select
Ellipse tool. And let's draw the first
large shape of our umbrella. So you can just click and
drag to draw out an oval. You don't have to hold shift. We actually want an oval
shape for this one. And that looks about right. So what I'm gonna do now is show my rulers by holding Command R. That's kind of a shortcut key. You can also go up to View, down to Show Rulers right here. Rulers. And then you can hide rulers, show rulers with Command
R or Control R on a PC. Also, it might be helpful to turn on Smart Guides
with Command U or just come in here to
the View drop-down and turn those on and make sure
those are checkmarked. Those are gonna be helpful
to align things up later. What I want to do
with these rulers is actually just
pull out a guide. So if I click and drag
from inside the ruler, I can pull out a guide here and I'm going to line
it up to the center, the horizontal
center of this oval. The reason I did that
is because we need to create the underside
of the umbrella. The underside is going to
look something like this. That umbrella E shape. What we're gonna do is create
a couple more ellipses. Ellipses, I don't know, plural of ellipse,
circles, ovals. And we're going to move them down here and
duplicate them across. So let's go ahead and
create another shape. It doesn't matter where
you start because I can, while I'm creating the shape, clicking and dragging
and holding, I can hold space-bar as
well and move that shape around and then let go and
then reread, define it. So if I just create
this oval here, hold space bar and I'm going
to have it sort of cross paths with where that guide and the oval does right there. I'm going to let go. We have this oval shape here that
crosses right across here. I'm gonna duplicate
this by holding Option, clicking on the
shape holding Shift to keep it aligned and
just moving it over. I'm gonna let go there. And then if I go up
to Object Transform, I can actually do transform
again or Command D, Control D on a PC. And what happens then is that it actually just repeat that
last transformation. If I do Command D, it's going to skip
another copy out there and skip
another copy across. Now these are not centered, so I'm gonna grab
everything and then shift click on the big
oval to unselect it. Now that I have these, I can right-click and group also Command G. Then once
those are grouped, if I shift click
on the big circle, I've got this group selected and the big circle, oval selected. Click again on that
oval without holding Shift and we're going
to align to key object. This is our alignment
panel up here, and actually it's
already set up. You can see the key. It's set up to Align
to Key Object. And what we wanna do
is just bring these over so that they're all
centered with this oval. I can do that with
horizontal align center. Boom, they're all centered up. Now I'm going to grab all
of these shapes again. And we're going to use
the shape builder tool, which is somewhere
over here, right here. It's got these two circles, the hotkey for that shift M. And what I can do with this, you'll notice that it recognizes each of the
different shapes in here. I can actually just
hold Option and draw through all of these
shapes and let go. And it deletes them all out. We just drew this umbrella
shape with shapes. We didn't have to use
the pen tool at all. Let me show you that again. Hold Option and you notice the cursor now has
a minus on it. It has a plus normally
now it has a minus. Just click and drag through all that and it deletes
them all out. So we've already got
this top umbrella shape. Now for the handle of it, it's gonna kinda loop down here, sort of like an upside down
candy cane or something. Let's go ahead and grab the
rounded rectangle tool. And we're going to just
create a rectangle in here. And that looks about right. And this rectangle
has no fill on it. It just has a stroke. And you can see, if
you look at this, I'm going to align
this so that the It's the right side of this
is aligned to the center. You can see that inside of here, I'm going to make it
a little bit bigger. There is this sort
of J shape to it. If we just up the stroke
of this, Let's do five. Now. We're gonna do
something like 20. Yeah, that's better. If I had a way to
just cut this out, I could actually make
the handle just out of this stroke of this rectangle. What I want to do
now is actually convert this stroke
to a shape itself. I'm going to go up
to Object Expand. To do that we get a little
window that pops up. I always just check fill, check stroke just to make sure everything
expands correctly. Hit Okay, and now we have a
shape instead of a stroke. What we can do with this shape, There's this cool thing
that he showed me that we can do with the eraser tool. I never knew you
could do this before. So over here in the tool panel, grab the eraser tool Shift
plus e to select that. Once I have the eraser tool
and this shape selected, yes, I can go through and erase paths on it and
things like that. And I can make the
with my bracket keys, I can make my cursor bigger and I can just
erase through this. But what I can do
is if as long as I have the shape that I wanted to erase
selected and only that shape I hold Option. Click and drag. It creates this, this rectangular box and
you can see it's already covering up parts of that shape. And that's because
if I let go of it, it's gonna delete out
that part of that shape. Really only have to
make a selection there. And then make a selection for this part will go
down to maybe here. Let go. And I have deleted out that shape and I'll have this perfect shape
of the handle. Switch back to my selection
tool with the shortcut key v, we need to give this umbrella
some kind of a fill. Let's select a sort
of teal color. And I'm gonna get
rid of the stroke. Then I'm going to grab
this handle shape here, right-click and
Arrange Send to Back. Then let's drop this
umbrella down a little bit. I selected it, I'm
going to Shift click down just a little bit and I'm gonna delete out
this guide and we pretty much have the guy
that must be locked. So if your guides are locked, go to Guides and then unlock guides so I
can delete him out. There we go. Now
one thing I'm gonna do is I feel like this could use a little bit more
thickness to it. So I'm going to add a little
bit more black to that. Maybe bumped that
stroke up some. So there is your umbrella shape. We made this completely
out of shapes. We didn't have to touch
the pen tool whatsoever. So I hope you guys learned some interesting cool
techniques by following this tutorial and
you can apply all of these to your own designs. What I would do is look
at what you want to draw, what you want to make and really find all the
basic shapes in it. Like can I make that face
out of circles or that, that car out of basic shapes, rounded
rectangles, circles. Can I use the shape
builder tool to add and subtract shapes together to
create the shape that I want. And what you'll find is that those shapes when
you create them, that way actually become a
lot more defined, a lot more. Even with the pen tool, it's hard to get things perfect. It's hard to get that perfect. If you know that perfect angle on those circles every time. It's a way to keep it a
little bit more defined. I think.
18. Flat Design Lamp: I'm gonna show you how to
make a flattened design lamp, but let me take it one step
further and show you how to create an on off switch. That's gonna be pretty fun. Let's hop right into it. First thing we're gonna
do is go to File New. We're going to create a
new document that's also Command or Control N for short. 1920 by 1080 is
perfectly fine with me. One of the advanced options
I like to do is RGB color. Most of my work is digital, but if it is going
to be printed, you might want to
consider CMYK art boards fine orientation, fine. I do like pixels
as the the unit. Then let's name this, Let's name this
flat design lamp. Then we're going to hit create, and that's going to make us
a new 1920 by 1080 document. Now, I like to start over in
the gray space over here, because I generally
just start with the white and then I'll
create colors later. Let's first create a rectangle. Everything starts with
that rectangle tool. The shortcut key is M. I'm going to just
create a rectangle, doesn't matter the size, something like this right there. We're just going to
start with that. If you want to know the size, I'm gonna switch over to the selection tool
shortcut key is V. I'm gonna click the
properties panel, which by the way,
I'm in the new CC. All my properties are
here on the right. If you're an older versions, you might see all the properties
stuff at the very top, but you'll be able to find
the same elements regardless. So over here we have
a width of 250 ish. So let's go ahead and make
that 250 and we have a height of 450 and I think
that's about right, so we'll just make that 250 by 450 if you're looking
for exact measurements, switch to the direct
selection tool. The shortcut key for that is a, I'm just going to
click and drag to grab one of these bottom points. And once I have that, I'm gonna hold shift and
press the right arrow key to kind of bump
that out a little bit. And I'm gonna do 123 times. So we're going to bump that
out three times and then I'm gonna grab the
left side of that. We're gonna bump it
left three times. Remember I'm holding shift, just pressing the
left arrow key. Now we have this sort
of trapezoid shape. I'm gonna go back to that
rectangle tool shortcut key is M. I'm gonna create a rectangle that is over the top of everything else. What I'm doing here is the, the very top of this. I wish I could point at it, but above this rectangle
is my lamp shade. I'm going to just size
that to something in here, right there like that. Now with the selection
tool, select everything, and we're going to use
the shape builder tool, one of my favorite tools, it's over here, It's
got two circles and a little shape builder tool. The shortcut key is Shift M. I will remind you of that a million times in this tutorial. Now the shape builder tool sees all the shapes that
are overlapping. You see this outside
rectangle shape. I'm gonna hold Option
or Alt and just click on that and it's
going to get rid of that. So now I have these
two shapes from here. This is my lamp shade, the top of my lamp that I want. So I'm just going
to click on that and it's going to
make that shape. I still have these two. Let's go back to
the selection tool and see what happened. I'm pretty sure through
that process we may have duplicated
the bottom piece. We can go ahead and
delete one of those. But now we have a
bottom and a top and Control or Command Z to undo if you've
made those movements. I want to leave these
right here and I want to change their fill and
stroke really quick. Because like I said, it
didn't matter what we started with from a
color standpoint, but I don't want a stroke. I selected both of them. I'm gonna go to the stroke
and hit 0 points on that. No stroke, we just have a fill. For the time being. I'm gonna get rid of
this bottom part, but I want to keep it because this bottom
part we're going to use later as the light that comes out of the lamp like
our on-off switch. So I'm gonna hit
Command or Control X. That's also up here in edit. And it is cut. It's currently grayed out because we have nothing selected but it's that command
or Control X shortcut. Then we're also going
to use this one here in a second paste in front, and that is Command or Control F. But first we need
to add a new layer. So let's go look at
our Layers panel and look at what
we got going on. This first layer is the
only layer currently. I'm gonna name that off because that's going
to be where we build the lamp in the off state. But I need to create
a new on Layer. Way down here is a
Create New Layer button. I'm gonna click it and we have a new layer on top
of the off layer. This new layer we're
going to label on, and I just double-click
that to label it. And now we have this on
layer and this off layer, and this layer just
has this path, this little lamp shade. We could even
double-click the path and rename that to lamp shade. We won't get into much of this, but just for so that, you know, you can do
that kind of stuff and organized in that way. So what we're gonna
do with this on layer is paste the
light into it. I got to make sure
it's selected. It may be highlighted,
but maybe not selected. Honest, I click on this circle because that's my target layer. Now I can use that old shortcut we talked about Command or Control F to paste in front that light piece that
we had cut out earlier. And now it's on this on layer. What I want to do now is
just lock this layer. We're going to toggle the
lock button right here, click on that, and then
we're going to hide it. So toggle the
visibility right there. We'll come back to that. But for now we're going
to build the lamp. So I'm gonna go back
to this off layer, make sure it's targeted. And then I can click
over on properties again and we can just build
the rest of the lamp. We have the lamp shade, we need the base, the maybe at the top or the lightbulb goes
some different pieces. I'm going to use that
rectangle tool that's just M is the shortcut key. And let's build the, I don't know the
lamp base and the, I don't know what you
call this the poll thing. But we're going to build that
just a skinny rectangle. Now I'm going to switch to the Selection tool
That's shortcut V. Select both, click on the lamp shade because
we're going to center this on the lamp shade. Find your alignment panel. If you don't see it
go up to window, down to a line, it's going to bump out. I'm gonna go ahead and
dock it right here. Pop that out. It's aligning to the
key object because we clicked on this
after we selected both, just hit this Align Center
and it's going to pop that lamp shade pole thing over to the center
of the lamp shade. But I'm not really satisfied. We could just leave
it like that, but I'm going to create some better pieces to this where the light
bulb goes and stuff. So what I'm gonna
do is let's zoom in a little with Command
or Control plus. And we're going to
just bring this down to the bottom of the
lamp shade right there. And I might have made that
off-center a little bit. So I'm gonna grab
these both again, click on the lamp shade and just click the Horizontal Center. You can see that it's
shifted a little bit. But this is what we're
going to have right now. I'm going to create where
the light bulb goes. And that's just with
another rectangle maybe right in here somewhere. We're once again, I'm
going to switch over to the selection tool
shortcut key V. I'm gonna select carefully that rectangle and
the lamp shade. Click on the lamp
shade, center it. Now what I want
to do is actually click on this rectangle, press the a key, that's the direct
selection tool. Click on this top anchor, anchor point and shift arrow
key that to the right. I'm gonna shift arrow key
this one to the left. Now we have a little place where that light bulb would go and
it kind of tapers outward. That's a little bit better. Look, I think last
thing I'm gonna make it a little spot where
this sticks out at the top. It's gonna be a little
bit wider than this base. But what we could do is go to the selection
tool, which is V. Click on this bottom part, hold Option or Alt, and that's going
to duplicate it. And then if we hold
Shift at the same time, it's going to keep it in line. And I'm just going
to bump this out up top right there like that. And I'm actually going
to hold Option or Alt. And when I get the
double arrows, I can scale this out
left and right and my widen that just a
little bit to there. And then we're
going to pull this all the way up to there. It's hidden underneath
the lamp shade, but it kind of sticks
out up on the top part. So all we really need now is like the base of
the lamp down here. Just another rectangle,
shortcut key M. We're gonna create
something, maybe a little skinny base down here. Maybe about the
width of this guy, maybe a little bit less. V for the Selection Tool, select both the, the
pole here and the cache. I wish I had a better
name for that. The lamp piece here,
the poll thing. And then just click on that because we're going
to center it on this. We're going to center
this base on this guy. Hit that horizontal line
center. And there we go. We pretty much have the lamp. We've got to color
things in now. I want everything to be silver
except for the lamp shade. Lamp shade will make
like, I don't know. We'll make it like a blue color, like we did, like I showed
you in the beginning. We'll make it a blue. Let's grab everything that's
not the lamp shade. So I'm clicking and dragging
with the selection tool. And I grabbed these
pieces down here. I'm gonna hold shift, grab this piece up here. And we're going to change
the color of this. Now I like to use the window
down here to Color panel. The shortcut key is F6. I like to pop out that
color panel because one of my favorite things is double-clicking on the
little swatch color here. And that opens up
the color picker. It's more than my
favorite ways to pick colors because I
know that basically this way is saturation and
this way is sort of the, what do you call it, the shade. And then if I'm pulling
it down into here, it's like a muted tones. So I like those muted
tones a little bit not too saturated and not
too dark to light. Let's make it blue. So I'm
gonna click this guy to change this whole thing is sort
of a blue tint or hue. And then maybe
something down in here, which is what we're
just not I don't know. This is silver. Sorry, guys. Okay. Silver something
down in here. We're just going to pull
it all the way left and make it silvery. Hit. Okay, and there's
our silver in this. What I want to do
with this is create a new swatch so that I can change this
later if I want to. We're going to make a
global swatch in fact. So go to Window down to
swatches somewhere down here. And that's going to pop out
the swatches panel somewhere. And what we can do here is click this New Swatch button once
we've got our color picked. And it's going to open up
this little new swatch guy. We're going to look at
color type process spot, you just keep it on process. But it definitely check
mark the global swatch. Because when we hit OK, it's going to add that to our
swatches list right here. It's got a little
white rectangle here. Now, even though these
are separate pieces, I can just double-click
this swatch. And it's going to open
up the Swatch Options. And I could adjust that
and even preview it. As I adjust that color, adjust any element that
uses that swatch color, it's going to adjust. I want to cancel
out because we'll keep it at silver for now. This lamp shade is obviously behind all of our
other elements. It needs to be in front. So let's bring it to the front. Shift Command, right bracket or Shift
Control Right Bracket. For those of you that don't
use shortcuts like that, it might be a little much just right-click on your lamp shade, go down to arrange,
bring to front. I'm gonna start clicking this up because I'm taking forever. Click on that lamp shade. We're gonna make
it a blue color. I'm just going to
start with something crazy like this,
really dark blue. And I'm going to
create a new swatch. And from here, I'm actually
going to adjust it. So let's make this blue, a lot lighter of a blue. I don't have my preview button because I haven't
made this swatch it. So let's go ahead and click. Okay, remember it's
a global swatch. Now I've got this swatch,
I'm going to bring it down here next to that gray. I'm gonna double-click it. And now I'm gonna check
mark my preview button. And we're going to
select this blue color. I'm going to make it
something bluish, maybe something like that. More of a muted tones. I'm going to bring these
back a little bit, maybe up a little bit. Somewhere in There
would be good. There's all the numbers if
you wanted the exact color. We have a blue lamp shade,
we've got the lamp. Last thing I might do is for this whole
flat design thing, we'd like to make shadows
on this guy, right? So a little bit of shading. I'm gonna create another
rectangle shortcut key M. Just create it so
it's big enough to cover your whole lamp here. And I'm gonna go
right to the center. It's gonna kinda lock in there
with those smart guides. If you don't have
those turned on, just go to View, down
to Smart Guides, That's Command or Control U. Alright, so it looks like I just completely
covered everything up. What I did was I covered
half of everything up. I'm gonna click and drag with that selection tool
to see everything. I'm going to use Shift M. Remember that's our
shape builder tool. And now it sees
all these shapes. And what I wanna
do is get rid of this outside shape right here. So I'm gonna hold Option, get rid of that outside shape. Now what we have, It's a little confusing to
look at Selection Tool. Remember shortcut key V. But I have this
piece right here. This piece is half of the lamp. If I change the
color of this piece, too black, for instance. Now we have a really,
really, really, really dark shadow on
half of this lamp. What I can do with
that guy is maybe take the opacity down to 10%. Whatever opacity you want, maybe we'll do 20% so
everyone can see it. There you go. So we have the shadow, we've got the lamp bill that we did a pretty
good job here. Now, as long as you didn't
move anything around, if you go back to
your layers panel, we have the off position. If I hide that,
it's just the lamp. Just have the lamp. He's off right now. But if we click the on
button, check that out. We have this light pouring
out of the bottom. Now we need to create, fix that rectangle and
add some color to it. But what we're gonna
do now is do that. All right, Here we go. I'm going to unlock this guy. I'm gonna show him. And now we can click on him. All right, let's send
him to the back. So let's pull this on
button to the back for now. I'm just going to drop
that layer underneath the off layer so I can see
the lamp on top of the light. Alright, now we're going
to create a rectangle. And this rectangle is
gonna be down here. It's going to make
sure we cover up all the light pouring
out of that down to the base of the lamp
because the light shouldn't go past where
the lamp is sitting, should just stop there. So now we have this rectangle. I'm gonna select
the light here and the rectangle would just made Shift M for the
shape builder tool. And I'm going to hold
Option or Alt and just draw through the
bottom portion of this. So I get both of
those pieces and it's going to get rid of
both of those pieces. Now the light is just down
to the base of the lamp. Let's add some color to this. And we're going to add a
gradient color to this. So you could go over here
to the gradient tool. The shortcut key is G. We can click on our light here and it's going
to add a gradient left to right, white to black. Now let's go to window
down to gradient, command or control
F9 to pop that out. I don't know that by heart,
but I just saw it on there. We've got this gradient. Really. We want the white to be up here and the black
to be down here. So I'm going to mess
with these angles. I think negative 90
will adjust that. Yep, negative 90. Now this left color is the top and the right
color is the bottom. We're going to make those two
colors of the same color. I'm going to double-click
on the gradient slider and we're
going to pick one. Let's pick this. I got this. Let's just pick
one of these yellow colors. Yellow for light. Alright, so it goes
to yellow to black. We want this black go over
here to be also yellow. If I click on this right slider and I changed the opacity to 0. Now it's kinda announce
getting there. It's got this light
that comes very saturated out of the top
and then dissipates as it, as it goes down to the bottom. You can then adjust
where that bottom is by dragging this swatch in and out. You can also adjust where
the midpoint of this is. If you want it to be a
lot quicker transition, you can adjust that
midpoint or if you want it to really cut hard at the
end, you can do that. I kind of liked it over here a little bit somewhere
in the middle. Now we have this light here. What we can do if we zoom out
a little command or control minus is click on
this lamp light here. And I want to bring
this layer to the top because I think that light should affect some of the, some of the lamp. But that might be a
little bit too much. That light completely hides the structure of our lamp there, all that silver
that we got going. So if I click on this gradient
and go back to properties, I can actually
change the opacity, maybe down to like
50% or even less. This depends on what you
want that opacity to be. That lights streams
out of there. That's pretty much it. So you can you can put this onto some sort of a background. I'm sure I'll try out some background colors
for the thumbnail. But if you go onto
that Layers panel, now you can toggle on and off
your lamp just like that. Now if you want to get
real technical here, you may have a pixel
or two that overlaps. It's possible, it
just depends on how your computers
rendering things. You could bring that lamp shade on a different layer
on top of the light. But as long as you use
that shape builder tool, this light should match up right with the bottom
of that lamp shade, shouldn't overlap too much. I think my monitor just
kinda shows that a little bit because of how I have
my display settings set. Also this gradient, it
might look a little choppy. If you go up to View and preview on different modes
like preview on CPU, we can change that, that actually smooth that
out a little bit. So Illustrator's got
some preview mode, some of my other tutorials and the blend modes like it
looks a little choppy. If you save this out as an image like a PNG
or JPEG or something. It should smooth out
that gradient a lot. But here in Illustrator a lot of times depending
on your settings, can be all over the place, how steps or choppy
that gradient looks. But for the most part, if you change your
preview modes, which is available in the latest CC version of Illustrator, I think the GPU
Preview maybe shows a little more choppiness
than the CPU preview. You can kind of go back
and forth between those. If you're trying to
show this to anybody, you can play with the
blending modes on this, on this light as well. So if we go to this opacity and we actually
click on Opacity, there's blending modes here, like screen or overlay, and that affects how the light affects
what's underneath it, how those layers
affect the colors underneath it so that
depending on what you want, they're like a screen might be a little bit better showing the base of that lamp
than some of the regular, normal mode with just opacity. Anyway, that's it. You guys, we made it, we did it. We created a lamp with
an on-off switch.
19. Flat Design Stop Sign: So flat design stop sign. I'm gonna start with
a new document. That new document
is 1920 by 1080, but I'm going to ignore
that art board and just go over here into
our big gray space. Why? Because stop signs have a white outline around them and that won't show up
on the white background, will make a new
background later. Okay, Let's get started. A stop sign is how
many sides in America, by the way, you guessed
it, it's eight sides. So we got to get that
polygon tool out. And if we just click on our
art board or our space here, it's going to pull up an option for the polygon tool and
we can make a radius. Let's just do 150. I don't even know where
that's going to end up. But we want it to be eight sides because a stop sign
is an octagon, so hit Okay, and we have a
little octagon out here. Now the other way to
create that is to click on your canvas and
drag with that polygon tool. Notice it's already
on an octagon. That's because we just
chose eight sides. But if I hit the up
and down arrow keys, it increases and decreases the number of sides
in my polygon. So we can get to an
octagon just like that. And then we can hold
Shift to get it aligned just right
up and down it. Or you can let go
of Shift and just kinda spin it around
if you wanted to. And then when you let go, it's going to create that shape. Those are two ways, but
the easier way is just to click and select your
amount of shapes. I've got this octagon out here. I'm gonna click on it with
the direct selection tool. And I'm going to scale
it up the corner here. Now notice that gets all skewed. That's because we need to
hold Shift while we scale. I really like to also
hold Option and Alt, or Alt, I should say, to scale from the center out. So Shift and Option or Shift and Alt if you're on Windows, scale that sucker
up and there is our stops and let's go ahead
and finish this guy out. All we really need is a fill
color and stroke color. If the old CC, you're going to see it up here. If you're in the
new Illustrator CC, you're going to see it
over here to the right. We've got the fill, let's
select a new color. We're just going
to select a red, but that's a super,
super hot red. So I'm gonna change that
in my favorite way, which is to go up to
window, down to color. It's going to pop
out the color panel somewhere In this color panel, I like to double-click on this swatch and that opens
up the color picker. My favorite color slightly
or not so saturated, they're like the muted colors
that flat design look. You see everywhere
that tends to be in up and down here
it's white to black. So somewhere here
in the gray space, and then you saturate
it a little bit more. Is some of those muted tones
not so, not so saturated. You can even see the difference between the color
that we're currently have selected and
then the color that we had selected prior, which is like
really hot RGB red. I want that more muted tone. I'm gonna hit OK,
and that changes that swatch or that
color of that fill. Perfect. The other thing we
want to do with this guy is actually
edit the stroke to be white because a stop sign has a white stroke around
the outside of it. So I'm gonna click on that
stroke and we're going to change it to maybe
something like five points. We'll see, we'll see
what that ends up. We might actually
do more based on the size of this stop sign, just depending on what size your sign is or what
size your shape is. Alright, so instead of black, we're going to click on that
and I'm gonna go white. I'm just gonna go straight
white with this one. I think I wanted to do
something more like ten points for that stop sign, outer edge, maybe 15. Let's do 15. That looks about right. Now. The other thing I
wanted to do with this, which will come up later, but we'll go ahead and do
it now is I want to change how that stroke
appears on my shape. And what I mean by that is if I click back on that stroke icon, I bring up those stroke options. You can align the
stroke to what is currently the center of
the edge of our shape. You can align it to the
inside or align it to the outside because we're going to add a tiny shadow later. I'm going to align
it to the inside. That makes it easier
to sort of contain that stroke within the shadow.
Alright, so there we go. We're just about there. Why don't we just go
ahead and add the stop to the stop sign and then
we'll do the post. Alright, so we're gonna go
over here to the type tool. The shortcut key for
that is T just click anywhere on your canvas
and you can start to type. Obviously I wanted to type stop. I'm gonna type all
capital letters STO P. And it's real tiny down there. If I just go click on
my selection tool, I can then grab
the edge of this. Instead of dealing with
the size of the font, I can just scale
this up on my own. Once again, you're going to skew it if you just
scale it like that. So hold Shift while
you're scaling it up, you can see how big
that is scaling. So we're gonna hold shift again, scaled up a little bit more. I'm going to switch my
font to something like, how about babies new? I know that it's
kind of like a, a, a taller font and it'll, it'll go with that minimal
design a little bit better. Let's do the regular, kind
of a little bit bolder. We're going to switch the
fill over here to white, just like the edge
of our stop sign. And then we're going to, I'm actually going to show
you go up to Window and down to character or I'm
sorry, down to Type. And then character. That's gonna pull up
the character panel. I'm showing you
this because this is really important for
people when they're dealing with type and they may not really know what I'm
looking at over here. But on this character panel, you can change the font, you can change the weight of
the font and then the size, the Letting, which
is the spacing between the lines you can
kern between letters. You can also set the tracking
for the entire piece. Let's set the tracking to 50, and that's going to
space out my letters. I can enter that with by
hitting tab after I type in 50. Then when I'm looking at this, I'm kind of thinking
that the, OH, and the p need a
little bit of kerning. That's where this guy comes in. I can just click. I double-clicked into that and I selected between
the O and the p. Now I'm going to go over
here and I'm just going to hit the up arrow
a couple times and now she's gonna hold shift
while I do that and that's going to change it by
increments of ten. It kind of bump that
out a little bit. We'll bump it out
a little bit more. So 20 on that guy. Then I might do ten
between the T and O. What I'm doing there is
I'm currently between the letters because the
font isn't perfect. I think the spacing needs to be tweaked a little bit and
I like where it's at now. S TOP, all those letters
look very evenly spaced. So let's bring this guy
on top of our stop sign. About in the middle,
doesn't matter. I'm going to scale
him up again by grabbing this corner with
the double arrow holding Shift and Option or
Alt if you're on Windows and just scale him
up to size him in here. That's about right, I think. Now this is kind of
an interesting part. By the way, I'm hitting
spacebar to use the hand tool to move
around my document here. But most of you probably
know that I'm going to hold Option or Alt and duplicate
this piece out here. I'm gonna keep my
type out there. That's what I do a lot when
I'm working in Illustrator, keep the editable
type out there. This guy I'm going to outline. And we can do that
by going up to Type and then down
to Create Outlines. The shortcut key for
that is Shift Command O or Shift Control O. That's one I definitely
know about heart. So now we've got
outlines instead of actual letters
that we can type. But the good thing
about this is there's no weird spacing now
it's just shapes. So I can take this
selection which is now grouped together,
all these letters. I can shift, click, and select also the stop sign. So I have both of them selected. I can also just click and drag through here with
the selection tool. And it's going to,
It's going to grab everything within what
I just selected there. Next, I'm just going
to not hold anything. I'm just going to click
on the stop sign. Notice there's a
darker blue line around it now or a
thicker BlueLine. That means I'm aligning
to a key object. So I'm gonna go up to
window down to a line. It's going to pop out
our alignment panel. Notice down here aligned
to currently key object. The key object is the stop sign. We are aligning the letters
stop to the stop sign. I want it to be in
the exact center. So I'm gonna grab Horizontal
Align Center and click it. I'm going to do vertical
lines center and click it. And now the stop is exactly in the center of the stop sign. Was a lot. Okay. Now let's do the post. The post is just gonna be a rectangle of a certain length. And we're going to
do, let's click on this polygon tool again and go over to the
rectangle tool. By the way, you can click and hold on that probably
in the beginning. You may have figured
that out and not sure I already had the
polygon tool selected. But if I click and
hold the select all these different tools, I'm going to grab the
rectangle tool shortcut key is M going to just create a long skinny rectangle like this by clicking
and dragging. And I'm just going
to eyeball the width to something like
that right there. With this guy. We're
going to change him to be a darker gray. So maybe we'll just pick
this dark gray right there. It's kind of picking one. And then what I want, you know, how those posts
they have like all these little holes in them. I'm going to create those little holes with the ellipse tool. So L is the shortcut key
for the Ellipse Tool. I've got it. I'm going to just draw
a tiny little circle. And this is hard to see,
but I'm also holding shift. There's a little circle created and I'm just
going to let go. Let's go ahead and zoom in. The shortcut key for that is Command Plus or Control Plus, if you're on a Windows, there's our little circle. And what I wanna do with him, his grab the selection tool. And I'm going to bring
this little circle over to the center of this post. Notice that all
these pink lines, they are smart guides.
You can turn them on. They really help
you line things up, go up to View, down To Smart Guides and
checkmark that to turn them on. All right, I can't
really see this guy. Let's change his fill to white. There he is. And now let's create a bunch of them going down this post. So I'm going to hold Option
or Alt to duplicate him down. You can also hold Shift while you do this to
make sure you keep an inline with the other circle. I'm just going to
give it some spacing right there and let go. Now what we're gonna do is basically duplicate
this a bunch of times. And I can hold Command
or Control and press D. And it's going to continue to duplicate that last
transformation. So just keep pressing
Command and D, Command and D all the way down. I'm pressing that
precedent, person, that person or Control and D if you're on
Windows, of course. And this has taken forever. Is there ever an end? Yes, there is. Okay. So I'm just going to
let it go. Let it go. Let it go, Let it go, Let
it go there. It's close. Now what I'm gonna do is take
this bottom one, click it, select it, hold Shift, select the post itself. So I have the
circle and the post selected. Click on the post. Now we're aligning
to a key object. If you remember gonna grab
that alignment panel again, and I'm gonna do this one here, which is like vertical
line to bottom. So it's going to
take that circle and line it up to the
bottom of this post. Now I'm just going to click
on this circle and press the up arrow key
12345678910 times. We'll do a little something
different on that. On the next part, but that's, that's spaced out
ten from the bottom. Now let's go back up to the top. And we're gonna grab this guy. Same thing, hold Shift,
click on the post, then click on the post again
to align to that key object. And we're going to
align it to the top this time not the bottom. We're going to do
the same thing. We're going to
click it ten times, but this time we're
going to hold Shift and just click it once, the down arrow, boom. So that's an increment of tin. Now that I did
that and you might be wondering, what
are you doing? Basically what I'm doing here, We got to zoom out
a little more, is I'm going to line
up all these circles. I'm going to select
everything here, including the post, that's fine. Just hold shift and
click on the post. Now it's de-selected. Now we have all these
circles selected and only the circles selected. I'm gonna go back
to the align tool, make sure we're aligning
to the selection. I'm gonna distribute
all the objects, Vertical Distribute Center, which basically means
it's going to take that selection and space
out all the objects evenly. So now we have perfect
spacing with all these. I do think those circles
are a little big. Here's what we're gonna do. We're gonna grab them all again, zoom in a little bit. Shift-click the post. Now we have just the
circle selected. Here's kind of a nifty feature. We're going to go up to
object, down to transform, and then we're gonna
go to Transform Each. What we can do with this
guy already did it, of course, is, let's, let's reset this to a 100. So this is what it's
gonna look like. Nothing's going to happen. If you check mark
the Preview button, you're going to see happen what you want to have in and
basically Transform Each means. If you have a number
of objects selected, it's going to apply
this transformation to each of them individually, which is super nice
if you want to transform all these
circles at the same time, I've got them all selected. I'm going to use the
horizontal and we're gonna do 18, I think. I think maybe horizontal,
vertical scale AT, so that's gonna make
them a little bit smaller. Let's do
something like that. And I'm gonna hit Okay. Now I've transformed all those and made them a
little bit smaller. Super quick way to do that. Last thing I'm gonna do because all these circles are
on top of this post. What I can do is just
select everything again. But this time I'm going to essentially subtract all
those circles from the post. And I can do that with
the Pathfinder options. If I go to Window
down to Pathfinder, this is one case where I
would actually rather use Pathfinder than
Shape Builder tool. I always use Shape Builder tool, but this one, I would
rather use Pathfinder. I'm gonna hit this minus front, which basically
means it's going to subtract whatever shape is in front from the shape behind. And that's all those little
circles from the posts. So now we have something
that actually looks like a post with all
those holes in it. And all we need to do
is make sure that this is on the very bottom. So I'm gonna click
it, right-click, arrange, send to back. It's also shift Command left bracket or Shift
Control Left Bracket. Now that it's in the back,
I can just drag it over here behind my stop sign. My smart guides are helping me line it up right in the center. If you want to make sure
it's in the center, just grab them both. Click the stop sign, go to the alignment panel, hit that horizontal
align center. It's going to line
everything up to the stop signs centered. Alright, so there it is. We have we have a post. All right, Let's shorten
this post up a little bit. And then we will also make the stop sign a
little bit smaller by holding Shift and
Option or Alt on that stop sign and just make it a little
bit smaller there. Maybe something like that. I don't know. What do you think? Whenever B flat
design store or comes some kind of little
shadow element, it kind of adds a
slight bit of realism, although half the time the
shadows don't make any sense, kinda like this one here. So to do that, I'm going to do a rectangle with the rectangle
tool shortcut key M. I'm going to just
create a rectangle that I know is gonna cover
up enough of my sign. That rectangle is
white. Let's make it black, just straight black. Now I'm gonna rotate this guy, so make sure you get those
double-ended arrows, that kind of half circle there. Click, rotate, hold Shift, and I'm to rotate it 45
degrees just like that. Then I'm just going to eyeball this thing somewhere
in the middle. So it runs through the middle of my sign ish somewhere
right in there. That's good enough.
Now I'm going to hold shift and
select the sign. So I've got both the sine
and this rectangle selected. Now we're bringing the
shape builder tool double circle with the
pointer over here. Shift M is the shortcut. It sees all these little shapes. I want to get rid of this one. So I'm gonna hold Option or Alt. Notice the minus
under the cursor. Now just click. And now it's gone. Back to the selection
tool shortcut key for that as v by the way, because I got this super
opaque shadowy thing. All I want to do
with that is take its opacity down to 10%. I've got a slight, slight shadow on this. It just adds, it adds a
little something to it. I'm going to add one
more something to it. So imagine. Imagine that you have
this stop sign and below it maybe there's a shadow
down here at the bottom. We're gonna do that
with an ellipse tool, but a really skinny or with the ellipse tool but a
really skinny ellipse. The shortcut key for that as L, we can click and hold and
grab it here just like that. And I'm going to maybe do. I'm just eyeballing this
like somewhere in here, not the whole width of the stop sign,
somewhere in-between. And I'm just going to
click and drag across and make a super-duper
skinny ellipse. Let go. It's all black right
now, that's fine. We do need to center this up. So grab that selection tool. You've got this ellipse, Shift-click on this post, and then click on the post, aligning to that key
object like usual. Grab your alignment panel. Remember Window Align
if you need to. Key object, okay, I'm gonna
horizontal lines center, going to move that shadow
of the center. Perfect. I think I want the
shadow to the very back. So let's zoom in a little
Command or Control Plus. You can right-click on this
or use the shortcut key. But go down to
arrange, Send to Back. And now let's make this
something like 15% opacity. So it's a real light gray. Then I don't think it should hit right at the
bottom of that posts. So maybe we just
click it and bump it down with the arrow keys so that the middle of the post is hitting the middle
of the ellipse. We've got like a
little shadow down there of the stop sign up top. How about the last thing we
do here is add a background. You know, a lot of
those minimal things, they have a cool
colored background. So let's just go back to that. Rectangle tool creates some kind of rectangle around this guy. Just like that. It's whites. Okay,
let's change it. Let's go to the color panel. If we go to Window
down to color, it's going to pop out
that color panel. Remember my favorite
little panel? We're going to drag this hue
thing up into the blue area. And then let's click something
a little bit saturated, but a little bit toned down, some kind of over in here, maybe a blue somewhere
around there. Hit Okay. We got the blue, but we've
got to send him to the back. So we're gonna click on him, right-click arrange,
send to back. There it is. That's a little hot on the blue. Let's take the blue
back and notch there. So I'm gonna click
on it, double-click the fill, let's bring them back. Let's make them
lighter and grayer. Maybe something like, maybe something like that.
Maybe something like that. Alright. Now what you can do
is click on this blue shape Command or Control to that's
going to lock that in there. Then we can select
this entire stop sign. We can right-click go to Group. Now this stop sign is grouped, but we can't click on
this background again. So I want to click on it again. So that is command option
two or Command Alt to, to unlock that background. You can also find what's locked and unlocked
in your layers panel, all your objects and
shapes over here. Notice we have the group
here, you can see it. We have stop over there. You can see that we have
the rectangle here. You can see it. If it's locked right here, you'll see a little lock icon. You can just click on
that to unlock it. If you don't have those
shortcut keys remembered. The reason I did that though, was to group this, this here. And then someone select both this group and
the background. Click on that. I'm just going to center it up. You guys, That's all
I'm doing right now. So bring out the alignment
panel we're aligning to the background
center, center done.
20. Flat Design Christmas Tree: So I'm gonna create a new
Illustrator document. You can go up to File New or on the sort of
splash screening. Hit the Create New button
over here on the left. I'm going to create it
to be 1920 by 1080. That's pixels. And it's
going to be an RGB, which is in the
advanced options if you wanted to change that and
no bleed or anything, one artboard, all
that stuff is fine. Hit Create and we
got a new art board. I'm going to zoom
out a little bit. Now, things look a little
different for you. For instance, here on the right I have the properties panel. That's because I'm in the
2018 essentials panel. So if you want to, you
can switch over to that and we'll kind of base
things on that panel, will open up other panels and windows here that I need to
utilize from time to time. However, that's what
the property section is over here on the right. Now I'm going to try to
design this on the fly. You guys are in the future so
you know how it turns out, we'll see how this goes. However, if you're
watching this video, it must have turned out okay, we're gonna start by creating
a couple of triangles. I'm gonna do that by
clicking and holding on the Rectangle tool and
selecting the polygon tool. Then I'm just going to click
on my Canvas anywhere. And little polygon
dialog box opens up, gives me a radius and gives
me a number of sides. I'm going to change
the number of sides to three because there's three
sides and a triangle and hit, Okay, and we have a
triangle created. Now I'm going to switch back
to that selection tool. Make sure I have it selected. And I'm going to check
the fill and appearance or fill and stroke in
the appearance panel. I don't want a stroke on it, so I'm just going
to get rid of that. I'm gonna hit 0 on the stroke. It's just going to put a
slash through it on the fill. We're gonna click on that
and go with a green color. I want to select a
green color of my own, and I don't really care
for these two panels. So I'm going to open up in the Window drop-down
the color panel, that's F6 as the shortcut key. Now what I like about
the color panels, when I double-click
on the fill color, it opens up the color picker. I prefer the color picker over this other sort of rainbow
color picker down here. But what you can do with
this is I'm gonna take the, I don't know if this is just just the generic color
picker over here, like making it green all over. And then I can select from all my different saturations
and Hugh levels. I'm going to select
something in the sort of grayish green area. We're going to try
for that muted look. Most of my colors are gonna
get picked from here, whether it's a blue or red
or any other color like yellow or yellow might be a little bit more
golden like up here. But anyway, anywhere in that mid-range is
taking that green from a more saturated
highlighted look down into sort of
more of a muted tone. That's where I'm gonna pick
from for the most part. So hit, Okay. And we have a green triangle that's gonna
be the start of our tree. Now what I'm gonna do
with this triangle is I'm going to hold Option or Alt. And I'm going to click and drag this triangle
out to the right. Notice all these pink
lines while those, after I let go and duplicate this triangle,
that's what we just did. This little pink lines
are smart guides. You can go up to View,
down to Smart Guides and turn those on Command
or Control U. That helps us position things
and align them together. Now this color panel I'm going to drag over here
and we're just going to dock it to the
right side toolbar. I'm gonna click this
little double arrow to collapse it into icons. Now it's right here,
that little palette, and I can open it up and
close it as I need it. I'm going to click on this second triangle
that were created. And I'm going to scale
it up a little bit, but I'm going to hold
Shift while I do that so that it keeps
it in proportion. Let's just make this
an arbitrary scaling. Looks good, okay. We want a third part or
third section of this tree. So let's hold Option or
Alt again and click and drag this over to
create a third section. And then this last section, we'll make it the biggest
section and we'll scale it up. Remember to hold Shift
while you do that. Okay, so we've got
the three sections of our tree now we need to align
them on top of each other. Let's just go ahead and
move this guy a little bit so that he is above
the top of this guy. And also let's move this
guy up a little bit so he's above the top
of the middle one. You see how they're staggered. Each of their top points
are above each other. Now let's select them all. And with them all selected
in the Properties panel. And if you don't see
alignment over here anywhere, just go to Window Align any
of the panels I'm using. You can always go up to
Window and then find that panel in here to click it and make sure it's showing. However, with all
these guys selected, I'm gonna use the
Horizontal Align Center on those and it's going
to basically align them. Align their vertical axis
ran on top of each other. So now we have what
looks like a tree and I can mess with this a little bit like the
top part of this. Maybe it looks a little
like the top section. It looks a little small, so I can click that and grab the bottom part
and hold Shift and drag it down to make it a little bit sized,
a little bit better, I think in my opinion, and I can do the same thing with maybe this mid-section
click and drag him down just a touch to sort of space that out a
little bit better, but I like what that looks
like, that looks like a tree. So I'm going to
select everything. And I'm just going
to bring it down here to the center somewhere. Just so we're a little
closer now let's zoom in so you guys can
see what we're doing a little bit better. We're going to
create those three. So we created those three
will create the trunk next and then we'll
work on the shadowing and maybe actually will work on some Christmas ornaments and then the shadowing
and we'll be done. So this will go by pretty quick. Let's go back to
the rectangle tool. We're gonna select that. And we're gonna
create a little trunk down here at the bottom of the base of our tree. Branches. We'll call them our
branches and our trunk. I suppose. I'm just going to
create a rectangle. And that rectangle,
I need to select it again and maybe go
to my colors panel. And we're gonna change this, but double-clicking the
fill and opening up that color picker to
something more brown. So we'll find something in this sort of between
the yellow and the red. Then we'll probably go
something pretty dark here, but still kind of in that
grayish area and then hit Okay. So now we have the the trunk, the base of our tree, and
also the little leaves. And this guy is probably
not centered up. I'm gonna click him hold shift, click the bottom set of
branches, the bottom triangle. Then we're gonna
click that triangle again and it's completely
highlights it. That means I'm aligning
to that object. And what am I aligning
everything that isn't that that object
is one of the lining. So I'm gonna hit this
horizontal line center. It's going to bring that
trunk to the center. Notice that just
bumped it over a hair. Now I know that it's
completely aligned center with everything else here. Sweet. All right. Let's add a little bit of
shadowing under the branches. Then we'll add some ornaments, and then we'll add the
overall shadow at the end. Alright, so what I wanna
do is actually add, I want these sets of triangles to lift off the
page a little bit. What I'm gonna do
is make sure that each one is aligned
where I want it. I want this I want them to be in order from the bottom
to be on the bottom, the middle to be in the middle, and the top to be in the top. I'm gonna take this bottom
section, right-click it. I'm going to go to Arrange, Send to Back, and that's Shift Command left bracket or
Shift Control Left Bracket. I use that all the time. I highly recommend
learning those. You send that all the way
to the back of this layer. This guy is in the middle and then this guy
needs to be on top. So we'll right-click
him, arrange, and then bring to
bring to front, which is Shift
Command right bracket or Shift Control right
bracket if you're on Windows. Now this one's on top, this one's in the middle and
this one's on the bottom. I actually want the trunk to
be the bottom most layer. I'm gonna use my shortcut
key Shift Command left bracket or Shift
Control F bracket. Remember that's
arrange send to back. Okay, that's enough
on the arrangement. I highly recommend
learning those though. Alright, so what I want to do is create a
little bit of a shadow. And that shadow is
gonna be kinda like a little bit of an angle here. We're gonna basically bust
out the shape builder tool. I'm going to create a rectangle first rectangle tool,
shortcut key E M. We're going to make
this rectangle black. So let's double-click
that and just drag this down into the black. So we have a black
color as the fill. I'm simply going to draw a rectangle over the
top of our shape. It doesn't matter how
it's aligned or anything. I'm just going to draw that
right over the top there. Now I'm going to grab my selection tool
shortcut key is V, hover over corners target
the double ended arrow. And I'm going to rotate
this a little bit. Let's see what kind
of angles do we have? So let's rotate it. It's at 0. We're gonna rotate it and maybe just a few
degrees, just like that. Not too much, but
just a little bit. I'm going to duplicate
this guy by selecting it, holding Option or Alt and clicking and dragging
it down here. What we're going to do, and you can see the blue
highlight right now, is we're gonna create a shadow
underneath the branches, just a hint of a shadow. I think the angle on that might need to be a
little bit more, so we'll adjust
that in a second. But it's basically
going to fall, right? Or that blue line is
underneath those branches. So if I let go, I've duplicated that now I have two of them. I'm going to select
them both again, and we're just going to adjust that angle a little bit more. This is completely up to your discretion and
how this angle goes. Okay, now I need to sort of slice and dice this rectangle to leave only the shadowy part underneath each set of branches. Let's zoom in a little bit here. Now you see how this middle
triangle is poking out, just a hair underneath here. I'm going to that's
okay with me. I don't want to cover it, but I do want to move
it down just a touch so that it's only
poking out just the tiniest little bit down there. And I'm going to zoom
out now and select both the rectangle and the middle triangle
that's holding shift to select both of them. And I'm going to switch over
to the shape builder tool that's two circles and
a pointer over here. Shift M is the shortcut. Now, this shape
builder tool sees each shape separately where
these two shapes overlap. I want to keep this
piece over here. What I can do to separate
that is just click on that. Now it's created this as
its own separate shape. And I'll show you
if we go back to our selection tool and
click off of everything, click onto the rectangle. Notice how the rectangle doesn't select the whole
thing now it selects everything else
that's left over. I can just hit the
delete key on that. Now I have this shadowy layer underneath this middle triangle because we basically added, segmented this shape off. Okay? Well, now I want it to only overlap
where this triangle is. I'm going to select
both of those. Shift-click. Use my shape
builder tool Shift M. And now it sees where
all of these intersect, these bottom triangle
and the rectangle, if I hold Option or Alt, notice my cursor
changes to a minus key, I can click on this outside
shape and it gets rid of it. I still have this
little shape over here. We're going to have to
zoom in on him to see, but see how I have a little
triangle poking out. Well, if I hold Option or Alt, I can subtract out
that shape as well. What am I left with? Just the shadowy layer
underneath that set of branches. And on top of this
triangle down here, Let's do the top one, but we'll do it a
little quicker. I need to move him
up a little bit so that the bottom of this
triangle is poking out. That's going to give us the segment we need
over here on the right. See how he's just poking out
just a little bit down here. Okay, that's perfect. Now I need to select both the top triangle
and the rectangle. Go to the Shape Builder
tool Shift M for that. And notice how we have
all these sections. Just click on this right section
and it's going to create that shape for whatever
reason that it filled it in with
our green color. That may be a feature of the
shift shape builder tool, but we don't
necessarily want that. We want that to go to black. So I'm gonna switch back
to the selection tool. Click on that guy. We're gonna fill him
with black instead, get that thing back to normal. But now I can click
on this left section and just delete that out. So we deleted out that rectangle because we created
this shape over here. So now we select the middle
triangle and this guy, and we're going to do Shift M
for the shape builder tool. And now it sees everywhere
that these two intersect. So we're going to
hold Option or Alt, subtract out the right side, zoom in and find your way to this triangle and
subtract him out. Then we'll zoom back out. And now we have that
shadow as well. That was a real long segment there on the shape builder tool. I'm going to select
these two rectangles. Now, we're going to pull
them back a little bit. Let's just change the opacity. Maybe there's something
like 50% on those. So it's just a bit of a shadow. That's pretty cool.
That's pretty cool. Minimal tree. I actually like
that better than my other minimal tree tutorial. But what are we gonna do now? Well, let's add some ornaments. We're gonna do that by
selecting the Ellipse tool, that's the shortcut key L. And we're going to
create some circles. And these circles are
going to have colors. And we're going to make
them a certain size. Just click and drag
to make a circle. You can hold Shift
to make sure that circle is a perfect
circle shape. And let's create some colors. We're going to go back
into that color picker and remember back in the red. So we're gonna take
like a muted red tones, something in here. It's almost even pink. We're going to drop him on
top of this tree right there. And then we can
hold Option or Alt. And we can just click
and drag and place these ornaments around our tree sort of haphazardly
however you would like. Maybe there's one on
the top and three in the middle and then maybe four on the bottom,
something like that. But let's make
them all different colors right now they
look like berries. So let's take this one and
make it more of a blue color. Now that this is selected, you can just change where this falls to change the color of it. That's a little too
close to the green. We want that to pop a little
bit more off of there. So maybe we'll make it a
little bit more highlighted. There you go. We want this
to be maybe a yellow color, so we'll just switch this. You can just make these whatever colors you
want them to be. We could do like a purple
here, purple, pink, whatever. Just make this however you want. And now we can leave
one of these red. We can click on this and maybe I like that yellow
so I can hit the I key for the eyedropper tool and just click on
that yellow on. It, changes it to that color. That's perfect. I still don't like the
way this blue pops, so maybe I want to adjust
these a little bit. There we go. That pops
a little bit more. So let's grab, let's grab this one here and we'll
add drop her that blue. And then this guy in
the bottom right, we'll just click and
hit I to eyedropper, that purple. There we go. It feels like we're a
little blue on this side. So I'm going to swap these two. We're gonna make
this one yellow. And we're going to make this
one, maybe this one red. And so there's not
quite as many. And I'm going to switch this
one. This is what you get. I'm gonna switch
these colors around, but you just make this thing however you want. There we go. That looks better. We have a Christmas tree. Let's create some more
shadows with this guy. Okay, so in the old version
of this tree tutorial, I didn't use the
shape builder tool much and now that I know it, I wish I didn't
know that before. I'm gonna select
this entire shape and we're going to
group it together. Right-click, go to Group. Perfect, everything's grouped together now I can
move them around. I can also scale
him up and down. So let's zoom out a little bit, see how big he is on our Art board here. I'm going to select him and
go to the alignment panel. We're going to open that up because I don't see
it to the right. I'm going to just
drag him in here. There we go. We get the alignment panel open and I'm going to align him. I'm going to show options on
this guy because we need to align him to the art board. Once we have that guy selected, we can center him vertically, horizontally there he is in
the center of the artboard. I'm going to grab the
entire tree and just hold Shift and Alt or Option. Scale him up from the center. We're going to make him
bigger so that you guys can see him better. There he is. All right. Now, we are going to create a shadow on top of
this entire tree. And oh my gosh, this is such an easier method than
I've ever done before. Select the rectangle tool, checkout the fill and stroke. Whereas it, I'm gonna
make my fill completely black and then make
sure there's no stroke. I'm just going to create
a random rectangle. Doesn't even have to
be a perfect square, but I will align it to the
exact center of my tree. And I'm gonna make sure
that it's in the center by making sure that the
smart guide is telling me, Hey, we're in the center. So right there,
it's in the center. Perfect. Now I'm going to
select everything. And then we're gonna grab
the shape builder tool. Just Shift M to grab
the shape builder tool. It recognizes where the tree
and this rectangle overlap. I want to get rid of
this outside shape. So I'm just going to hold
Option or Alt and click on it. Boom, we only have the shadowy rectangle on the right half of
the tree there. So I can take this guy and
bring his opacity down. Maybe they're like 25%. And that creates that shadow on the right side of the tree. Now, maybe I don't want it to
be on top of the ornaments. Can you tell that it's
covering up these ornaments? So these are a little dimmer
on the right and these are, see how it's kind of cutting
it into this guy here. Well, I can always just click
and drag this guy off here, grab all of my ornaments. If we ungroup this tree by right-clicking Ungroup,
now it's all ungrouped. We can grab these
little ornaments and we can just select them. Make sure we've got them all. We can group them together
on their own group. And we can bring them to the
front by right-clicking, arrange, Bring to Front. They are on top of
everything else. If I drag this shadow
back on top of the tree, which it did not drag
exactly in the right spot. So I'm gonna zoom in and
sort of make sure I see these two points are really zoomed in and if I drag over it, we'll make sure to intersect
right on top of those two. That's perfect. And now the ornaments are on
top of that shadow, which kind of helps make
it look a little better. We've got the shadow, we've got the ornaments, we've
got everything. How about a long shadow will create a long
shadow and maybe it will create a
background layer color. And you note one
other thing to note, I don't actually like how
this overlaps that shadow, so I'm just going to
bring this ornament, I'm gonna double-click
to go inside that group, kind of isolate that group. I'm going to bring
this ornament over just so he's on the left
side of that shadow. Just so we're not sort of
over the top of that shadow. So it's a cleaner design. But we're going to create a
long shadow with this guy. We need a background. Let's do like a background
of maybe a red. I don't know. We'll try this. I'm going to hit the
rectangle tool that's M. I'm just going to
create a shape that's the entire size
of our art board. Those smart guides help
us lock it into that. I'm going to click
the selection tool, right-click on this
shape and Send to Back. Now it's on bottom
of everything else. I think that these
clash a little bit, so I'm gonna click
on this red color. Go to my color picker
and we're going to find a color that works
a little bit better. It might need to be a lot
lighter, in that case, which we can make it
lighter and maybe a little grayer and hit Okay,
and see where that is. That's good enough. We have a Christmas tree on
sort of a grayish background. It's a little bit warmer gray. I'm gonna click on
that background and lock it into place by hitting Command or Control
to on your keyboard. Now I can't move that
background around. So let's create a quick
little long shadow. I'm gonna do this different
than the other tutorial. There's tons of tutorials
out there on this. I'm just going to
create a rectangle. And that rectangle is going
to start at this top point. And it's going to
end at the bottom of our tree and just
extend outward. There it is, there's our
rectangle right now, use the same color
as our background. So let's change that to a
black so we can see it. We get this black rectangle. Well now what I
want to do is just take these two points on
the right and move them. I want these two points
to stay in their spots, but I want to move
these two points to adjust the angle
of the shadow. So I'm going to hit the
direct selection tool not to selection the
direct selection, that's shortcut key a click and drag to select just
those two points. And now I can, now I can drag this shadow around
and change the angle. And also I can
stretch and skew it. I can take it beyond our art
board down here and maybe, maybe just at whatever
angle you want it to go sort of like 45 degrees
is what I got it there. Okay, so now we
have a shadow going down and then back
up to this point. We can send this guy to the
back by right-clicking, making sure he's
selected right-clicking. And hitting arrange
send to back. He is behind the behind
the background layer. So maybe the background should have been the last thing we did, but we can hit Command Option
two or Command Alt to, to unlock all of our elements. And we can send
this background to the back again and lock him back in with Command or Control to now the
backgrounds and the back. And we should be good here. We have a shadow, but the shadow is super, super, super, super,
super, super dark. So I want that to
be not so dark. So we're going to
change that to be maybe, maybe like 50%. And we should also potentially
have a gradient to this. Let's add a gradient. We're
gonna select this guy. We're going to select
the gradient tool, the shortcut key for that is G. And I don't see, well, if you're on 2018 tool
options pops up here or you can go to window
down to gradient. And then that gradient
panel is going to pop up. And if you select this, it's going to immediately apply
a gradient to this shape. I'm just going to apply
it from left to right. So we want the left side
to be the darker side. First thing I want
to do is make sure both of these are
the black color. I'm gonna double-click
on this color swatch here and change it to black. Now we have black and
we have black here. And the other thing we want
to do is we want to go from a 100% opacity
to 0% opacity. This right side, we're
going to change him to 0. The opacity. Now he
basically goes from completely opaque to
completely transparent. But it goes not at the
angle of our shadow. So once you get that
shadow angle figured out, just select the gradient
tool we have it selected. And notice I've got a
certain cursor out here. I can click and drag to change the angle and
distance of my gradient. It's going to end
wherever I let go. And it's going to be
at this angle as well. Fed drag it down here. Now the gradient goes at the
same angle as our shadow, which works out pretty well. I'm gonna hit the
selection tool guy here and we're gonna
take a look at this. One thing I don't
like is I don't like where this shadow starts. So maybe we can
click on this guy, use our direct selection tool. Click this very bottom
point and bring that over to the right
side of the trunk. I think the shadow
would start from there. It kind of makes
sense for it too. And now we can zoom out. Now we have this
long shadow that extends beyond our art board and it also goes from opaque
to a more transparent. And we can adjust that as well. We can take that down even
more with the opacity level, maybe the twenty-five
percent or even 10%. Just so we have the tiniest hint of a shadow behind that tree. You can always click
that in whether it's a circle shape
or maybe you want to clip it into this rectangle
by selecting both and right-clicking and
making clipping mask out of those two shapes. But for now we just
have the shadow itself. And that's it, you guys, this is the minimal Christmas
tree that we designed. You can adjust all these colors to be what you want them to be, changed things however you want. But that is a version of sort of developing
some flat minimal art. I hope you guys enjoyed this tutorial and I
forgot one thing, don't forget, we need to put
the star on top of the tree. Holy cow, how did I forget that? The star, we have the star
we want the fill to be. Yellow ish. How about we just use our eyedropper tool
and we'll just click on one of these
yellow circles. That is not the eyedropper tool. There we go. And remember
I for the eyedropper, it's over here in the toolbar. We're just going to
eyedropper that yellow click on the Star Tool. And we're going to
create a star at the top of our tree here. If you hold Shift, it'll
be like perfectly aligned. However, whatever size
you want it to be, boom, there's our star. We're going to zoom in and sort of put it right on
top of our tree. Let's zoom in a little bit more. We're just going to align him up right there on top of the tree. And what you can
do now to change this shadow is you
can click on it, use that direct
selection tool again, click on this 1 at the
top of the shadow and we can bring him up hold
Shift to keep him aligned. We'll bring him up to here. And one thing that's going
to happen is it's going to change where it sort
of hits down here. So we could move that
star down a little bit, sort of cover that up and really place it on
top of the tree. And then also use that direct selection
tool to click and drag that shadow to
the top of the star. So the shadow comes from
the top of the star. There we go. That star doesn't pop out from
the background very well. So we could always change the background color
to be something else, to be something darker. I'm going to go
ahead and do that. We're going to hit
Option Command and two, or option control and two. And we're gonna
change that color to be maybe a little bit darker. Still. Warm. Hit. Okay, now we can see
all of the star and everything doesn't blend
into the background very, very much. Okay, So there you go. That is your minimal Christmas
tree with the star on top. Almost forgot that one. That's what I get for doing
this thing on the fly. I hope you guys learned
a ton in this tutorial. If you have any questions, make sure to post
those questions below, and I will see you
in the next one.
