1. Intro: Welcome guys. I'm so excited to
see you again with the great course today about an iPad
concepts application, which is vector-based
sketching tool. And much better than
any other, I would say, for creating architectural stuff and
architectural sketching. So if you are a fan of
Procreate or more fully, I try them as well, but this one is great because
anything you will draw, you can change
later if you need, right away, you don't
need to use only an iPad. You can use as well
the Samsung tablets or any other Android
tablets because concepts are
supported as well for the Windows computers where
you can install concepts are. My name is delivered during lab. I teach architects
like ten years already how to
present their work. Simple, quick, but very
understandable for clients. These little trainings are
based on that knowledge. And maybe you saw my
first two classes. If not, I totally
recommend to take a look. This course is
mainly about behind the scenes to see how
architects creating diagrams. So this one is pretty simple,
very effective methods. Thanks, all iPad and
concepts application.
2. What we will do: We will do a diagram of this great innovation center
from Alejandro Aravena. I found a very nice photos. So tweet on design website. We will use for that purpose, this photo because it's from the perspective
bird's-eye view. It's nice to sketch on it
and to find a module and then change it for diagrammatic
approach in four steps. But if you feel you have your own idea or your own
building, you can use it. No problem. Follow
only few rules. One of them is find a cubical
shape and not organic shape and try to find something more with perpendicular
angles as well. The photo from the
bird's-eye view. So you can nicely analyze. And because of symmetrical
diagrams are made from 45 degrees angle and from a bow to not distort the
dimensions of the building. So this is the task projects
and looking forward for your interpretation because
you can play with colors, with arrows, with a thickness of lines, etcetera, etcetera. So let's go dive into it.
3. Intro to Concepts App: Let me quickly introduce the concepts up because
if you are new in it, it can be quite overwhelming. But no worry, it's
a very easy and you will learn as we will
go through the sketch. So what you can see here
are basically projects. So this one is called
VSwitch for me, but then you can have like other projects and then my own, you can set up your own project. How ever you want to call it. Then in project you can
set up sections. So e.g. as I have like section on
the Skillshare classes or my manuals or know-how
or advertisements, marketing and other stuff. So we can set up these as well. I recommend to set up
an inbox section so you can click on a section
and renamed the section one. We hold down finger on
that and rename for the I will click on the
inbox and hit Okay. You can see they are arranged
according the alphabet. So I found the best way. What you can do is to put a z in front of the inbox or x
in front of the inbox. And it will be sorted in the first order because
I can reorder them. But when I reordered
from alphabetical order, then my sketches are not ordered properly because
I'm using a date. I use year, month, and date in front
of any document, which I recommend
to you as well. And in this case, I use usually reversed
alphabetical order. So let me hold
down the renaming. And I will go here
and write e.g. Z dash. And you can see here is that the green box is my first one. And then I can rearrange
document if I need. And this is like my
Started document. Okay? And if you need to delete some or if you need to
create a new document, hit blast and click New Drawing.
4. New drawing setup: Alright, in new drawing, it's recommended to make your little arrangement because original arrangement is
something like this. The wheel and pellets are
somewhere here, et cetera. So you can very easily drag the wheel with the holding
down the finger on any tool. And then you can go
around the position where the tool or wheel is
available to place. But you can leave it
here if you want. No problem for me. I like to use it as in other softwares as a
vertical fella tool. So I will go for
debt position and I will release the finger. So this is my tools. You can see that each tool, if you swipe into the document, you will see all other all
other settings on the tool. But no worry, we will
go through that. But other staff, what do you need to set up these pallets? So usually import export
layers and precision. And if they are
distributed somewhere else in your documents,
something like that. Let's say you can go and
gather them into one place. Again, I use the
composition from the computer as I am used to have all pellets in
one place so viable. Bring the layers back
or below the export. Led me bring precision
moles here, right? So this is it for
the beginning and one more or one last
thing before we will dive into when you hit
the little wheel here, it's good to see if you
have a stylus, e.g. in my case, Apple pencil, but you can have whatever
pencil you want. And it's important. You can check the
finger action for me is panning Canada so I
can move the cameras. And for the double-tap, I have usually a color wheel. So you'll see if I will bring my benzyl and go
for a double top. You can see all capex
if you like markers. So these one is like
infinite markers. So you will nicely go through
them. One more setting. Here we go two gestures. And in gestures, when you tap
and hold with the finger, I want and lasso. And if I tap with two fingers, I will go undo. And if I tap with three
fingers, I will go redo. And if I will top of
your four fingers, I want to toggle
in for interface, which will give me a nice
clean, a presentation view. Jump out from the document with the little four squares on
the left, top left corner. Alright, so we did
a nice setup and now it's important to rename the document
because I'm titled, I don't like this. So usually you can do it like tap and hold
for longer time. You will get the renaming here. You can write down
your year, month, and then I will usually
write down the date, but for now I will use double d and then the
name of the document, name blonde or something
like that, Dan. And these ones will be, as you can see, I
will delete this one. This will be our
starting template. You can use this template
when you hold down this, again, the finger and
you can duplicate it. Okay, so we will get
like the name too, and you will see is on
the first position. And I will hold down the
finger again, rename. And I can rename
that for diagram. And you can rename
as well the date. So e.g. 01 or
something like that. Okay. So what is your date? Write down the
date, enter, done. And let's go into now
you can see the diagram. The template will remain
as the first one, but the diagram is like
the next document, so I'll click on it.
Alright, We're ready.
5. Importing the picture: Right, So the picture you should download from the
sources what I provide you and then drag or transfer it into your
photos in your iPad. So for me, just swipe up
a little bit your dock. And here is your photo app. So just click and drag somewhere on the right
or on the left side, I will drag into the right side. And here in your photos, I zoomed in a little
bit with two fingers. You can see your photo. So very easy. Just hold top and drop anywhere in your document and you will see
the photo, right? So that's the import. And now grab the Pencil. Because we will do a quick
analysis of the building. So we will know
how many roles or how many columns we need
to make a nice diagram.
6. Does building have columns?: We need to analyse the building. So lets me draw some lines to see how many columns we
can find in the building. It's necessary to maintain the right proportion
of the building. So that's why whatever tools
you have here, no problem. You can click in some of them. And if you want to set
up the proper pen, just click one more time with finger or with the Apple Pencil. And here you can find the basic tools or you can
find whatever other tools. But for now, I would go for
classic normal default ban. So I recommend as well. We don't need to, we
don't need to set it up. Anything. We can just click and you can just pick
whatever color you like. What do you prefer?
So just double-tap on your Apple pencil
or click here on the wheel on the color and choose whatever color
you like. So e.g. I. Can go for orange or blue one, as in my promo picture. And I will go with the thickness of the
band, the first value. So go for a thickness like 0.1. And then opacity is
the second slide. So I will go for 100. And then the next
is the smoothness. So from zero, which will give you lines like this, these way. If you have, if you
have your line, like squiggle something, then you can bring
the arrow tool. If you don't have an
arrow tool just to tab and take the tools
of the selection. And with the selection
tool down there, you can pick like item
picker for the lasso. So we have the last saw. You can make a selection
with the item picker. You can go with the cursor
and you will find the line. And then later you can
set it up very nicely and change the dimensions of the line and the smoothness
of the line as well. So this is the strong point of the concepts because
you can change afterwards anything
what you draw there. So here we have a line
and we have rotation off. So I will click on that
and you can feel free to Zoom it or scale it as well, rotated so nicely aligning with the first edge of the
building, something like that. And then I can do
like duplication. So I will do a
duplicate of the line. Click here on duplication. These duplication
of the line I will place somewhere
here and de-select. So this is like
one module for me. And then I will
select two of them. For debt is better
not to item beaker, which is also possible
like the top and top. But I prefer the lasso. So I click on the item, Picker, get lasso and just do
a lasso with these. I selected the picture
as well. You can see it. So just two-finger
stop going back. Click somewhere else
to de-select routing. And in layers, I need
to do two things. First one will be turned off
automatic sorting of layers. So click on automatic, you will get manual sorting. And then from the image just
tried to select two lines. These two lines, I will move
to my panel layer like so. And the image layer
click on the name of the image and
click on the lock. So dead will lock
the layer you can see next to your eye it's
very small, but it's there. So it's locked. And now just click on a pan layer
and you can continue, or we can continue with the duplication of
these two lines. So bring me back the selection. Just select these two
lines, duplicate them. And now I can nicely
duplicate them like as well to align with
the previous one. Duplicate again, duplicate,
again, duplicate. And just always cover one
of the previous line. And because it's in perspective, you can see that we
have like 1,234,567.5. So we can say, okay, seven fields are enough. We can stretch it, which is also very nice concepts because when you
grab with the arrow tool, you can select all of
them with this lasso. Then you can strategy dam or you can scale them, etc, etc. In some cases you can see
also scaling of lines, which is because you don't have stretching but you have scaling. So here, down there
are three options. You can stretch, you can scale, and you can scale off. No transformation
points are possible. I will also disabled rotation. We've click on that and make
sure you go for stretching. And then you can nicely
stretch the lines, something like that because
it's a perspective. So of course we have
some deformations here. But for these purposes, just quickly analyze how
many columns do we have. It's quite okay. So I will deselect, Duplicate these three, and duplicate it here
because then I see that these extension of the building will
go for two modules. I will bring another color, let's say like orange one. And we my proper pen
with zeros smoothness. I can write down that
this is the 12345678. We have eight columns
here with the orange one. I know that this is 42
roles as well, right? And here you can nicely see, let me bring another
blue one that we can have the window
like for two rows, something like that. Okay? Then we can have a
window for three rows. One is empty, again
for two rows window, and then we have
an extension here, again probably for two row, two columns, two columns, 32. Okay? So this is the
way how you can quickly analyze how big the windows will be and how many
columns do we need for proper designing
of diagram? Great. On the other side, probably
we can do the same stuff, like one empty to four columns. One empty too, for a
window, and one empty. Okay? So what have we
found here is 13467, seven columns in this side, and eight columns on
this site would be nice. Perfect. So this is the
quick analysis of columns. Let me do an analysis of rows. How many rows do we need?
7. Finding rows module: Let me make another layer, bring another layer
because this is the big advantage of
digital sketching. And let me bring the
100s smooth line. And I will go with the green. So we can also see, and I will draw a one line here. What I recommend is to draw with the proper size of
role as a column. So I will select these line, duplicate it a little bit down, de-select, zoom in
a little bit and to see if I'm on the
proper size of my grid. And then I want to
re-select it back. So this is just the step
back with two fingers stop. So tap and you will get the selection of the line,
something like that. Duplicate it again
to get another one. And now I would like to
duplicate all three. So I will select all
three and duplicate it down there.
Something like that. Okay, and now I can see
quickly see that, oh right, the 1234 rolls nicely aligned with the first window and as well we have
the second window. So I know that I am doing the right duplicate four
of them down there. Something like that. Very nicely aligning
here, you can see. And I need to Three more, select and duplicate
it down there. Something like that. Nice. So now we see that our
window will be here. Here as well. Here. And the entrance here. And we can count the rows, 11 roles as well for another
side of the building. And these will be quickly defined during the sketch so we don't need to
analyse it anymore. Alright, so we are now
prepared for doing a diagram.
8. Let's set up the iso-grid: Right way defined nicely, eight columns versus 11 rows. So let's go to create
that kind of cute. And we set it up our grid
for a diagrammatic approach, we will use the precision moles. So go for a precision mode. And here you can see the grid, so we can turn on the grid. But if you don't see
the isometric grid, just click on ISIL or whatever
you have written there, like dot grid, e.g. and change it for
an isometric grid. If you change for isometry, click one more time
for isometric grid. Here you can see you can
nicely set up the grid. So for my use here, 10 mm or too much, I will go for 5 mm per grid. And the line weight, e.g. we can go for a
bigger one, likes to, to have it more visible for you, but you can leave it
for one point as well. You can change the colors. I will leave it for a blue one. And then you can go back
or just stop somewhere in the empty field
in the document. So you can see nicely the grid. And then later we will
use the snapping tool. And then snapping tool, you need to have a snap to grid and Snap to Grid
during the edit. And in our layers, we can click on a new layer, which will be the diagram. So I will click one
more time and rename that layer for the diagram. You can do it with
the Apple pencil, you can do it with the
keyboard as you wish. So let me show you here like so. And I can write diagram, not anagram about diagram.
9. Draw an iso-cube: Alright, and I will start
with the green one. Then a lighter, I can change it. So eight rows. I will start drawing. And now, and now
you can see that even I am not smoothing
my line at all. I will get always
very straight line, 345678 because of this snapping. Okay, so I have eight, then 11 down there. So let's go 12345611. And in the other
side we have 77. Okay, but we are going
into the picture. So let's do move further our
cube and finish it there. So I will bring the selection. And in the selection
I will select everything and just move it. And during the
moving you can see snapping points are
snapping because I have my snapping also set up for while editing so
it snaps to read, just reselect,
de-select everything, bring back the tool, the drawing through,
and just draw a line. Something like that. And let's go finish the cube. Something like that. Perfect. So this is our first
first step in our diagram. Let's do duplicate it and we
will start adding details. Duplicate and move it here.
10. Drawing extensions of the volume: In this stage, let me add the
extensions of the building. So here we have two extensions. So I'll bring again the ban. And these extension is somewhere here for two rows, right? And then according analyses, in the row of seven, we will start with the
extension of another part here. Okay, so you'll see
how snapping works. I can make a circle
polygon, old circle, right? So 1234 from down, I can start from four from down. 1234 from down, and going to nicely like so. And we have, in our sketch, you can see we have some
entrance here as well. We have some additional
extension back there. So let me draw here a little extension,
something like that. Here on top we have
some opening inside. So this is the beauty
of the isometric grid that you can quickly draw
and simulate the depth. And because we have some overlapping lines and
we don't want to them there, we will bring another tool
which is a slice tool. But if you don't
have a slice tool, click on any tool, what you have, just
double-click on any tool. And you can change the tool, like if you have a hard mask, let's say you can click on the slice and then
tap somewhere else. With the Slice tool, you can define the size of your slice, like slicing knife. And I will define very small
or something around 1 mm. Because then it's very
easy to go and just slice the line if I
made any extension. So e.g. here, I can slice
something like that. And then I can go with the
arrow and select and delete. Okay? In the concepts basically
you don't need to erase. There is no eraser. You basically slides
because it's vectors. Because then later
you can select and change the size
of the vector. I will bring the
slides again here, a little slicing line. Well here. Okay, then I will
select and delete and remove as well
some extensions, unnecessary extensions
as well here. And here. Perfect. And these line
probably don't need to be here because it's
one in one phase. So I will remove. And now I can go with the selection and
just select, Delete, select, Delete, select
and delete, right? So that easy, right. Select, Delete, select Delete. So we will, we learn how to quickly select how
to delete the staff. And in the next phase, we will add some windows.
11. Windows pre-drawing: Right, we are in
the next phase of the building and we want
to add some windows. So firstly, try to set
up some dotted lines, like here will be the windows. So I will bring again the pen, but I can change the band. When you scroll back through
the dotted lines about, you can see already I have my dotted line here,
but no problem. I can later switch back or
you can select any other two. Quick click and go
for a dotted line. Dotted line I want as
well, the green color. I click on the color. And you can see here is a
little watch in these color. That means that this
color was used, the leg last one. So I will select that. And now we can
take a look where, where the windows row or column 76 and then 2347644 rows. So go back. And let's go seven round 23476. Here is the first window. The second window will go here. I remember something like that. Okay. And then we will
have some entrance. It's below and one more
window next to the extension. So bring here a little window and bring the entrance parking. So this is like the symbolic
state representation where windows will be. And then later we can show
our point there with arrows, so it will be nice. And on the other
side we have window, say on the same spot like this first window down
there for two columns, then break into other columns in the same high height
as the second window. So here will be
the first window, then the break and
the second window. Perfect. This is our simulation
of windows. Now we can duplicate
it and change it. Right.
12. Drawing the depth of windows: So now let's go
change the windows. And this is the great
advantage of the concepts. Because when I select
these windows, I can simply change
the tool, e.g. for the line or for any other
or four to feel if I want. But I will change for
a line right now. And the same stuff
I will do here, quickly, selection and
change for the field. And we forget the entrance here so we can add the
little entrance. Like so. And this one will go back. Yeah, let's make
the shorter line and the slice tool
like an slice, these as well as these. And we can add the depth. So I will select the
line as well and we'll go for the depth of the windows and make extensions if the, there are some missing them. So it's quite satisfying, right? If you're drawing a
depth very quickly. And with the selection, just select and delete perfects. Then voila. Okay, so pretty easy. In 10 min, we did a
very nice building. And now we just need to add some colors and some outlining called the
building. And that's it.
13. Draw some shadows tricks: In this phase we
will add shadows. And as well, I will change
the color a little bit because the green one can
be a little bit invisible. So let me select everything together and let's go for the blue one or
for the orange one. Okay. Yeah, because I have a big
grid than the blue color. It can look a little
bit problematic. But at the very end, with the Export,
it will be nice. I will bring again
the Slice tool. I found that these lines
don't need to be here. So I sliced it, select the lights, deletes, and I will move this a little
bit to get proper aligning. If it doesn't work, I can delete as well these
and just draw a new one. So make sure nicely fit,
something like that. And I can select and go
forward to blue as well. And now I found as nice
complimentary color to blue one, I found an orange one
that I would like to use. If you don't have these colors. Of course, you can use
these little trick when you go for a color
which you used, e.g. the blue one right here. And I will open up
the color wheel and set up the blue
color down there. On the other side. All the way up is
complimentary color. So you can see
something like orange. And of course you can choose
something more nicer, not so dark here. So I used this orange color. That's why I found these
colors is very nice. Of course, you can
set up these colors and save them for later use. Here is a little star. So when you click there, you can find like
different colors. These orange color you can bring and pulled into
your palette, e.g. or create your own new ballot. And then click here and bring
the blue as well, etc, etc. So then I can select
this as my palette and just swipe here all the way to my delight
of two colors, e.g. okay, so now I will
bring the orange, but not for lines because
with the lines, right. But I will use the fill. So if you don't have
fill yet, again, choose whatever tool you want, click twice and go in
the basics all the way. At the end, there is a field and feel we will use only
something like 50%. Or let's start with
something like decent ten per cent of shadow. Then per cent nice. Then we can bring these
orange color for some faces. What is good to realize from
where the sun is shining? Therefore, I bring the
orange turn off snapping. And just drawing that
here is the sun. And the sun is shining like so. So we will get shadows. But of course, let's do another
layer that will be safer. So I will bring the selection, Select, go for a new layer. And this layer
rename for shadows. Go back forward, feel, and don't forget to
turn on Snapping. So I turn on snapping. And let's go for a feel
of a little orange color. So as well here. Here will be, we have
to be very careful. You need to be very careful. If you will go a little
bit out of the line, something like that,
then you have to go back and later we
will deal with that. And here we have a Windows. So I have to go around the
windows and going back. And because we have
a snapping if nicely snaps around the grid. Okay. And then I see I
need to go all the way up. And again, if you mislead
somewhere here or so, you can go back in the same direction and then
continue all the way top. So in the one, again, if I, if I will go for item
picker in one line, I can do this full phase. Of course it needs
a little practice. So don't worry if you will not
make it in the first time. But no problem, you can
redo it one more time. Take your time. I will do another
faces here as the, as the same aligned faces. So this phase, what I
did already probably will be in a different
shade, but no problem. I will continue with
the inside faces. This one as well. These one, right? Yeah, you see, here I made it smaller. Alright. So now I believe, yeah, these phase as well needs to be made so very
quickly, but nicely. Of course, you can do it as well on 22 times one. And then the second one. The only thing is
you don't want to go over because if you we'll
go over, you get darker. Shade. So make sure you will go only to the line
where you left off. And now you see it's very nice. Okay, So I made several
shades on this phase and then I can select this face
and make it a little bit darker because
ten is already baked. So let's go for 2021. No problem. And then I can bring it in
again and go for 21 or 20. And we draw faces
which will be darker. So nice. Here probably don't need
to be aligned again. So I will go into my
diagram with DoubleClick. This is isolation mode. When you double-click
on the miniature and bring the selection, select these lines and delete perfect and
double-click again. And here I can see that e.g. these phases, which are a little bit
in back, can be darker. So I select it with my
item bigger right now, and tap with my finger
and bring them like so. Okay, and make them darker, elaborate a little
bit before 3,030.30%. So it will give you a
little bit depth into a diagram and select
these two as well. Then go for it dirty. So I think we made a
pretty nice job with that. We have a three shades here. We can double-click
on the shadows. And you can nicely see our tree. Shadow colors. Again, double-click back
and we can go for outline.
14. Outlining of the diagram: So we are in the final
of our diagrams. Here we can see the
process of the diagram. And here we can make an
outline of the building. And of course we can make an
outline of all the links. So lets me, let me bring the, the pen, classical pen, the GluA1, about for now
we will go much thicker, thicker like 0.4, 0.5. Don't forget to
turn on snapping. And now we can of course turn, make a new layer, which we will rename
for an outline. And we can go for an
outline of the building, which will bring more
consistency into the hall. The volume. Again, one tap with two fingers, you will quickly go back. Hi, can use also the selection
tool and make it smaller. So this is our first one. And if I double tap on
that outline thumbnail, I can bring the selection lasso. I can do the selection right? And then go back into all
layers visibility and just duplicate and shifted to
my previous building. And probably it will not fit so I can turn off snapping and then it will be much easier,
something like that. Okay. And for next stage as well, and double-click, double-tap
and just bring it here. Okay, The last one I should
do manually snapping. So now we see or our outlines probably
they should be darker. So how easy I can
make them darker. Double-click on the
thumbnails of outlines, select them, read them. Lasso Tool, and go
for a darker color. So I just click on the color
and pick a darker one. Double-tap on the miniature. Nice.
15. Diagram's arrows: The last thing, what do we
want it to add is arrows, because arrows we used in architecture very often to
show that something is pushed, that something is extended, etc. So these are the little arrow. I can design a new
layer, rename arrows. And I will bring the blue color. Of course, I can choose
the darker blue color and I can change that as well
in my favorite colors. Bring this color here. And these blue
color we can delete just holds with the stylus, drag it out, and
leave and release. So you will get two other
colors and the arrows, let's go draw an arrow up here. So I will bring this much
smaller line like 0.1 again. And I will drag
something like here. Here. Two lines, two lines, and the peak of that arrow must be
somewhere in the middle. So let me turn off snapping, but bringing 100% smoothness. And now when I will drag, I can drag the line
somewhere in the middle. So somewhere here and
from the other side, summer here as well. Okay, So this is the arrow. And for our purposes, we can make it a little bit. We can make it as a group, which is also very good. So bring the selection lasso. Let's make a selection of that arrow and
click on the group, which will make a
group of the arrow. And now we can play
with the thickness of the arrow if we need as well. We've the field I have here, my fill with the white color. And here is the
trick how to make the white fill as the bag color. So I will make another layer. And this layer I will bring behind the arrows,
something like that. With these white color, we want 100% with no snapping. I can easily drag. It's almost invisible. So let me use the
orange color for you. So you will see what I am doing. Something like that. It will
be the background color. And now with the selection, we've item picker I can select and change
for white color. And because it's
the layer behind the lines of arrows are about. And I can do another trick. And that is the combining of
these two layers very easily click on arrow and click these
double arrows down there. And it will brings two layers together and select
everything and group. Then you have very nice tool. This arrow we can select right
now because it's a group. So it's perfect and we can play with the position
of the arrow, e.g. here, we want to show that these will be the whole inside. Then we can duplicate it. And we can show that this one
will be the window inside. But make sure you don't want
to change the size of arrows because then you will have like different hierarchy in arrows. So let me click with
two fingers back. One more time, one more time, and make sure turn
off stretching or scaling and just
work with rotating. So now I can nicely
rotate and show that this is window will be
pushed duplicate. This window as well, there'll be pushed duplicate. And now I would like to
make this window, but if, when I rotate, the
arrow doesn't work. So here is a trick
and other trick, just two fingers tap. Here we have some
flipping according the vertical axis or according
the horizontal axis. So you can very
quickly change from where you want to use the arrow. There we are. Very nice
displaying of arrows as well. We can point like here
and duplicate that. We have also the entrance here. So play the arrows for your specific steps
in your diagrams. And we can select
as well that e.g. holes are made here and
the windows are made here. So don't need to duplicate the intention of arrows,
what we are doing. So now we can nicely show what
we're doing in each phase. Perfect.
16. Number your stages: Perfect. Don't forget
to write down as well. I can bring the huge number and I can write that
this is the step one. Write and duplicate
these number. To make it nicer. These will be 234. Okay? And now 234. And extend these two
lines. We've stretch. These three, induce
as well or maybe not. So this is our approach and
play with diagrams with eyes, symmetrical shape,
isometric grid. And let's do a quick export.
17. Export: So 40 export, double-click on the export and you can choose whatever format you
want in pro version. So I will pick the JPEG, the size of a screenshot. That means that also
a little part of my reference picture
will be shown. If you don't want to
do this, just click. Go for four fingers, tap so you will see what
everything will be visible. Just zoom in a little
bit, something like that. And now again, four fingers. Double-click on Export. Choose JPEG, choose
screenshot size, not the whole drawing. Choose plain whites, not the
grid. We don't want a grid. You can choose a paper
style if you want them, but I chose a plane. And here is the great thing. You can export up to 400% scale because
this is the vector. So you can go like
10,000 pixels. She's not necessary right now. So I will go for
100%, which is nice, 2,700 pixels. It's great. And just click Export. This is the preview and you
can just hit Save Image. This is our picture. And very nice diagram
from the building.
18. Final words and task: So hope you enjoyed
that as much as I did. And I'm looking forward
for your interpretation, your colors of your styles, of your arrows and your steps. So make sure you upload your creation and
looking forward to, to be in touch with
you. Bye guys.
Dalibor Dzurilla, Strategic Architect Presentator
